MINI COOPER 2002 Service Repair Manual Electrical Wiring Diagrams ELE-41
Automatic transmission (CVT)
Transmission speed sensor
(pagel of 1)
87 F04
15A
X8687
«
1.0
RT/WS X6000
0.5
SW
3 X 8 5 1 6 0.5
BR/OR
73 X6000 A6000
Digital motor
