engine Mercury Mercury Cougar 1997 Owner's Manuals

6
%*
[II03400( ALL)01/96]
Breaking Your Vehicle In
*
[II03500( ALL)01/96]
Your new vehicle goes through an adjustment or
break-in period during the first 1,000 miles
(1,600 km) that you drive it. During the break-in
period, you need to pay careful attention to how
you drive your vehicle.
%*
[II03600( ALL)01/96]
q
Avoid sudden stops.Because your vehicle
has new brake linings, you should take these
steps:
*
[II03700( ALL)01/96]
Ð Watch traffic carefully so that you can
anticipate when to stop.
*
[II03800( ALL)01/96]
Ð Begin braking well in advance.
*
[II03900( ALL)01/96]
Ð Apply the brakes gradually.
*
[II04000( ALL)01/96]
The break-in period for new brake linings
lasts for 100 miles (160 km) of city driving or
1,000 miles (1,600 km) of highway driving.
%*
[II04100( ALL)03/96]
q
Use only the type of engine oil that Ford
recommends.SeeEngine oil recommendations
in the Index. Do not use special ªbreak-inº
oils.
*
[II04200( ALL)03/96]
Your vehicle is equipped with an Electronic
Powertrain Control Module that limits engine
and/or vehicle speeds with a cut-out mode to
promote durability.
File:02rciic.ex
Update:Thu May 30 10:22:07 1996

10
%*
[IS01700( BCGV)01/96]
The Mechanical Cluster
*
[IS02000( BCGV)01/96]
The following warning lights and gauges are on
the mechanical cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
%*
[IS02600( ALL)01/96]
Brake System Warning Light
*
[IS02700( ALL)03/96]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by a
qualified service technician.
[IS02800( BC )04/96]
one inch art:0000108-E
The brake system warning light
[IS03100( ALL)12/95]
This light comes on when the parking brake is
set, or if it is not set, it comes on briefly when
you turn the ignition key to START. It normally
goes off shortly after the engine starts and you
release the parking brake. If the light stays on
after you have fully released the parking brake,
have the hydraulic brake system serviced.
*
[IS03200( ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

11 % [IS03300( ALL)04/96]
Anti-Lock Brake System Light
(If equipped)
[IS03400( ALL)12/95]
This warning light will go on each time you
start your vehicle. If it remains on for longer
than five seconds, you should shut off your
engine and restart. If the anti-lock brake light
stays on, this indicates that the anti-lock feature
is disabled and should receive immediate
attention by a qualified service technician.
Normal braking is not affected unless the brake
warning light is also lit.
*
[IS03500( ALL)03/96]
The Anti-Lock Brake System has self-check
capabilities. As previously described, the system
turns on the anti-lock light each time you start
your engine. After the engine is started and the
anti-lock light is out, the system performs
another test the first time the vehicle reaches
14 mph (22 km/h). The system turns on the
Anti-Lock Brake System (ABS) pump motor for
approximately 1/2 second. At this time a
mechanical noise may be heard. This is a normal
part of the self-check feature. If a malfunction is
found during this check the anti-lock light will
come on.
[IS03600( ALL)04/96]
one inch art:0011194-B
The anti-lock brake system light
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

13 %
*
[IS06300( ALL)03/96]
Air Bag Readiness Light
*
[IS06400( ALL)04/96]
The air bag system uses a readiness light and a
tone to indicate the condition of the system. The
readiness light is in the instrument cluster. When
you turn the ignition key to the ON position,
this light will light up for six (6) seconds and
then turn off. This indicates that the system is
operating normally. NOTE: Regularly scheduled
maintenance of the air bag system is not
required.
*
[IS06500( ALL)04/96]
If the light fails to illuminate, continues to flash,
remains on, or you hear a beeping sound, have
the system serviced at your Ford or
Lincoln-Mercury dealer immediately.
[IS06700( BC )04/96]
one inch art:0000653-C
The air bag readiness light
% [IS07150( BC )03/96]
Low Coolant Light
[IS07200(MBC )04/96]
This light tells you that the coolant is low inside
the coolant recovery bottle and that you should
add more coolant.
[IS07300(MBC )04/96]
This light comes on for a few seconds when
your ignition key is turned to start, but should
turn off when the engine starts. If this light stays
on, check the level of coolant inside the recovery
bottle. SeeEngine Coolantin the Index.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

14 [IS07350( BC )03/96]
one inch art:0011209-AThe low coolant light
%*
[IS07500( ALL)01/96]
Charging System Light
*
[IS07600( ALL)01/96]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[IS07700( ALL)04/96]
one inch art:0010119-B
The charging system light
*
[IS07800( ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS07900( ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
%*
[IS08400( BCGV)03/96]
Overdrive Off Indicator
[IS08600( ALL)04/96]
one inch art:0010730-B
The overdrive off indicator light
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

16 %
*
[IS09000( ALL)03/96]
High Beam Light
*
[IS09100( ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
[IS09200( ALL)04/96]
one inch art:0010125-B
The high beam light
%*
[IS11050( BC )12/95]
Service Engine Soon Warning Light
%*
[IS11100( ALL)05/96]
This light illuminates when the engine's
Emission Control System requires service. It will
also illuminate when the ignition key is in the
ON position and the engine is off.
[IS11350( BC )05/96]
one inch art:0000282-B
The service engine soon warning light
%*
[IS12100( BC )04/96]
Anti-Theft Alarm Light (If equipped)
[IS12150(MBC )04/96]
one inch art:0001389-A
Anti-theft alarm light
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

18 % [IS13001( BC )03/96]Door Ajar Light (If equipped)
[IS13101( BC )03/96]
This light tells you when any door is not
completely shut. It glows when the key is in the
ON position.
[IS13201( BC )03/96]
one inch art:0010126-C
The door ajar light
%*
[IS13250( BC )04/96]
Engine Oil Pressure Light
[IS13300( BC )05/96]
This light indicates the engine oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. The light
should come on every time your ignition key is
turned to ON or START, and should go out
when the engine starts. If the light stays on or
turns on while the engine is running, you have
lost oil pressure andcontinued operation will
cause severe engine damage.
[IS13350( BC )05/96]
one inch art:0010532-A
The engine oil pressure light
*
[IS13400( BC )05/96]
If you lose engine oil pressure:
*
[IS13450( BC )04/96]
1. Pull off the road as soon as safely possible.
*
[IS13500( BC )05/96]
2. Shut off the engine immediately. If you do
not stop the engine as soon as safely
possible, severe engine damage could result.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

19 [IS13550( BC )04/96]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, seeEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your vehicle should be on level
ground.
[IS13600( BC )03/96]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the light is on, regardless of the oil level.
Contact your nearest dealer for service as
soon as possible.
*
[IS13700( BC )03/96]
For more information about adding oil, see
Adding engine oilin theMaintenance and Care
chapter of this guide.
%*
[IS13750( BC )04/96]
Low Fuel Light
[IS13800( BC )04/96]
This light comes on when your fuel gauge
indicates approximately 1/8 to 1/16 of a tank.
Your vehicle must be turned to ON for this light
to come on. This light will either flicker or glow
steadily.
[IS13850( BC )04/96]
one inch art:0000116-C
The low fuel light
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

21
*
[IS14800( ALL)01/96]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
%*
[IS15700( ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS15800( ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS15905( BCGV)04/96]
The pointer moves from the C (cold) mark into
the normal band as your engine coolant warms
up. Under normal driving conditions, the pointer
should stay in the normal band. It is acceptable
for the pointer to fluctuate within the noprmal
band under normal driving conditions, and
under certain driving conditions such as, heavy
stop and go traffic, or driving up hills in hot
weather, for the pointer to indicate at the top of
the normal band.
[IS16005( BCGV)04/96]
If, under any circumstances, the pointer moves
above the normal band, the engine is
overheating and continued operation may cause
engine damage.
% [IS16200( BC )04/96]
one third page art:0011144-D
The engine coolant temperature gauge
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

22
*
[IS16400( ALL)03/96]
If your engine overheats:
*
[IS16500( ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS16600( ALL)01/96]
2. Turn off the engine.
*
[IS16700( ALL)03/96]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[IS16800( ALL)03/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[IS16900( ALL)03/96]
If the coolant continues to overheat, have the
coolant system serviced.
%*
[IS18100( ALL)03/96]
Speedometer
[IS18200( BC )04/96]
one third page art:0011341-B
The speedometer
*
[IS18350( ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS18900( ALL)03/96]
Odometer
*
[IS19000( ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996
