Denotes connector No.
The same connector No. is used throughout the circuit diagrams to facilitate connector location searches.
The first alphabetical symbol indicates the location site of the connector and a number that follows is the unique number.
Numbers are usually assigned to parts in clockwise order on the diagram.
Example: A-19
Number specific to connector (serial number)
Connector location site symbol
A: ENGINE COMPARTMENT
B: ENGINE AND TRANSAXLE
C: DASH PANEL
D: FLOOR AND ROOF
D: FLOOR AND WINDSHIELD APERTURE
E: DOOR
F: LUGGAGE COMPARTMENT
Denotes ground point.
Same ground number is used throughout circuit
diagrams to facilitate search of ground point.
Refer to GROUP 70 SINGLE PART INSTALLATION
POSITION - GROUND MOUNTING LOCATIONS
for details of ground points.
Denotes the color of the corrugated
tube (If not specified, it is black.)
R: Red
Y: Yellow
The number of connector pins and the connector color
(except milk white)* are shown for ease of retrieval.
Example: (2-B)
Connector color
(milk white if no color is indicated)
Number of connector pins
*: Typical connector colors
B: Black BR: Brown
Y: Yellow V: Violet
L: Blue O: Orange
G: Green GR: Gray
R: Red NONE: Milk white
A-15 (2) FOG LIGHT (RH)
A-16 (2-GR) HORN (LOW)
A-17 (2-B) HEADLIGHT (RH)
A-18 (2-B) WINDSHIELD WASHER MOTOR
A-19 (2-GR) DUAL PRESSURE SWITCH
Indicates the device to which the
connector is connected.
The mark shows the
standard mounting position
of wiring harness.
AE
A-17
A-16
A-15 A-18 A-19
YDenotes a section covered by a
corrugated tube.
FRONT
WIRING
HARNESS
(RH)
Denotes harness name.

AC106118
Connector
symbol
-81
thru
-98
C
AB
STEERING COLUMN
C-88
C-97
C-83
C-81 C-84 C-85 C-86 C-87
C-98C-82 C-96
CLOCK
SPRING

AC003587
Indicates a splice point number.
The splice point numbers are identical to those in "CIRCUIT DIAGRAMS," making them easy to use.
In addition, the splice point numbers are usually numbered clockwise.
Example: S 013
Sequential number
Prefix meaning splice point
S013
S014
AB
S015 S016
S033
S032
S031

AC106581
Auto-cruise Control Switch System Circuit
AB
AC001451
CONNECTOR: C-20
ABAC106551AB
CONNECTORS: C-82, C-84, C-96
C-96
C-84
C-82
CLOCK SPRING

1 2 3
ACX02255 AE
AUTO-CRUISE
CONTROL SWITCH
CONNECTOR: C-82
AC106551
AC
CONNECTORS: C-82
CLOCK SPRING

AC106551AD
CONNECTORS: C-84
CLOCK SPRING
AC106551
AE
CONNECTORS: C-96
CLOCK SPRING

123
ACX01913 AE
C-82 CONNECTOR
HARNESS SIDE VIEW
AC106551AC
CONNECTORS: C-82
CLOCK SPRING

AC106551AB
CONNECTORS: C-82, C-84, C-96
C-96
C-84
C-82
CLOCK SPRING
AC001451
CONNECTOR: C-20
AB
AC106551AC
CONNECTORS: C-82
CLOCK SPRING
