Page 32 of 248
Controls and features
32• DEF – Distributes outside air
through the windshield defroster
ducts. It can be used to clear ice or
fog from the windshield. If the
temperature is about 10°C (50°F)
or higher, the air conditioner will
automatically dehumidify the air to
reduce fogging.
Operating tips
• In humid weather, select DEF
before driving. This will reduce
fogging on your windshield. After a
few minutes, select any desired
position.
• To reduce humidity buildup
inside the vehicle, don’t drive with
the climate control system in the
OFF position.
• Don’t put objects under the front
seat that will interfere with the
airflow to the back seats.
• Remove any snow, ice or leaves
from the air intake area (at the
bottom of the windshield under the
hood).
• If your vehicle has been parked
with the windows closed during hot
weather, the air conditioner will do
a much faster job of cooling if you
drive for two or three minutes with
the windows open. This will force
most of the hot, stale air out of the
vehicle. Then operate your air
conditioner as you would normally.
13MCfen 24.6.99 15:05 Uhr Seite 32
Page 145 of 248
Roadside emergencies
145 Ampere
ratingCircuits protected
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
39
40
41
42
43
44
45
46
47
48
49
50
51
52—
7.5
20
—
—
3
20
—
15
—
20
—
20
7.5
7.5
7.5
7.5
7.5
—
20*
20*
40*
—
—
60*
—
—
—
60*
—
60*
60*Not used
Alternator
Foglamps
Not used
Not used
EEC ignition module (memory)
Horn and hazard flasher warning system
Not used
Fuel pump
Not used
Ignition, Electronic Engine Control
Not used
HEGO sensor
ABS module
Low beam headlamp (passenger’s side)
Low beam headlamp (driver’s side)
High beam headlamp (passenger’s side)
High beam headlamp (driver’s side)
Not used
Ignition, light switch, central junction box
EEC relay
Central junction box (fuse 37 to blower relay)
Not used
Not used
Ignition
Not used
Not used
Not used
Engine cooling
not used
ABS
Central junction box (central timer module, rear
window defrost relay, fuses 24, 25, 27, 28, 34) Fuse
Power distribution box (engine compartment)
* Have these fuses replaced by your dealer or qualified technician.
23MREen 24.6.99 15:28 Uhr Seite 145
Page 146 of 248
Roadside emergencies
146Passenger compartment fuse
panel
To check or change a fuse or a
relay, open the fuse box by pulling
down the lock release lever (1).
1
Power distribution box (engine compartment)
RelayCircuits switched
R 1
R 2
R 3
R 4
R 5
R 6
R 7
R 8
R 9
R 10
R 11
D1
D2
Fuel pump
EEC module
Air conditioning
Low beam
High beam
Horn
Starter solenoid
Engine cooling fan (high speed)
Engine cooling fan
Not used
Daytime running lights
Reverse voltage protection
Not used
23MREen 24.6.99 15:28 Uhr Seite 146
Page 155 of 248
Roadside emergencies
155
3. Park the booster vehicle close to
the hood of the disabled vehicle,
making sure the two vehicles do
nottouch. Set the parking brake
on both vehicles and stay clear of
the engine cooling fan and other
moving parts.
4. Check all battery terminals and
remove any excessive corrosion
before you attach the battery
cables. Ensure that vent caps are
tight and level.
5. Turn the heater fan on in both
vehicles to protect from any
electrical surges. Turn all other
accessories off.
Connecting the jumper cables
1. Connect the positive (+) booster
cable to the positive (+) terminal of
the discharge battery.
Note:In the illustrations,
“lightning bolts” are used to
designate the assisting (boosting)
battery.
23MREen 24.6.99 15:28 Uhr Seite 155
Page 163 of 248
Maintenance and care
163 Precautions when servicing
your vehicle
Be especially careful when
inspecting or servicing your
vehicle. Here are some general
precautions for your safety:
• Do not work on a hot engine.
The cooling fan is automatic
and may come on at any
time. Always disconnect the
negative terminal of the battery
before working near the fan.
• If you must work with the engine
running, avoid wearing loose
clothing or jewelry that could get
caught in moving parts. Take
precautions with long hair.
• Do not work on a vehicle with the
engine running in an enclosed
space, unless you are sure you have
enough ventilation.
• Keep all lit cigarettes, open
flames and other lit material away
from the battery and all fuel related
parts.
If you disconnect the battery, the
engine must “relearn” its idle
conditions before your vehicle will
drive properly, as explained under
Battery in this chapter.
31MMCen 24.6.99 15:30 Uhr Seite 163
Page 173 of 248
Maintenance and care
173
MAX
MIN
The importance of engine
coolant
Engine coolant provides freeze
protection, boil protection, cooling
efficiency and corrosion protection
to the engine and cooling
components. In order to obtain
these protections, the engine
coolant must be maintained at the
proper concentration and fluid
level in the coolant reservoir.
Your vehicle was factory-filled with
a 50/50 engine coolant and water
concentration. If the concentration
of coolant falls below 40 % or rises
above 60 %, the engine parts could
become damaged or not work
properly. A 50/50 mixture of
coolant and water provides the
following:
• Boiling protection up to 265°F
(129°C).
• Freeze protection down to -34°F
(-36°C).
• Protection against rust and other
forms of corrosion.
• Enables calibrated gauges to
function properly. Cooling system - engine coolant
31MMCen 24.6.99 15:30 Uhr Seite 173
Page 174 of 248
Maintenance and care
174Checking engine coolant
The concentration and level of
engine coolant should be checked
at the mileage intervals listed in the
“Scheduled Maintenance Guide“.
The coolant concentration should
be maintained at 50/50 coolant and
water, which equates to a freeze
point of -34°F (-36°C). Coolant
concentration testing is possible
with a hydrometer or antifreeze
tester (such as the Rotunda
Battery and Antifreeze Tester, 014-
R1060). The level of coolant should
be maintained at the “cold full“ or
“cold fill range“ level in the coolant
reservoir. If the level falls below,
add coolant per the instructions in
the Adding engine coolant
section.
Adding engine coolant
When adding engine coolant, make
sure it is a 50/50 mixture of engine
coolant and distilled water. Add the
mixture to the coolant reservoir
when the engine is cool until the
appropriate fill level is obtained.
Do not put engine coolant in
the windshield washer fluid
container. If sprayed on the
windshield, engine coolant could
make it difficult to see through the
windshield.
Do not add engine coolant
when the engine is hot.
Steam and scalding liquids
released from a hot cooling system
can burn you badly. Also, you can
be burned if you spill coolant on
hot engine parts.
The coolant system in your vehicle
is filled with Ford Premium Engine
Coolant E2FZ-19549-AA
(Motorcraft CXC-8-B in Canada) or
equivalent meeting Ford
specification ESE-M97B44-A.
To maintain the integrity of the
coolant and the cooling system
and maintain the warranty on
the cooling system:
•Add the type of coolant
originally equipped in your
vehicle. If you are unsure which
type of coolant your vehicle
requires, contact your local dealer.
•Do not mix the factory-filled
coolant with an orange-colored
EXTENDED LIFE COOLANT
such as F6AZ-19544-A, meeting
WSS-M97B44-D. Mixing of Ford
Premium Engine Coolant with an
extended life product can result in
degraded corrosion protection.
31MMCen 24.6.99 15:30 Uhr Seite 174
Page 175 of 248
Maintenance and care
175 • A large amount of water without
engine coolant may be added, in
case of emergency, to reach a
vehicle service location. In this
instance, the cooling system must
be drained and refilled with a 50/50
mixture of engine coolant and
distilled water as soon as possible.
Water alone (without engine
coolant) can cause engine damage
from corrosion, overheating or
freezing.
•Do not use alcohol or
methanol or any engine
coolants mixed with alcohol or
methanol antifreeze (coolant).
Alcohol and other liquids can cause
engine damage from overheating or
freezing.
•Do not add extra inhibitors
or additives to the coolant.
These can be harmful and
compromise the corrosion
protection of the engine coolant.
•Do not mix with recycled
coolant unless the bottle label
states compliance with Ford
specification ESE-M97B44-A.
31MMCen 24.6.99 15:30 Uhr Seite 175
Page 176 of 248
Maintenance and care
176
MAX
MIN
1. Before you begin, turn the
engine off and let it cool.
2. When the engine is cool, wrap a
thick cloth around the coolant
pressure relief cap on the coolant
reservoir (an opaque plastic
bottle). Slowly turn the cap
counterclockwise (left) until the
pressure begins to release.
3. Step back while the pressure
releases (you may hear a hissing
sound).
4. When you are sure that all the
pressure has been released from
the cooling system, use the cloth to
turn the cap counterclockwise and
remove it.
5. Fill the coolant reservoir slowly
with the proper coolant mixture
(see above) to within the “cold full“
or the “cold fill range“ level on the
reservoir.
6. Replace the cap. Turn until
tightly installed. (Cap must be
tightly installed to prevent coolant
loss.)
To avoid personal injury,
make sure the engine is cool
before unscrewing the coolant
pressure relief cap. The cooling
system is under pressure; steam
and hot liquid can come out
forcefully when the cap is
loosened slightly.
31MMCen 24.6.99 15:30 Uhr Seite 176
Page 177 of 248
Maintenance and care
177 After any coolant has been added,
check the coolant concentration
(see Checking engine coolant
section). If the concentration is not
50/50 (protection to -34°F /-36°C),
drain some coolant and adjust the
concentration. It may take several
drains and additions to obtain a
50/50 coolant concentration.
Whenever coolant has been added,
the coolant level in the coolant
reservoir should be checked the
next few times you drive the
vehicle. If necessary, add enough
50/50 concentration of engine
coolant and distilled water to bring
the liquid level to the proper level.
If you have to add more than
1.0 liter (1.0 quart) of engine
coolant per month, have your
dealer check the engine cooling
system. Your cooling system may
have a leak. Operating an engine
with a low level of coolant can
result in engine overheating and
possible engine damage.
Changing engine coolant
Change your engine coolant
according to the appropriate
schedule listed in the “Scheduled
Maintenance Guide“. It is important
that the engine coolant be changed
at the specified intervals. The
corrosion protection of engine
coolant is depleted with time and
usage. Use of engine coolant with
depleted corrosion protection may
result in damage to the coolant
system. Color, specific gravity and
freeze point of the coolant are not indicators of depletion.
To find out how much fluid your
vehicle’s cooling system can hold,
refer to the Refill capacities in the
Capacities and Specifications
chapter. Fill your coolant reservoir
following the directions given in
the Adding engine coolant
section.
Coolant usage in severe winter
climate
If you drive in extremely cold
climates less than -34°F (-36°C), it
may be necessary to increase the
coolant concentration above 50 %.
Refer to the chart on the coolant
container to ensure the coolant
concentration in your vehicle will
provide adequate freeze protection.
Never increase the engine
coolant concentration above
60 %(protection to -60°F). At a
level over 60 %, your engine could
overheat and become damaged.
Coolant usage in hot climate
If you drive in hot climates, it is still
necessary to maintain the coolant
concentration at 50/50 coolant and
water. Do not allow the
concentration to fall below
40 % coolant.At a concentration
less than 40 %, the corrosion
protection to your engine and
cooling components may be
compromised and permanent
damage may result.
31MMCen 24.6.99 15:30 Uhr Seite 177
