52A-1
GROUP 52A
INTERIOR
CONTENTS
GENERAL DESCRIPTION. . . . . . . . .52A-3
SEAT BELT DIAGNOSIS. . . . . . . . . .52A-3
SPECIAL TOOLS . . . . . . . . . . . . . . . .52A-3
INSTRUMENT PANEL ASSEMBLY*.52A-4
REMOVAL AND INSTALLATION . . . . . . . . 52A-4
DISASSEMBLY AND ASSEMBLY . . . . . . . 52A-9
FLOOR CONSOLE ASSEMBLY . . . .52A-10
REMOVAL AND INSTALLATION . . . . . . . . 52A-10
TRIMS . . . . . . . . . . . . . . . . . . . . . . . . .52A-11
REMOVAL AND INSTALLATION . . . . . . . . 52A-11
DOOR TRIM . . . . . . . . . . . . . . . . . . . .52A-14
REMOVAL AND INSTALLATION . . . . . . . . 52A-14
DISASSEMBLY AND ASSEMBLY . . . . . . . 52A-17
HEADLINING . . . . . . . . . . . . . . . . . . .52A-19
REMOVAL AND INSTALLATION . . . . . . . . 52A-19
INSIDE REAR VIEW MIRROR . . . . . .52A-20
Continued on next page
WARNINGS REGARDING SERVICING OF SUPPLEMENTAL RESTRAINT SYSTEM (SRS) EQUIPPED VEHICLES

INSIDE REAR VIEW MIRROR
INTERIOR52A-20
REMOVAL SERVICE POINT
.
<> HEADLINING ASSEMBLY REMOVAL
Remove the front passenger's door check (body side mounting
bolt), open the front passenger's door and remove the headlin-
ing assembly. (Refer to GROUP 42, Door Assembly P.42-37.)
INSIDE REAR VIEW MIRRORM1521002600248
REMOVAL SERVICE POINT
.
INSIDE REAR VIEW MIRROR REMOVAL
Insert a narrow flat-tip screwdriver into the slit in the inside rear
view mirror bracket, keep the spring pushed in and remove the
inside rear view mirror in the direction of the arrow in the illus-
tration.
NOTE: While the spring is pushed in, the connection between
the spring and the pawl of the button is released.
13. CENTER HEADLINING PAD
14. REAR HEADLINING PAD
15. ROOF INSIDE ASSIST GRIP
BRACKET ROOF INSIDE ASSIST GRIP>
16. ASSIST GRIP BRACKETREMOVAL STEPS (Continued)

WINDOW GLASS
BODY42-15
WINDSHIELD
REMOVAL AND INSTALLATIONM1422001000324
Pre-removal and Post-installation Operation
Front Deck Garnish Removal and Installation (Refer to
GROUP 51, Windshield Wiper and Washer P.51-17).
Roof Drip Molding Removal and Installation (Refer to
GROUP 51, Garnish and Molding P.51-8).
Front Pillar Trim Removal and Installation (Refer to
GROUP 52A, Trims P.52A-11).
Instrument Panel Front End Garnish Removal and Instal-
lation (Refer to GROUP 52A, Instrument Panel Assembly
P.52A-4).
Inside Rear View Mirror Removal and Installation (Refer
to GROUP 52A, Inside Rear View Mirror P.52A-20).
