roof Mercury Villager 1998 Owner's Manuals

Using This Guide
To fully appreciate all of the features and options of your new
vehicle, we recommend that you thoroughly read through this
guide now and refer to it when you have specific needs or
questions. For your own safety and the safety of your passengers,
it is important that you completely understandallperformance
and care proceduresbeforeoperating this vehicle. For example,
without reading further, would you know:
mWhat to do if you get a flat tire? (Refer toFlat tirein the
Index)
mWhat it means if the O/D OFF light is illuminated on your
instrument panel? (Refer toOverdrivein the Index)
mHow to engage the childproof safety lock on the sliding door?
(Refer toChildproof locksin the Index)
mThat your automatic transaxle will not shift out of PARK (P)
until you apply the brake pedal? (Refer toGearshiftin the
Index)
Ford's Commitment to You
At Ford Motor Company, excellence is the continuous
commitment to achieve the best result possible. It is dedication to
learning what you want, determination to develop the right
concept, and execution of that concept with care, precision, and
attention to detail. In short, excellence means being the standard by
which others are judged.
Our Guiding Principles
mQuality comes first.For your satisfaction, the quality of our
products and services must be our number one priority.
mYou are the focus of everything we do.Our work must be
done with you in mind, providing better products and
services than our competition.
Introduction
1

Interior Lamps
The front dome lamp is located overhead between the driver and
front passenger seats. However, if your vehicle is equipped
with a power sunroof, the dome lamp is located behind the driver's
seat.
The rear dome lamp is located overhead near the rear seating
positions.
Either dome lamp will stay illuminated if the switch is pushed
to the ON position. The dome lamps will stay off if the switch is
pushed to the OFF position. When the switch is positioned to
the door/middle position, the dome lamps will come on when
either of the front doors or the sliding door is opened. The
front dome lamp, footwell lamps, and the sliding door step lamp
have a time delay feature and will gradually dim within about
15 seconds.
The rear dome lamp also illuminates when the liftgate is opened
and goes off when it is closed. However, the rear dome lamp
will not remain lit in the ON position unless the ignition switch
is in the ON position. This feature is intended to help avoid
a run-down battery which can occur when a light is left on
unintentionally.
The dome lamp switch positions
82

Overhead Map Lamps (If equipped)
The power sunroof overhead console also contains the overhead
map lamps.
You can turn the map lamps on and off by pressing the
switches next to the lamps.
Radio
For information about the radio in your vehicle, refer to the
Electronic Sound Systemschapter.
Clock Controls on Electronic Radios
The electronic radios have a built-in clock. For complete
operating instructions, refer to theElectronic Sound Systems
chapter.
Radio Antenna
The fixed radio antenna is mounted on the front fender on the
passenger side of the vehicle.
The overhead map lamps
84

When the CRUISE indicator blinks, press the speed control OFF
switch and have the system checked by your Ford or
Lincoln-Mercury dealer.
The CRUISE indicator light may blink if the CRUISE CONT. ON
switch is pressed while pushing the RES/ACCEL,
COAST/SET, or CANCEL buttons located on the left side of the
steering wheel.
Power Sunroof (If equipped)
The power sunroof controls are found in the overhead console.
The power sunroof operates with the ignition in the ON position.
To open the sunroof, press and hold the OPEN side of the
switch. Release the switch when the sunroof reaches the desired
position. To close the sunroof, press the CLOSE side of the switch.
When the sunroof panel is closed, you can raise the sunroof to the
vent position by pressing the UP side of the switch. To lower the
moonroof from the vent position, press the DOWN side of the switch.
WARNING
Do not let children play with the moon roof. They may
seriously hurt themselves.
Remove any snow, water or other foreign matter from the
sunroof before you open it.
Power sunroof controls
96

Sliding Shade
The sunroof has a sliding shade you can manually open or close
to block the sun when the glass panel is shut. To close the
sliding shade, pull the shade toward the front of the vehicle. The
shade automatically opens when the sunroof is opened.
Doors
For information on the liftgate refer to theLiftgatesection later in
this chapter.
Exterior Locks
To unlock the door with the key, place the key in the door lock
cylinder and turn it toward the rear of the vehicle. To unlock all the
doors, turn the key toward the rear of the vehicle a second
time within 2-3 seconds (if equipped). To lock the door with the
key, turn it toward the front of the vehicle. Return the key to the
neutral position (straight up in the lock cylinder) to remove it.
The exterior door lock Ð passenger side doors shown
Controls and Features
97

Automatic Door Lock
If your vehicle is equipped with the optional power door locks,
locking the driver door with the key or with the manual rocker
switch will also lock all other doors. However, when the driver
door is unlocked, with the key or with the manual rocker switch,
other doors remain locked. The optional keyless entry system
will also lock and unlock your doors.
Anti-Lockout
Your vehicle is equipped with an anti-lockout feature which
prevents the driver side door from being locked while the key is
in the ignition. To lock the driver side door, remove the key
from the ignition and then use either the manual rocker switch or
the door lock cylinder.
Accessory Delay (If equipped)
Accessory Delay is a feature that allows vehicles equipped with
power windows and the power sunroof to operate all power
windows and the power sunroof for 15 minutes after the ignition
is turned to OFF or until the driver or front passenger door is
opened (after ignition is turned to OFF).
Sliding Door
The sliding door allows rear seat passengers to enter and exit
easily.
To lock the sliding door, push the right side of the rocker switch.
To unlock the sliding door, push the left side of the rocker
switch.
To open the sliding door from inside or outside of the vehicle,
pull the handle toward the rear of the vehicle. The door will stay
open if you slide it all the way back until the catch at the
bottom of the door engages.
98

Childproof Lock for the Sliding Door
Your vehicle has a childproof lock for the sliding door. If you set
the childproof lock, the sliding door cannot be opened from
inside the vehicle.
Childproof lock location
100

The childproof lock:
mprevents children inside the vehicle from opening the door.
mallows the door to be opened from the outside (if the door is
unlocked).
To set the childproof lock:
1. Open the sliding door.
2. Find the childproof lock knob above the label.
3. Pull the knob out.
To release the childproof lock:
1. Open the sliding door from the outside.
2. Push the childproof lock knob in.
Power Door Locks (If equipped)
The power door lock control switches are located in the panels of
the front doors. They control the locks on both front doors, the
sliding door and the liftgate.
Controls and Features
101

Remove the two batteries by snapping open the lid of the remote
transmitter. The transmitter can be snapped apart by twisting
a thin coin between the two halves of the transmitter. Replace the
batteries with new ones as shown in the above illustration.
Close the lid securely. Press both the LOCK and the UNLOCK
button two or three times to test the remote transmitter operation.
If the batteries are removed for any reason other than
replacement, repeat the steps inReplacing the batteriesto test your
remote transmitter(s).
mAn improperly disposed battery can hurt the environment.
Always confirm local regulations for battery disposal.
mThe remote transmitter is waterproof; however, if it does get
wet, immediately wipe it completely dry.
mThe operational range of the remote transmitter extends to
approximately 49 feet (15 meters) from the vehicle. This
range may vary with conditions.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
Replacement/Additional Transmitters
In the event a transmitter is lost or an additional remote
transmitter needs to be set, you must change the ID code. Follow
the steps below to change the ID code of your system, or
return the remaining transmitter(s) to your dealer for
reprogramming of your remote entry system. This is necessary to
prevent unauthorized use of the lost transmitter.
Controls and Features
11 5

Four Season Roof Rack (If equipped)
Always load your luggage as far back as it will safely go on the
four season roof rack. Do not load more than 100 lb. (45 kg).
Be careful that your vehicle does not exceed the Gross Vehicle
Weight Rating (GVWR) or its Gross Axle Weight Rating (GAWR
front and rear). The GVWR and GAWR are located on the
Safety Compliance Certification Label (located on the driver's
door pillar).
The front and rear cross-bars can be adjusted forward and
backward. Place your luggage between the bars, adjust the bars,
and secure the luggage with rope to the bars. There are also
adjustable loops on the side bars for the rope attachment.
WARNING
Be sure that items on the roof rack are securely fastened.
The four season roof rack
Driving
239
