mirror Mercury Villager 1997 Owner's Manuals

74
*
[CF12100(ALL)01/96]
Liftgate Window Features
%*
[CF12200(ALL)01/96]
Rear Window Defogger (If equipped)
*
[CF12300(ALL)01/96]
The defogger for the rear liftgate window clears frost, fog, or
thin ice from both the inside and outside of the rear window.
The defogger operates with the ignition in the ON position.
[CF12400(ALL)01/96]
If your vehicle is equipped with heated exterior mirrors, they
activate when the rear window defogger is switched on.
*
[CF12500(ALL)03/96]
The control switch is located on the instrument panel to the
right of the steering column.
[CF12600(ALL)03/96]
13-1/2 pica art:0040073-E
Rear window defogger switch location
*
[CF12700(ALL)05/96]
Before using the defroster, clear away any snow that is on the
rear window and outside rearview mirrors. With the engine
running, push the defroster button.
*
[CF12800(ALL)01/96]
After approximately 10 minutes, the defroster will turn off. If
the window or mirrors are still not clear, turn the defroster on
again.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

110
[CF34500(ALL)01/96]
10-1/2 pica
art:0040123-B
Power quarter window switch
%*
[CF34600(ALL)03/96]
Mirrors
*
[CF34700(ALL)01/96]
RWARNING
Make sure you can see clearly through the rearview
mirror at all times. Do not block your vision. If you
cannot see through the mirror, it could result in a
collision, injuring yourself and others.
%*
[CF34800(ALL)01/96]
Side View Mirrors
*
[CF34900(ALL)01/96]
Close your door and adjust the driver's seat to the most
comfortable position before you adjust the side view mirrors.
[CF35000(ALL)05/96]
If you have manually adjusting side view mirrors, you can
adjust them in any direction by moving the mirror. The mirror
heads can be folded rearward to prevent damage when using an
automatic car wash.
*
[CF35100(ALL)01/96]
NOTE: Be careful. The convex side view mirror on the right
makes objects appear smaller and farther away than
they actually are. Use the inside rearview mirror (or
look behind you) to determine the actual size and
distance of objects that appear in the convex mirror.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

Controls and Features
111
%*
[CF35200(ALL)01/96]
Dual Electric Remote Controlled Mirrors (If equipped)
[CF35300(ALL)01/96]
If you have power side view mirrors, you can adjust them in
any direction by using the mirror controls on the instrument
panel. This switch operates with the ignition in ON or ACC.
[CF35400(ALL)01/96]
The mirror control switch is on the instrument panel to the left
of the steering wheel.
*
[CF35500(ALL)05/96]
To adjust the remote controlled side mirrors:
[CF35600(ALL)05/96]1.
Select the right or left mirror by moving the selector switch
to R or L.
*
[CF35700(ALL)01/96]2.
Move the control knob in the direction you want to move
the mirror.
[CF35800(ALL)01/96]3.
Return the selector switch to the middle position to keep the
mirror in place.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

112
[CF35900(ALL)01/96]
17-1/2 pica
art:0040110-D
Dual electric remote controlled mirrors switch
[CF36000(ALL)05/96]
Heated mirror feature (If equipped)
[CF36100(ALL)01/96]
Both power mirrors are heated whenever the rear window
defroster is turned on. Do not remove ice from the mirrors with
a scraper or you could damage them.
%*
[CF50000(ALL)01/96]
Cargo Net (If equipped)
*
[CF50100(ALL)01/96]
The cargo net is designed to hold your cargo upright between
the third row bench seat and the liftgate to prevent it from
moving around the cargo area.
*
[CF50200(ALL)01/96]
To install the cargo net:
*
[CF50300(ALL)01/96]
Attach the loops on the four corners of the net to the four
retainers on the cargo area rear quarter panels. Pull on the net
to be sure that it is fastened securely.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

389
Index
Clock.......................... 40
Cold engine starting.................. 212
Combination lap and shoulder belts.........131, 133
Controls, mirrors................... 110
Convenience kit in cargo area.............. 257
Coolant (see Engine coolant)
checking and adding................ 289
drain and flush................... 293
preparing for storage................ 338
specifications.................... 343
temperature gauge................ 18,23
warnings...................... 289
Cooling fan...................... 278
Customer Assistance Centre, Ford of Canada....... 356
D
Daytime running light system.............. 77
Defrost
rear window..................... 74
windshield...................... 56
Dipstick
automatic transaxle fluid............... 295
engine oil..................... 283
power steering fluid................. 293
Disabled vehicle (see Towing).............. 274
Dispute Settlement Board................ 352
Doors
door ajar warning light................ 15
lubricant specifications................ 343
Driving under special conditions
heavy load..................... 229
towing a trailer................... 230
File:vxixn.ex
Update:Fri Jun 14 07:38:49 1996

396
Lights, warning and indicator (continued)
charging system................... 13
check engine..................... 12
door ajar....................... 15
engine oil pressure.................. 14
hazard warning light............... 76,243
high beam...................... 17
low fuel....................... 16
lowoil........................ 14
low washer fluid................... 17
oil pressure...................... 14
rear ABS....................... 10
safety belt...................... 11
service engine soon.................. 12
turn signal indicator.................. 87
Load limits
GAWR....................... 229
GVWR....................... 229
trailer towing.................... 235
Lubricant specifications................ 343
Luggage rack..................... 241
Lug nuts
anti-theft...................... 263
tightening sequence...............260, 267
M
Maintenance (see Servicing).............. 277
Master cylinder, brakes................ 285
Message center, low washer fluid............. 17
Methanol in fuel................... 312
Mileage, calculating fuel economy............ 314
Mirrors
dual electric remote control............. 111
rearview...................... 110
side view mirrors.................. 110
File:vxixn.ex
Update:Fri Jun 14 07:38:49 1996

397
Index
Mirrors (continued)
side view mirrors (manual).............. 110
side view mirrors (power).............. 111
Motorcraft parts.................... 341
O
Octane rating..................... 311
Odometer
description...................... 20
trip odometer..................... 20
Oil filter....................... 284
Oil (see Engine oil).................. 281
Oil viscosity...................... 281
On-board diagnostic (OBD II) system.......... 318
Overdrive....................... 226
Overseas offices.................... 357
P
Parking brake
operation...................... 221
warning light..................... 9
Parts (see Motorcraft Parts)............... 341
PCV valve, specifications................ 341
Power door locks................... 102
Power features
door locks..................... 102
mirrors....................... 110
windows...................... 107
Power steering
dipstick...................... 293
driving with power steering............. 223
fluid, checking and adding.............. 293
fluid, specifications................. 343
servicing...................... 223
Prop rod, hood.................... 279
File:vxixn.ex
Update:Fri Jun 14 07:38:49 1996

399
Index
Safety restraints (continued)
replacement..................... 146
warning light and chime................ 11
Safety seats for children
and air bags..................138, 156
attaching with tether straps............. 163
automatic locking mode (retractor)........138, 156
in front seat.................... 156
in rear outboard.................. 156
in rear seat..................... 156
tether anchorage hardware.............. 163
Seat belts (see Safety restraints)............. 131
Seats
child safety seats.................. 156
cleaning upholstery................. 335
head restraints................... 123
Serial number (VIN).................. 356
Service concerns.................... 350
Servicing your vehicle
precautions when servicing.............. 278
servicing when you tow............... 274
Shift positions (see Gearshift).............. 224
Shoulder and lap belts (see Safety restraints).....131, 133
Shoulder belts (see Safety restraints).........133, 139
Side mirrors
adjusting...................... 110
Snow tires and chains................. 307
Spare tire
changing the tire................256, 260
conventional spare................. 256
finding the spare.................. 257
removing the spare tire............... 257
storing the flat tire................. 257
temporary spare................... 256
File:vxixn.ex
Update:Fri Jun 14 07:38:49 1996
