WARNING LIGHTS AND CHIMES
Turn signal
Illuminates when the
left or right turn signal
or the hazard lights are
turned on. If one or
both of the indicators stay on continuously or flash
faster, check for a burned-out turn signal bulb. Refer
toExterior bulbsin theMaintenance and care
chapter.
High beams
Illuminates when the
high beam headlamps
are turned on.
Safety belt
Momentarily illuminates
when the ignition is
turned to the ON
position to remind you
to fasten your safety belts. For more information,
refer to theSeating and safety restraintschapter.
Door ajar
Illuminates when the
ignition is in the ON or
START position and
any door is open.
EFC H
FUEL DOOR>
SERVICE
ENGINE
SOON
THEFT102030405060
70
80
90
100
1202060100
140
180
P R N D 2 1MPH km/h
00
000
00000
P!
BRAKELOW
COOLANT
+ –
110CRUISE
RPMx1000
0 1234
5
6
7ABSUNLEADED FUEL ONLY
O/D
OFF
Instrumentation
6

Service engine soon
Your vehicle is
equipped with a
computer that monitors
the engine's emission
control system. This
system is commonly known as the On Board
Diagnostics System (OBD II). This OBD II system
protects the environment by ensuring that your
vehicle continues to meet government emission
standards. The OBD II system also assists the
service technician in properly servicing your vehicle.
TheService Engine Soonindicator light illuminates
when the ignition is first turned to the ON position
to check the bulb. If it comes on after the engine is
started, one of the engine's emission control systems
may be malfunctioning. The light may illuminate
without a driveability concern being noted. The
vehicle will usually be drivable and will not require
towing.
What you should do if the Service Engine Soon
light illuminates
Light turns on solid:
This means that the OBD II system has detected a
malfunction.
Temporary malfunctions may cause yourService
Engine Soonlight to illuminate. Examples are:
1. The vehicle has run out of fuel. (The engine may
misfire or run poorly.)
2. Poor fuel quality or water in the fuel.
3. The fuel cap may not have been properly installed
and securely tightened.
SERVICE
ENGINE
SOON
Instrumentation
7

3. Set the parking brake and ensure the gearshift is
securely latched in P.
4. Open the hood. Protect yourself from engine heat.
5. Locate and carefully
remove the engine oil
indicator (dipstick).
6. Wipe the indicator clean. Insert the indicator fully,
then remove it again.
²If the oil level isbetween the ADD and FULL
marks or between the MIN and MAX marks
(depending on application),the oil level is
acceptable.DO NOT ADD OIL.
²If the oil level is
below the ADD or
MIN mark, add
enough oil to raise
the level within the
ADD-FULL or within
the MIN-MAX range.
²Oil levels above the F in FULL or above the MAX
mark, may cause engine damage. Some oil must
be removed from the engine by a service
technician.
7. Put the indicator back in and ensure it is fully
seated.
ADD 1 QTFULL
MAX MIN
Maintenance and care
131

Severe winter climate
If you drive in extremely cold climates (less than
±36ÉC [±34ÉF]), it may be necessary to increase the
coolant concentration above 50%. Refer to the chart
on the coolant container to ensure the coolant
concentration in your vehicle is such that the
coolant will not freeze at the temperature level in
which you drive during winter months. Never
increase the engine coolant concentration above
60%. Leave a 50/50 mixture of engine coolant and
water in your vehicle year-round in non-extreme
climates.
CHECKING AND ADDING POWER STEERING
FLUID
Check the power
steering fluid. Refer to
the ªService Guideº for
the service interval
schedules. If adding
fluid is necessary, use
only MERCONtAT F.
1. Start the engine and let it run until it reaches
normal operating temperature (the engine coolant
temperature gauge indicator will be near the center
of the normal area between H and C).
2. While the engine idles, turn the steering wheel
left and right several times.
3. Turn the engine off.
Perform steps 4 and 5 following the procedure for
your engine.
Maintenance and care
138

If an overfill occurs,
excess fluid should be
removed by a qualified
technician.
An overfill condition of transmission fluid may
cause shift and/or engagement concerns and/or
possible damage.
BATTERY
Your vehicle is
equipped with a
Motorcraft
maintenance-free
battery which normally
does not require
additional water during
its life of service.
However, for severe usage or in high temperature
climates, check the battery electrolyte level. Refer to
the ªService Guideº for the service interval
schedules.
If the electrolyte level in the battery is low, you can
add plain tap water to the battery, as long as you do
not use hard water (water with a high mineral or
alkali content). If possible, however, try to only fill
the battery cells with distilled water. If the battery
needs water often, have the charging system
checked.
Keep the electrolyte level in each cell up to the
ªlevel indicatorº. Do not overfill the battery
cells.
For longer, trouble-free operation, keep the top of
the battery clean and dry. Also, make certain the
battery cables are always tightly fastened to the
battery terminals.
If you see any corrosion on the battery or terminals,
remove the cables from the terminals and clean with
a wire brush. You can neutralize the acid with a
solution of baking soda and water. Reinstall the
DON’T ADD IF IN CROSSHATCH AREA--CHECH WHEN HOT-IDLING
Maintenance and care
142

Fuel Filler Cap
Your fuel tank filler cap has an indexed design with
a one-eighth turn on/off feature.
When fueling your vehicle:
1. Turn the engine off.
2. Carefully turn the filler cap counterclockwise 1/8
of a turn until it stops.
3. Pull to remove the cap from the fuel filler pipe.
4. To install the cap, align the tabs on the cap with
the notches on the filler pipe.
5. Turn the filler cap clockwise 1/8 of a turn until it
stops.
If the ªService Engine Soon/Check Engine ª indicator
comes on and stays on when you start the engine,
the fuel filler cap may not be properly installed.
Turn off the engine, remove the fuel filler cap and
reinstall it being careful to align the cap properly.
If you must replace the fuel filler cap, replace
it with an authorized Motorcraft part. The
customer warranty may be void for any damage
to the fuel tank or fuel system if an authorized
Motorcraft fuel filler cap is not used.
The fuel system may be under pressure. If
the fuel filler cap is venting vapor or if you
hear a hissing sound, wait until it stops before
completely removing the fuel filler cap. Otherwise,
fuel may spray out and injure you or others.
If you do not use the proper fuel filler cap,
the pressure in the fuel tank can damage
the fuel system or cause it to work improperly in a
collision.
Maintenance and care
155

Air bag supplemental
restraint system ........ 66
and child
safety seats ............. 69
description .............. 67
disposal .................... 72
indicator light ......... 72
passenger air bag ... 70
Air conditioning
automatic temperature
control
system . 21,22,23,24,26
Anti-theft system ...... 47
arming the system .. 47
Automatic transaxle . 93
driving
with ........... 96,97,98,99
Brakes ........................ 89
anti-lock ................... 89
anti-lock brake system
(ABS) warning
light .......................... 90
fluid, checking and
adding .................... 133
shift interlock .......... 93
Break-in period ........... 3
Cargo cover .......... 41,42
Cargo net ................... 41
Cellular telephone
(see your Cellular
Phone Guide) ............ 39
Child safety seats
attaching with tether
straps ....................... 78
in rear seat ......... 76,78
tether anchorage
hardware ................. 79
Cleaning your
vehicle ...................... 167
built-in child
seat ..................... 80,83engine
compartment ......... 168
exterior lamps ....... 170
plastic parts .......... 170
washing .................. 167
waxing ................... 168
wheels .................... 168
wiper blades .......... 170
Console ...................... 38
Controls
power seat ............... 55
Coolant ............. 137,138
checking and
adding .................... 135
refill capacities ...... 137
Defrost
rear window ............ 17
Doors
central unlocking 36,37
Emission control
system ...................... 158
Engine
coolant ................... 134
idle speed control . 142
service points . 129,130
starting after a
collision ................. 108
Engine block heater . 87
Engine oil
checking and
adding .................... 132
dipstick .................. 130
specifications . 130,132
Exhaust fumes .......... 87
Floor mats ................. 39
Fuel
choosing the
right fuel ................ 156
detergent in fuel ... 157
filling your vehicle
with fuel ......... 153,155
quality .................... 156
Index
182

running out of
fuel ......................... 157
safety information
relating to automotive
fuels ....................... 153
Fuses ................. 109,110
Hazard flashers ....... 108
Head restraints ......... 54
Headlamps
high beam ............... 15
Heating ...................... 17
heating and air
conditioning
system ........... 17,18,20
Hood ........................ 128
Ignition ..................... 177
Inspection/maintenance
(I/M) testing ............ 159
Instrument panel
cleaning ................. 170
Keyless entry system
autolock .............. 51,52
keypad ..................... 49
locking and unlocking
doors ........................ 51
programming entry
code ......................... 50
Keys
key in ignition chime 11
positions of the
ignition .................... 28
Lamps ...................... 160
autolamp system ..... 16
daytime running
light .......................... 15
headlamps ............... 15
headlamps, flash to
pass .......................... 16
instrument panel,
dimming ................... 16
interior lamps ....... 164replacing
bulbs ............... 161,163
Lane change indicator
(see Turn signal) ...... 32
Liftgate ...................... 44
remote release ........ 40
Lights, warning and
indicator
air bag ...................... 11
anti-lock brakes
(ABS) ........................ 9
anti-theft ................... 9
brake ........................ 10
charging system ...... 10
cruise indicator ....... 10
door ajar .................... 6
low coolant ................ 8
low fuel ...................... 8
oil pressure ............. 10
overdrive off .............. 9
safety belt ................. 6
service engine soon .. 7
speed control .......... 31
turn signal
indicator .................... 6
Locks .......................... 53
childproof ................ 38
Luggage rack ........... 107
Lumbar support,
seats ...................... 55,56
Mirrors
heated ...................... 38
side view mirrors
(power) ................... 37
Moon roof .................. 34
Motorcraft parts ...... 158
Octane rating .......... 156
Odometer ................... 13
Overdrive .............. 94,95
Panic alarm feature,
remote entry
system ........................ 44
Index
183
