washer fluid Mercury Mystique 2000 Owner's Manuals

Maintenance and care
167 For ease of identification, all filler caps and the engine oil dipstick are
marked yellow/black. 2.0 litre EFI-engine compartment
Power
steering
reservoirEngine
coolant
reservoirAutomatic
transaxle
dipstick
(if equipped)Brake fluid
reservoir
BatteryWindshield
washer fluid
reservoirEngine oil
dipstickPower
distribution
box
Air
cleaner
Engine oil
filler cap
31MMCen 24.6.99 15:30 Uhr Seite 167

Maintenance and care
168
Power
steering
reservoirEngine
coolant
reservoir 2.5 litre EFI-engine compartment
For ease of identification, all filler caps and the engine oil dipstick are
marked yellow/black.Air
cleanerBrake fluid
reservoirAutomatic
transaxle
dipstick
(if equipped)
BatteryWindshield
washer fluid
reservoirEngine oil
dipstickPower
distribution
boxEngine oil
filler cap
31MMCen 24.6.99 15:30 Uhr Seite 168

Maintenance and care
172Brake/clutch fluid reservoir
Brake and clutch fluid systems are
supplied from the same reservoir.
The level of the fluid must lie
between the MIN and MAX marks
on the side of the reservoir. If the
level falls below the MIN mark, the
brake fluid level warning light on
the instrument cluster will
illuminate. Add only DOT 3, DOT 4
or Super DOT 4 brake fluid that
meets the Ford specification (see
the chapter Capacities and
specifications).
If you use brake fluid that is not
DOT 3, DOT 4 or Super DOT 4 you
will cause permanent damage to
your brakes.
MAX
MIN
Brake fluid is toxic.
BRAKE
BRAKE
Do not let the reservoir for
the master cylinder run dry.
This may cause the brakes to fail.
Windshield washer system
If necessary, add enough washer
fluid to fill the reservoir. Follow the
instructions on the washer fluid
label.
Do not put engine coolant in
the container for the
windshield washer fluid.
Alternative design
31MMCen 24.6.99 15:30 Uhr Seite 172

Maintenance and care
174Checking engine coolant
The concentration and level of
engine coolant should be checked
at the mileage intervals listed in the
“Scheduled Maintenance Guide“.
The coolant concentration should
be maintained at 50/50 coolant and
water, which equates to a freeze
point of -34°F (-36°C). Coolant
concentration testing is possible
with a hydrometer or antifreeze
tester (such as the Rotunda
Battery and Antifreeze Tester, 014-
R1060). The level of coolant should
be maintained at the “cold full“ or
“cold fill range“ level in the coolant
reservoir. If the level falls below,
add coolant per the instructions in
the Adding engine coolant
section.
Adding engine coolant
When adding engine coolant, make
sure it is a 50/50 mixture of engine
coolant and distilled water. Add the
mixture to the coolant reservoir
when the engine is cool until the
appropriate fill level is obtained.
Do not put engine coolant in
the windshield washer fluid
container. If sprayed on the
windshield, engine coolant could
make it difficult to see through the
windshield.
Do not add engine coolant
when the engine is hot.
Steam and scalding liquids
released from a hot cooling system
can burn you badly. Also, you can
be burned if you spill coolant on
hot engine parts.
The coolant system in your vehicle
is filled with Ford Premium Engine
Coolant E2FZ-19549-AA
(Motorcraft CXC-8-B in Canada) or
equivalent meeting Ford
specification ESE-M97B44-A.
To maintain the integrity of the
coolant and the cooling system
and maintain the warranty on
the cooling system:
•Add the type of coolant
originally equipped in your
vehicle. If you are unsure which
type of coolant your vehicle
requires, contact your local dealer.
•Do not mix the factory-filled
coolant with an orange-colored
EXTENDED LIFE COOLANT
such as F6AZ-19544-A, meeting
WSS-M97B44-D. Mixing of Ford
Premium Engine Coolant with an
extended life product can result in
degraded corrosion protection.
31MMCen 24.6.99 15:30 Uhr Seite 174

Maintenance and care
219 Cleaning the engine
Engines are more efficient when
they are clean because grease and
dirt buildup act as insulators and
keep the engine warmer than
normal. Follow these guidelines to
clean your engine:
• Take care when using a power
washer to clean the engine. The
high pressure fluid could penetrate
the sealed parts and cause damage.
• Do not spray with cold water, to
avoid cracking the engine block.
• Cover the alternator to prevent
water damage when cleaning the
engine.
• Never wash or rinse the engine
while it is running; water in the
running engine may cause internal
damage.
31MMCen 24.6.99 15:31 Uhr Seite 219

Capacities and specifications
224
* Total capacity
** with automatic transaxle
Engine oil
- with filter
- without
Manual transaxle 1.9 l (2.0 qts)
Automatic transaxle
with oil cooler
Power steering
Cooling system with heating
Windshield washer fluid
Fuel tank
Braking system4.25 l (4.5 qts)
3.75 l (4.0 qts)
8.5 l (9.0 qts.)
6.6 l (7.0 qts)*
7.1 l (7.5 qts)**
Fill to MAX mark
Fill to top of reservoir
58.5 l (15.4 gallons)
Fill to MAX mark5.5 l (5.8 qts)
5.0 l (5.3 qts)
9.6 l (10.2 qts)
9.5 l (10.0 qts)*
9.7 l (10.2 qts)**
Capacities2.0 litre
engine2.5 litre
engine
32MCSen 24.6.99 15:34 Uhr Seite 224

ItemFord part name
or equivalent
High Performance
DOT 3 Motor
Vehicle Brake
Fluid, (North
America)
DOT 4 Brake
Fluid or Super
DOT 4 (Europe)
Premium engine
coolant
Super Premium
SAE 5W-30 Motor
Oil
Motorcraft
MERCON
®AT F
Motorcraft*
MERCON
®AT F
Ultra-Clear
Windshield Washer
Concentrate
Ford
part number
C6AZ-19542-AB
for DOT 3
E2FZ-19549-AA
CXC-8-B (Canada)
F5FZ-19549-CC
(Oregon)
XO-5W30-QSP
XT-2-QDX
XT-2-QDX
C9AZ-19550-AC
or
C9AZ-19550-BC
Ford
specification
ESA-M6C25-A
(DOT 3) (North
America
ESD-M6C57-A
(Super DOT 4)
(Europe)
ESE-M97B44-A
API Certification
Mark and
WSS-M2C153-G
MERCON®
MERCON®
ESR-M17P5-A Brake fluid
Engine coolant
Engine oil
Power steering
fluid
Transaxle fluid
automatic/
5-speed manual
Windshield
washer
fluid
* Use only MERCON®
approved transmission/transaxle fluid. Use of any fluid approved and/or labeled
for MERCON®
V may cause internal transaxle damage.
Capacities and specifications
225
Lubricant Specifications
32MCSen 24.6.99 15:34 Uhr Seite 225

Index
247 TPage
Tachometer . . . . . . . . . . . . . . . . .21
Tail lamps (see Lamps)
Temperature control
(see Climate control)
Testing the warning lights . . . . . .19
Tether anchor installation
(see Child safety restraints)
Tilt steering wheel . . . . . . . . . . . .55
Tires
changing . . . . . . . . . . . . . . . . .150
checking tire pressure . . . . . .191
cleaning . . . . . . . . . . . . . . . . . .218
inspection and maintenance . .191
replacing . . . . . . . . . . . . . . . . .192
rotating . . . . . . . . . . . . . . . . . .191
snow tires and chains . . . . . . .194
spare tire . . . . . . . . . . . . . . . . .151
tire grades . . . . . . . . . . . . . . . .188
treadwear . . . . . . . . . . . . .189, 192
wearbands . . . . . . . . . . . . . . . .192
Towing your vehicle . . . . . . . . .161
Trailer towing . . . . . . . . . . . . . .134
Transaxle
automatic, operation . . . . . . . .121
fluid, checking and adding
(automatic) . . . . . . . . . . . . . . .179
fluid, refill capacities . . . . . . . .224
lubricant specifications . . . . . .225
manual, operation . . . . . . . . . .127
Transmitter (see Remote entry)
Trip odometer . . . . . . . . . . . . . . .20
Trunk (see Luggage compartment)
remote release lever . . . . . . . . .66
using the remote entry system .69
Turn signal
indicator lights . . . . . . . . . . . . . .8
lever . . . . . . . . . . . . . . . . . . . . . .57
U
Used engine oil, disposal . . . . . .171VPage
Variable interval wipers . . . . . . . .58
Vehicle care . . . . . . . . . . . . . . . .216
Vehicle Identification Number
(VIN) . . . . . . . . . . . . . . . . . . . . .228
Vehicle Emission Control
Information(VECI) . . . . . . . . . .204
Vehicle loading . . . . . . . . . . . . .130
Ventilating your vehicle . . . . . .109
Viscosity (see Engine oil)
W
Warning chimes
headlamps on . . . . . . . . . . . . . .19
key in ignition . . . . . . . . . . . . . .19
safety belt . . . . . . . . . . . . . . . . .19
Warning lights (see Lights)
Washer fluid reservoir . . . .167, 168
Weight limits (GAWR, GVWR) .130
Wheels
cleaning . . . . . . . . . . . . . . . . . .218
inspection and maintenance . .191
Windows
one-touch down . . . . . . . . . . . .64
power windows, operating . . . .64
rear, defrosting . . . . . . . . . . . . .24
Windshield washer fluid and wipers
checking and adding fluid . . . .172
checking and replacing
wiper blades . . . . . . . . . . . . . .186
operation . . . . . . . . . . . . . . . . . .58
fluid, specification . . . . . . . . . .225
variable interval wipers . . . . . . .58
Wrecker towing . . . . . . . . . . . . .160
4MInden 24.6.99 15:41 Uhr Seite 247
