Page 17 of 308
![Mercury Mercury Cougar 1997 Owners Manuals 14 [IS07350( BC )03/96]
one inch art:0011209-AThe low coolant light
%*
[IS07500( ALL)01/96]
Charging System Light
*
[IS07600( ALL)01/96]
This light indicates that your battery is not being
charged and Mercury Mercury Cougar 1997 Owners Manuals 14 [IS07350( BC )03/96]
one inch art:0011209-AThe low coolant light
%*
[IS07500( ALL)01/96]
Charging System Light
*
[IS07600( ALL)01/96]
This light indicates that your battery is not being
charged and](/img/33/10905/w960_10905-16.png)
14 [IS07350( BC )03/96]
one inch art:0011209-AThe low coolant light
%*
[IS07500( ALL)01/96]
Charging System Light
*
[IS07600( ALL)01/96]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[IS07700( ALL)04/96]
one inch art:0010119-B
The charging system light
*
[IS07800( ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS07900( ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
%*
[IS08400( BCGV)03/96]
Overdrive Off Indicator
[IS08600( ALL)04/96]
one inch art:0010730-B
The overdrive off indicator light
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996
Page 192 of 308
![Mercury Mercury Cougar 1997 Owners Manuals 191
*
[ER19400(MBC )12/95]
Removing the anti-theft lug nut
*
[ER19500(MBC )02/96]
Insert the key over the locking lug nut. Make
sure that you hold the key square to the lug nut.
If you hold the key on Mercury Mercury Cougar 1997 Owners Manuals 191
*
[ER19400(MBC )12/95]
Removing the anti-theft lug nut
*
[ER19500(MBC )02/96]
Insert the key over the locking lug nut. Make
sure that you hold the key square to the lug nut.
If you hold the key on](/img/33/10905/w960_10905-191.png)
191
*
[ER19400(MBC )12/95]
Removing the anti-theft lug nut
*
[ER19500(MBC )02/96]
Insert the key over the locking lug nut. Make
sure that you hold the key square to the lug nut.
If you hold the key on an angle, you may
damage the key and the lug nut.
*
[ER19600(MBC )12/95]
Place the lug nut wrench over the lug nut key
and apply pressure on the key with the wrench.
Turn the wrench in a counterclockwise direction
to remove the lug nut.
*
[ER19700(MBC )12/95]
Reinstalling the anti-theft lug nut
*
[ER19800(MBC )12/95]
Insert the key over the locking lug nut. Place the
lug nut wrench over the lug nut key and, while
applying pressure on the key, install the lug nut.
%
*
[ER19900( ALL)02/96]
Jump-Starting Your Vehicle
*
[ER19950( ALL)02/96]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start your vehicle with a
booster battery.
*
[ER20000( ALL)02/96]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[ER20100( ALL)02/96]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
File:10rcerc.ex
Update:Thu May 30 10:30:02 1996
Page 225 of 308
![Mercury Mercury Cougar 1997 Owners Manuals 225 [MC22800(MBC )12/95]
one third page art:0011152-A
Detail of the automatic transmission dipstick
%*
[MC23200( ALL)01/96]
Battery
*
[MC23300( ALL)01/96]
Your vehicle may have a Motorcraft
maintenanc Mercury Mercury Cougar 1997 Owners Manuals 225 [MC22800(MBC )12/95]
one third page art:0011152-A
Detail of the automatic transmission dipstick
%*
[MC23200( ALL)01/96]
Battery
*
[MC23300( ALL)01/96]
Your vehicle may have a Motorcraft
maintenanc](/img/33/10905/w960_10905-224.png)
225 [MC22800(MBC )12/95]
one third page art:0011152-A
Detail of the automatic transmission dipstick
%*
[MC23200( ALL)01/96]
Battery
*
[MC23300( ALL)01/96]
Your vehicle may have a Motorcraft
maintenance-free battery. When the original
equipment battery is replaced under warranty, it
may be replaced by a Motorcraft
Low-Maintenance Battery.
*
[MC23400( ALL)01/96]
The Low-Maintenance Battery has removable
vent caps for checking the electrolyte level and
for adding water, if necessary. The electrolyte
level should be checked at least every 24 months
or 24,000 miles (40,000 km) in temperatures up
to 90ÊF (32ÊC) andmore often in temperatures
above90ÊF (32ÊC).Keep the electrolyte level in
each cell up to the level indicator. Do not
overfill.
*
[MC23500( ALL)01/96]
If the level gets low, you can add tap water to
the battery, provided the water isn't hard or
doesn't have a high mineral or alkali content.
However, if possible you should refill the battery
with distilled water. If the battery needs water
quite often, have the charging system checked
for a possible malfunction.
File:11rcmcc.ex
Update:Mon Jun 3 09:27:52 1996
Page 258 of 308
![Mercury Mercury Cougar 1997 Owners Manuals 258 %
*
[CS05200( ALL)01/96]
Cooling system
*
[CS05300( ALL)01/96]
q
Protect against freezing temperatures.
%*
[CS05400( ALL)01/96]
Battery
*
[CS05500( ALL)01/96]
q
Check and recharge as necessary.
*
Mercury Mercury Cougar 1997 Owners Manuals 258 %
*
[CS05200( ALL)01/96]
Cooling system
*
[CS05300( ALL)01/96]
q
Protect against freezing temperatures.
%*
[CS05400( ALL)01/96]
Battery
*
[CS05500( ALL)01/96]
q
Check and recharge as necessary.
*](/img/33/10905/w960_10905-257.png)
258 %
*
[CS05200( ALL)01/96]
Cooling system
*
[CS05300( ALL)01/96]
q
Protect against freezing temperatures.
%*
[CS05400( ALL)01/96]
Battery
*
[CS05500( ALL)01/96]
q
Check and recharge as necessary.
*
[CS05600( ALL)01/96]
q
Keep connections clean and covered with a
light coat of grease.
*
[CS05700( ALL)12/95]
q
If storing your vehicle for more than 30 days
without recharging the battery, it may be
advisable to disconnect the battery cables to
ensure battery charge is maintained for quick
starting.
[CS05800( ALL)12/95]
NOTE: If battery cables are disconnected, it
will be necessary to reset memory
features.
%*
[CS05900( ALL)01/96]
Brakes
*
[CS06000( ALL)01/96]
q
Make sure brakes and parking brake are fully
released.
%*
[CS06100( ALL)01/96]
Tires
*
[CS06200( ALL)01/96]
q
Maintain recommended air pressure.
*
[CS06300( ALL)01/96]
Miscellaneous
*
[CS06400( ALL)01/96]
q
Make sure all linkages, cables, levers and
clevis pins under vehicle are covered with
grease to prevent rust.
*
[CS06500( ALL)01/96]
q
Move vehicles at least 25 feet (8 m) every 15
days to lubricate working parts and prevent
corrosion.
File:12rccsc.ex
Update:Thu May 30 10:31:57 1996
Page 288 of 308

296 Index
Anti-theft lug nuts and key........ 189
Anti-theft system
arming the system........... 97
description............... 96
disarming an untriggered system..... 98
disarming a triggered system....... 99
triggering............... 98
warning light.............. 16
Appeals (see Dispute settlement board) . . 266
Assistance (see Customer assistance).... 263
Audio system (see Electronic
sound system)............. 25
Autolamp system (see Headlamps)..... 69
Automatic transmission
driving an automatic overdrive..... 157
fluid, adding............. 224
fluid, checking............ 223
fluid, refill capacities......... 254
fluid, specification........... 255
Axle
lubricant specifications......... 255
refill capacities............ 254
traction lok.............. 154
B
Backing up............... 159
Basic vehicle warranty........... 4
Battery................. 225
acid, treating emergencies....... 192
charging system warning light...... 14
disconnecting............. 226
how to service............ 225
jumping a disabled battery....... 191
maintenance-free........... 225
proper disposal, recycling....... 226
replacement, specifications....... 253
servicing............... 225
File:rcixc.ex
Update:Mon Jun 3 09:28:38 1996
Page 290 of 308

298 Index
Bulbs, replacing............. 243
halogen............... 244
headlamps.............. 244
high-mount brakelamp........ 246
specifications............. 248
C
Canada, customer assistance....... 271
Canada, warranty information....... 4
Canadian Motor Vehicle Arbitration Plan
(CAMVAP).............. 271
Capacities for refilling fluids....... 254
Carbon monoxide in exhaust....... 149
Car seats for children
(see Child safety seats)........ 125
Cassette tape player (see Electronic
sound system)............. 36
Catalytic converter............ 239
CD player (see Electronic sound system) . . . 25
Chains, tires.............. 232
Changing a tire............. 181
Charging system warning light....... 14
Child safety restraints.......... 124
child safety belts........... 142
child safety seats........... 125
Child safety seats............ 125
and air bags............. 125
automatic locking mode
(retractor)...........112, 125
in front seat............. 125
in rear outboard seat......... 125
in rear seat............125, 140
tether anchorage hardware....... 141
Chime
key in ignition............. 74
safety belt............... 12
Circuit breakers
checking and replacing........ 179
see also fuses............. 171
File:rcixc.ex
Update:Mon Jun 3 09:28:38 1996
Page 299 of 308

Index 307
Lamps (continued)
flashing the lamps........... 76
hazard flashers............. 78
headlamps............... 68
high beams.............. 75
high-mount brakelamp........ 246
illuminated entry system........ 91
illuminated mirrors........... 89
instrument panel, dimming....... 71
interior lamps............. 71
replacing bulbs............ 243
trailer................ 167
Lane change indicator (see Turn signal) . . . 74
Lap belts................ 117
Lights, warning and indicator
airbag................. 13
anti-lock brakes (ABS).......... 11
anti-theft................ 16
brake................. 10
charging system............ 14
door ajar................ 18
engine oil pressure........... 18
hazard warning light.......... 78
high beam............... 16
low coolant.............. 13
low fuel................ 19
low washer fluid............ 20
oil pressure.............. 18
overdrive off.............. 14
safety belt............... 12
service engine soon........... 16
theft system.............. 16
turn signal indicator.......... 17
Load limits............... 162
GAWR................ 162
GVWR................ 162
trailer towing............. 164
File:rcixc.ex
Update:Mon Jun 3 09:28:38 1996
