Electronic Sound Systems
47
[AS32400(ALL)06/95]
Rear Seat Radio Control Operation
[AS32410(ALL)06/95]
13-1/2 pica
art:0040313-A
Rear seat radio controls
*
[AS32420(ALL)06/95]
How to turn the rear seat radio controls on and off
[AS32440(ALL)06/95]
Press memory preset buttons ª3º and ª5º simultaneously on the
face of your radio to turn the rear seat radio controls on. A
headphones symbol (j) will appear in the display when the
rear seat controls are on. Press ª3º and ª5º simultaneously
again to turn rear seat radio controls off.
*
[AS32460(ALL)03/96]
How to adjust the volume
[AS32480(ALL)06/95]
Press the right (R) side of the ªVOLUMEº rocker switch to
increase volume, and push the left (s) side to decrease the
volume of the rear speakers.
[AS32500(ALL)09/95]
NOTE: Rear seat control volume can be set no higher than
current radio setting.
File:04vxasn.ex
Update:Thu May 30 09:46:22 1996

48
[AS32520(ALL)06/95]
Using the ªPROGRAM ADVANCEº button
[AS32540(ALL)06/95]
This button has different functions depending on the audio
source. In radio mode, pressing this button will cycle through
the memory presets for the given frequency band (AM, FM1,
FM2). In the cassette mode, pressing this button will change
tape sides. During the CD operation, this button will cycle
through the discs (one button push, one disc advance).
[AS32560(ALL)06/95]
Using the ªSOURCE SELECTº button
[AS32580(ALL)05/96]
This button will cycle through all modes. The cycle order is as
follows: AM, FM1, FM2, tape, CD (if equipped).
*
[AS32600(ALL)06/95]
How to turn the speakers on and off
[AS32620(ALL)06/95]
When the rear seat controls are on, push the ªSPKRS, ON-OFFº
button to turn all speakers off. Push again to turn all speakers
on.
*
[AS32640(ALL)06/95]
Using headphones with the rear seat controls
[AS32660(ALL)03/96]
Two 3.5 mm headphone jacks have been provided on the rear
seat controls. Plug headphones into the provided jack(s) to
operate headphones. Note that the headphones can be used only
when the speakers are off.
[AS32680(ALL)06/95]
Using the ªSEEKº button
[AS32700(ALL)06/95]
This button has different functions for each source (mode). In
radio mode, pressing ªSEEKº proceeds to the previous or next
station. In cassette mode, this button is an Automatic Music
Search (AMS), moving to the next or previous selection on the
tape. In CD mode, this button moves to the beginning of the
next or previous track.
File:04vxasn.ex
Update:Thu May 30 09:46:22 1996
