Downloaded from www.Manualslib.com manuals search engine CHASSIS ELECTRICAL - Radio-and Tape Player54-I 57
Continued from previous Page
I
Is changeoverto normal operation made by placing POWER buttonto ON position while pressing EJECT button?
YesFaulty set
tIs power supply cut off automatically to return to no display state
after three-minute operation?Faulty set
Does manufacturing numberof set agree with identification number
on card?
YesError in attaching card (For set manufacturing number identificationlocation, refer to
F!54-183)
Yes
Is a beep heard and does radio operate when identification number - Normal (Error in first and second setting)indicated on card is reset and PROG button is placed to ON
position?
No
Is “OFF” displayed after three-minute beeping togetherwith displayof “3 Err”?Faulty set
Yes
t
0In this state, only POWER button operation is accepted (“OFF’is displayed) and no other button opera-
tion can be made effectively.l
In the “OFF” state, continuation of the BAlT, ACC line ON state for more than one hour will allow identi-
fication number checking operation again and placing the POWER button to ON position will display
“code” and wait for input.
1 TSB Revision

Downloaded from www.Manualslib.com manuals search engine 54-178CHASSIS ELECTRICAL - Radio and TaDe Plaver
D. CD PLAYER
D-lCD will not be accepted.
Does the shutter open when a CD is inserted? l l
YesTake out the CD.
1 Yes
tThough CD is completely inserted once, “e
CD is rejected? l 3No-l
Yes
tCheck CD.l Is the labeled side faced downward?
l Is the recorded face of the CD dirty?
l Does dew exit on the recorded face of the CD?- Yes- Insert the CD correctly or check to see if the
CD is defective.
No
l 1‘2
‘3
tReplace CD.If the CD is already loaded, doesn’t the shutter open to allow
insertion when another CD is inserted?
If the key switch is not at ACC or ON, the CD stops at depth
of 15 mm below the panel surface even when it is inserted, andit will be rejected when pushed farther?
Even though the CD is loaded, E (error) is sometimes displayedwith the CD rejected because of vibration/ shock or dew on the
CD face or optical lens.
TSB Revision

Downloaded from www.Manualslib.com manuals search engine 54-184CHASSIS ELECTRICAL - Radio and Tape Plaver
TYPE 1
POWER button Disp’ayPROG button
TYPE 2
DisplayPROG button
Memoryselect
button
POWER button
TYPE 3
PROG button
ZHllA004
Memory,1r select
POW’ER buttonIDisplayH’llAlM
section00002402
Typical security code “5283”
ZHllFOOl
2.Return power supply for the radio and player to the normal
state.3. Turn the ignition key to the “ACC” position.
4. Press the POWER button, and “code” will be displayed
on the display.
5.Press No.1 through No.4 memory select buttons and setthe
4-digit security code indicated on the card.
Every time each digit key is pressed, the number changes
as follows:
40 +l +2--e 9+0 **-
6.Press the PROG button. After a beep is heard, the radioand tape player will be in the operating state.
7. If the input security code does not agree with that in
memory, “1 Err” is displayed on the display. In a few se-conds, it will change to “code”. So, repeat steps 4 and
5.
NOTE
(1) The security code can be set three times at the most.
(2) The second error is displayed as “2 Err”. If the third
error is made, “3 Err” is displayed and then it changes
to “OFF”.
(3) When setting is attempted four or more times, keeping
the ignition key in the “ACC” or “ON” position for about
one hour will automatically erase the “OFF” display.
\
,ij~
I
I
I
\,
LJ
1 TSB Revision

Downloaded from www.Manualslib.com manuals search engine CHASSIS ELECTRICAL - Radio and Tape Player54-185After the erasing, therefore, repeat step 3 and up.
If the ignition key is turned to the “OFF” position during
one-hour period of keeping it in “ACC” or “ON” position,
the “OFF” display will be erased.With the ignition key placed in the “ACC” position
again, press the POWER button, and the “OFF” display
will be resumed. Therefore, keep this state for another
one hour or so.TSB Revision
