Features and controls
3-23
3
After completion of the steps above, the theft-alarm indicator
(A) will illuminate for approximately 20 seconds and keeps
blinking on and off, indicating that the system is armed.
NOTE
The system will be armed even if the engine hood is open,
but when the system is set, be sure that the engine hood is
locked.

The system will be disarmed if, while the theft-alarm indi-
cator (located in the front center of the dashboard) is illu-
minated, all doors and the rear hatch or trunk lid are
unlocked by remote control transmitter.

The system will be disarmed if, while the theft-alarm indi-
cator is illuminated, the ignition key is turned to the “ON”
or “ACC”.

The system will not be armed if a door is not completely
closed. If this happens, rearm the system as described
above.

The trunk lid can only be opened by remote control trans-
mitter without triggering or disarming the system even
after the system has been armed. When it is closed, the
system will be rearmed.

The driver should not arm the system until first confirm-
ing that all passengers have left the vehicle. If the driver
arms the system with passenger(s) in the vehicle, the
alarm may be activated when the passenger(s) open the
door.
BK0115900US.book 23 ページ ２００９年１０月２７日　火曜日　午後１２時１分

3-24 Features and controls
3
Alarm stage
N00510400060
The alarm will be activated if any of the following occur while
the vehicle is parked and the system is armed.
1. One of the doors and the rear hatch or trunk lid is opened
without the remote control transmitter.
2. The engine hood is opened from the outside.Type of alarmWhen the alarm is activated:
1. The headlights blink on and off for 3 minutes.
After 3 minutes the headlights automatically shut off.2. The horn will sound intermittently for 3 minutes.
NOTE
The alarm will continue to operate for 3 minutes. At the
end of that period, the alarm will automatically shut off to
save battery power. The system will then be rearmed until
the proper disarming step is taken.Alarm deactivationThe alarm can be deactivated in the following ways.

By using the remote control transmitter to lock or unlock
the door, the rear hatch or trunk lid.

Turn the ignition key to the “ON” position.Horn sounds!
Headlights blink on and off!
BK0115900US.book 24 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Features and controls
3-25
3
Disarmed stage
N00510500061
The system will be disarmed when either of the following steps
are taken:
1. All doors and the rear hatch or trunk lid are unlocked by
the remote control transmitter.
2. The ignition key is turned to the “ACC” or “ON” position.
3. If the UNLOCK button is pressed when all doors and the
rear hatch or trunk lid are closed and no door is opened
within approximately 30 seconds, re-arming will automat-
ically occur.NOTE
Once the system has been disarmed, it cannot be rearmed
except by repeating the arming procedure.
Testing the theft-alarm system
N00510600059
Use the following procedure to test the system:
1. Lower the driver’s window.
2. Arm the system as explained in “Armed stage”.
3. Make sure that the theft-alarm indicator comes on and
flash in approximately 20 seconds.
4. Wait a few seconds and then unlock the driver’s side door
by using the inside door lock knob and opening the door.
5. Check to be sure that the horn sounds intermittently and
the headlights blink on and off when the door is opened.
6. Disarm the system by unlocking all doors and the rear
hatch or trunk lid by the remote control transmitter or
using the key.NOTE
To make sure the alarm sounds when the engine hood is
opened, open the engine hood by using the engine hood
release lever when the system is in the “armed” stage.
Disarm…by remote control transmitter
BK0115900US.book 25 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Features and controls
3-171
3
Dome light (Front)/Reading lights-Type1
(if so
equipped)
N00525800147
Dome light (Front)The dome light can be turned on by sliding the dome light
switch.
1 (DOOR) - The dome light comes on when any door or rear
hatch is opened. When all the doors (including the
rear hatch) are closed, the dome light is dimmed
gradually for 30 seconds then goes out. However,
the light goes out immediately without being
dimmed if:

The ignition switch is turned to the “ON” posi-
tion.

All the doors (including the rear hatch) are
locked using the power door lock switch, or
the remote control switch of the keyless entry
system.
NOTE
If the ignition key is removed with the doors
and the rear hatch closed, the dome light
comes on for 30 seconds and then goes out.
2 (OFF) - The dome light goes off.
BK0115900US.book 171 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Features and controls
3-173
3
Reading lights
N00553800083
Push the reading light switch (B) to turn on the light. This light
produces a spot beam for convenient use as a map light.
Push the reading light switch again to turn the light off.
(DOOR) - The dome light comes on when any door or rear
hatch is opened. When all the doors (including the
rear hatch) are closed, the dome light is dimmed
gradually for 30 seconds then goes out. However,
the light goes out immediately without being
dimmed if:

The ignition switch is turned to the “ON” posi-
tion.

All the doors (including the rear hatch) are
locked using the power door lock switch, or
the remote control switch of the keyless entry
system.
NOTE
If the ignition key is removed with the doors
and the rear hatch closed, the dome light
comes on for 30 seconds and then goes out.
(OFF) - The dome light goes off.
BK0115900US.book 173 ページ ２００９年１０月２７日　火曜日　午後１２時１分

3-174 Features and controls
3
Dome light (Rear) (ECLIPSE only)
N00525400417
The dome light can be turned on by sliding the dome light
switch.
Cargo area light (ECLIPSE only)
N00526100150
The cargo area light comes on when the rear hatch is opened.
When the rear hatch is closed, the cargo area light goes off.
1 ( ) -
The dome light comes on.
2 ( ) -The dome light comes on when any door or rear hatch is
opened. When all the doors (including the rear hatch)
are closed, the dome light is dimmed gradually for 30
seconds then goes out. However, the light goes out
immediately without being dimmed if:

The ignition switch is turned to the “ON” position.

All the doors (including the rear hatch) are locked
using the power door lock switch, or the remote
control switch of the keyless entry system.
NOTE
If the ignition key is removed with the doors and
the rear hatch closed, the dome light comes on for
30 seconds and then goes out.
3 ( ) -
The dome light goes off.
BK0115900US.book 174 ページ ２００９年１０月２７日　火曜日　午後１２時１分

5
Comfort controls
Vents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5- 2
Manual air conditioning (if so equipped). . . . . . . .5- 5
Automatic air conditioning (if so equipped) . . . . .5- 14
Important air conditioning operating tips . . . . . . .5- 22
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5- 24
AM/FM electronically tuned radio
with CD player-Type 1 (if so equipped) . . . . . . .5- 26
AM/FM electronically tuned radio
with CD autochanger-Type 2 (if so equipped)
AM/FM/Satellite electronically tuned radio
with CD autochanger-Type 3 (if so equipped) . .5- 39
To use the external audio input function . . . . . . . .5- 63
Steering wheel audio remote control switch
(if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . . .5- 65
Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5- 67
Error codes (SIRIUS Satellite Radio) . . . . . . . . . .5- 69
Handling of compact discs . . . . . . . . . . . . . . . . . . .5- 71
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5- 74
General information about your radio . . . . . . . . . .5- 76
BK0115900US.book 1 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Comfort controls
5-65
5 Steering wheel audio remote control switch

(if so equipped)
N00714800413
The remote control switches are located on the rear surface of
the steering wheel. Reach behind the wheel to access the
switches.
These switches can be used when the ignition switch is in the
“ON” or “ACC” position.
NOTE
Do not push two or more of the steering wheel remote
control switches at the same time.To turn on the powerPWR ON/OFF button — 4When the power is off, press this button to turn the power on.
To turn the power off, press this button for 2 seconds or longer.To adjust the volumeVolume up button — 2The volume will increase when this button is pressed.Volume down button — 6The volume will decrease when this button is pressed.To listen to the audio systemSelect the desired mode by lightly pressing the Mode change
button (4).
The mode switches between the radio and CD with each push
of the button.To listen to the radioTo select AM/FM/SAT modeMode change button — 4
Select the desired band by pressing this button.
The order is: AM → FM1 → FM2 (SAT1 → SAT2 → SAT3 →
SAT4) → CD → AM.
1- Seek up/Track up/Fast-forward button
2- Volume up button
3- Preset change/Folder up/Disc up button
4- PWR (ON/OFF)/Mode change button
5- Seek down/Track down/Fast-reverse button
6- Volume down button
BK0115900US.book 65 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Alphabetical index
1
A
Accessory (installation) 1-7
Active stability control 3-85
ASC indicator 3-88
ASC OFF indicator 3-88
ASC OFF switch 3-86
Skid control function 3-86
Traction control function 3-85
Air cleaner filter 7-11
Air conditioning
Automatic air conditioning 5-14
Important operating tips for the air conditioning 5-22
Manual air conditioning 5-5
Air conditioning label 9-2
Aluminum wheels 7-76
Antenna
Glass antenna 5-74
Satellite radio antenna 5-75
Whip antenna 5-74
Anti-lock braking system 3-82
Warning light 3-83
ASC 3-85
ASC indicator 3-88
ASC OFF indicator 3-88
ASC OFF switch 3-86
Audio system 5-24
AM/FM electronically tuned radio with CD autochanger-
Type 2 5-39AM/FM electronically tuned radio with CD player-Type 1
5-26
AM/FM/Satellite electronically tuned radio with CD
autochanger-Type 3 5-39
Error codes 5-67
Handling of compact discs 5-71
Steering wheel remote control switch 5-65
Automatic transaxle 3-71
Fluid 7-12
,9-9
Selector lever operation 3-72
Selector lever positions 3-76
Sports mode 3-77
B
Back-up lights
Bulb capacity 7-49
Replacement 7-59
Ball joint, steering linkage seals and drive shaft boots 7-34
Battery 7-16
Charging system warning light 3-114
Checking battery electrolyte level 7-17
Disconnection and connection 7-18
During cold weather 7-18
Specification 9-8
Brake
Anti-lock braking system 3-82
Braking 4-6
Fluid 7-15
,9-9
Hose 7-33
BK0115900US.book 1 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Alphabetical index
6AM/FM/Satellite electronically tuned radio with CD
autochanger-Type 3 5-39
General information about your radio 5-76
Rear combination lights 7-59
Rear hatch 3-16
Rear seat 2-11
Rear shelf panel 3-178
Rear side-marker lights
Bulb capacity 7-49
Replacement 7-59
Rear turn signal lights
Bulb capacity 7-49
Replacement 7-59
Rear window defogger switch 3-136
Rear-view camera 3-102
Rearview mirror
Inside 3-56
Outside 3-58
Refrigerant (air conditioning) 9-9
Replacement of light bulbs 7-47
Replacing tires and wheels 7-25
Reporting Safety Defects 8-3
S
Safe driving techniques 4-4
Seat 2-2
Front seats 2-4
Heated seats 2-10
Rear seat 2-11Seats and restraint systems 2-3
Seat belt 2-13
Adjustable seat belt shoulder anchor 2-19
Child restraints 2-24
Driver’s seat belt reminder/warning light 2-18
Front passenger seat belt warning light 2-19
Maintenance and inspection 2-35
Pre-tensioner 2-22
Seat belt extender 2-21
Seat belt guide 2-20
Seat belt use during pregnancy 2-22
Service brake 3-80
Service precautions 7-2
Skid control function 3-86
Snow tires 7-28
Spark plugs 7-32
Speedometer 3-106
Starting
At extremely cold ambient temperature 3-65
Flooded engine 3-66
Normal conditions 3-65
Steering
Power steering fluid 7-16
,9-9
Tilt lock lever 3-55
Wheel lock 3-63
Steering wheel remote control switch 5-65
Stop and tail light
Bulb capacity 7-49
Replacement 7-59
BK0115900US.book 6 ページ ２００９年１０月２７日　火曜日　午後１２時１分
