The Climate Control Systems
*
[IP00600(ALL)01/94]
Your vehicle has one of the following climate
control systems:
[IP00900(ALL)02/95]
q
Manual Heating and Air Conditioning System
[IP01000(ALL)04/95]
q
Electronic Automatic Temperature Control
(EATC) System
*
[IP01100(ALL)09/89]
If you are not sure which system your vehicle
has, see the diagrams on the following pages.
[IP03150(ALL)11/94]
Manual Heating and Air Conditioning
System
[IP03175(ALL)03/95]
one third page art:0000698-E
The knobs that control the manual heating and air
conditioning system
[IP03200(ALL)03/95]
Fan speed knob
[IP03250(ALL)03/95]
The fan speed knob controls the volume of air
circulated in the vehicle. There are four fan
speeds: LO, medium/low (first dot),
medium/high (second dot), and HI.
File:fcips.ex
Update:Wed Dec 20 09:32:19 1995

73
Warning Lights and
Gauges
%*
[LG00500(ALL)05/92]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster. Your vehicle has
one of the following clusters:
[LG00800(ALL)02/95]
q
Standard cluster
[LG00900(ALL)02/95]
q
Optional cluster
*
[LG01100(ALL)05/94]
If you are not sure which cluster your vehicle
has, check the diagrams on the following pages.
[LG02050(ALL)03/95]The Standard Cluster
[LG02075(ALL)02/95]
The following warning lights and gauges are on
the standard cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
File:fclgs.ex
Update:Tue Aug 8 11:08:13 1995

93
%*
[IP00500(ALL)01/95]
The Climate Control Systems
*
[IP00600(ALL)01/94]
Your vehicle has one of the following climate
control systems:
[IP00900(ALL)02/95]
q
Manual Heating and Air Conditioning System
[IP01000(ALL)04/95]
q
Electronic Automatic Temperature Control
(EATC) System
*
[IP01100(ALL)09/89]
If you are not sure which system your vehicle
has, see the diagrams on the following pages.
[IP03150(ALL)11/94]
Manual Heating and Air Conditioning
System
[IP03175(ALL)03/95]
one third page art:0000698-E
The knobs that control the manual heating and air
conditioning system
[IP03200(ALL)03/95]
Fan speed knob
[IP03250(ALL)03/95]
The fan speed knob controls the volume of air
circulated in the vehicle. There are four fan
speeds: LO, medium/low (first dot),
medium/high (second dot), and HI.
File:fcips.ex
Update:Wed Dec 20 09:32:19 1995

260
*
[SV04350(ALL)01/95]
NOTE: Read and understandPrecautions When
Servicing Your Vehicleat the beginning
of this chapter before opening the
hood.
%
*
[SV04500(ALL)04/95]
Engine Compartment
*
[SV04600(ALL)09/93]
Your vehicle has one of these types of engines:
[SV04700(ALL)08/95]
q
a 3.0L Vulcan engine
[SV04750(ALL)08/95]
q
a 3.0L Duratec engine
*
[SV04850(ALL)11/94]
The following pages show diagrams of each
engine type and where to find items that you
should regularly service.
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995

277
reservoir located in the engine compartment. To
locate the reservoir, see the diagram of your
vehicle's engine underEngine Type, in this
chapter.
*
[SV17650(ALL)08/95]
The coolant additives also protect the entire
cooling system from internal passageway
corrosion and these additives lubricate the water
pump. The coolant should be serviced as noted
in theMaintenance Schedule and Recordbooklet.
[SV17700(ALL)04/95]
one third page art:0000305-E
The engine coolant reservoir (3.0L Vulcan shown Ð 3.0L
Duratec similar)
[SV17750(ALL)04/95]
The coolant level in the reservoir should be
maintained within the cold fill range.
[SV17900(ALL)02/95]
There may be a low coolant warning light in the
instrument cluster which will light when the
coolant level is low.
%*
[SV18000(ALL)11/94]
Checking hoses
*
[SV18050(ALL)11/94]
Inspect all engine and heater system hoses and
hose connections for deterioration, leaks, and
loose hose clamps as specified in theMaintenance
Schedule and Recordbooklet. Repair or replace
with Motorcraft hoses or equivalent as necessary.
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995

291 %
*
[SV25100(ALL)02/95]
Tire Rotation
[SV25200(ALL)11/94]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them as indicated in the
Maintenance Schedule and Recordbooklet.
[SV25300(ALL)11/94]
Rotate the tires according to the following
diagram. Do not include the spare tire as part of
your rotation. If you notice that the tires wear
unevenly, have them checked.
[SV25410(ALL)11/94]
one third page art:0001369-A
Rotating the tires
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995

312 %
*
[SV35200(ALL)03/95]
Checking and Replacing Fuses
*
[SV35300(ALL)02/95]
If you need to check a fuse, follow these steps:
[SV35400(ALL)11/94]
1. Lift the handle of the fuse panel or power
distribution box to unlatch the cover.
[SV35600(ALL)11/94]
2. On the cover, find the fuse you want to
check. The diagram on the cover tells you
where to locate the fuse on the panel.
[SV35900(ALL)11/94]
3. Check the fuse to see if it is blown. To
remove the fuse, use the pulling tool
attached to the inside cover of the fuse
panel. Look through the clear side of the
fuse to see if the metal wire inside is
separated. If it is, the fuse should be
replaced.
*
[SV36000(ALL)11/94]
quarter page art:0030248-A
Fuse puller tool and fuse
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995
