clock MITSUBISHI ECLIPSE 2011 4.G Owner's Manual

5-60 Comfort controls
5
To fast forward/reverse the discTo fast forward or reverse, use the TRACK button (7 or 8).
Fast forward
You can fast forward by holding down the side of the
TRACK button (7) for more than about 1 second.
Fast reverse
You can fast reverse by holding down the side of the
TRACK button (8) for more than about 1 second.
To select a desired folder (MP3 CDs only)You can select your desired folder by turning the
TUNE/FOLDER switch (11).
Folder up
Turn the TUNE/FOLDER switch (11) clockwise until the
desired folder number appears on the display.
Folder down
Turn the TUNE/FOLDER switch (11) counterclockwise until
the desired folder number appears on the display.
BK0115900US.book 60 ページ ２００９年１０月２７日　火曜日　午後１２時１分

5-74 Comfort controls
5Antenna
N00734200107
Glass antenna
(if so equipped)
N00702300020
The antenna is embedded in the inner side of the rear window
glass.NOTE
When the rear window glass is cleaned, wipe the glass
with a soft cloth by moving the cloth along the antenna so
as not to damage it.
Whip antenna
(if so equipped)
N00734400037
To remove the whip antenna, unscrew it by turning it counter-
clockwise.NOTE
Be sure to remove the whip antenna in the following
cases:
• When entering a place with low clearance.
• When going into an automatic car wash.
• When placing a car cover over the vehicle.
BK0115900US.book 74 ページ ２００９年１０月２７日　火曜日　午後１２時１分

For emergencies
6-7
6
6. When you do not see any more steam or spray, open the
hood. Look for obvious leaks, such as a split radiator
hose. Be careful as components will be hot. Any leak
source must be repaired.
7. If there is no obvious leak source, check the coolant level
in the reserve tank. If there is none, or if it is too low,
slowly add coolant.
8. If the reserve tank needs coolant, you will probably also
need to add coolant to the radiator. Do not loosen or
remove the radiator cap until the engine has cooled down.9. Start the engine, and slowly add coolant, up to the bottom
of the filler neck. Use plain water if you have to (and
replace it with the right coolant as soon as possible).
10. Replace the radiator cap and tighten it fully. Check the
temperature indicator. You can drive when the indicator
returns to the normal zone.
11. Have your vehicle checked by your authorized Mitsubishi
Motors dealer or a repair facility of your choice.
WA R N I N G
!
Removing the radiator cap could scald you with
escaping hot water or steam. When checking the
radiator level, cover the cap with a cloth before try-
ing to remove it. Turn it slowly counterclockwise,
without pressing down, to the first notch. The pres-
sure in the system will then be let out. When the
pressure is COMPLETELY LET OUT, press down
and keep turning the cap counterclockwise until it
will come off.
BK0115900US.book 7 ページ ２００９年１０月２７日　火曜日　午後１２時１分

6-12 For emergencies
6
To remove the spare tire
N00849700101
1. Lift up the luggage floor board.
2. To remove the spare tire, remove the installation clamp
(A) by turning it counterclockwise.NOTE
The clamp cannot be used for a normal tire. Store the nor-
mal tire in the cargo area (trunk).

Because the compact spare tire is designed only for
your vehicle, do not use it on any other vehicle.
Do not put the compact spare tire on a different
wheel, and do not put standard tires, snow tires,
wheel covers or trim rings on the compact spare
wheel. Damage may result.
Do not use snow chain with your compact spare tire.
Using a chain could cause damage to your vehicle
and loss of the chains.
CAUTION
!
BK0115900US.book 12 ページ ２００９年１０月２７日　火曜日　午後１２時１分

6-18 For emergencies
6
8. Lower the vehicle slowly by rotating the wheel nut
wrench counterclockwise until the tire touches the
ground.9. Tighten the nuts in the order shown in the illustration until
each nut has been tightened to the torque listed here.
88 to 108 N•m (65 to 80 ft-lb)
10. Lower the jack all the way and remove it.
CAUTION
!
Never use your foot or a pipe extension to apply
added force to the wheel nut wrench when tighten-
ing the wheel nuts. If you do so, you can over-tighten
the wheel nuts and damage the wheel.
BK0115900US.book 18 ページ ２００９年１０月２７日　火曜日　午後１２時１分

7-52 Vehicle care and maintenance
7
Headlights (except for vehicles with high inten-
sity discharge headlights)
N00943100162
1. Depress the tab (A) on the harness connector and pull the
harness connector toward you to remove it. 2. Turn the bulb (B) counterclockwise, and then remove the
headlight bulb with holder.
3. To install the bulb, perform the removal steps in reverse.*- Front of the vehicle
BK0115900US.book 52 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Vehicle care and maintenance
7-53
7
Adjustment of headlight aim
N00943200121
The alignment of the headlights should be checked by an
authorized Mitsubishi Motors dealer or a repair facility of your
choice.Parking and side-marker lights (vehicles with
high intensity discharge headlights)
N00917300280
1. When replacing the bulb on the left side, remove the cap
(A) of the headlight by turning it counterclockwise.
CAUTION
!
Handle halogen light bulb with care. The gas inside
a halogen light bulb is highly pressurized, so drop-
ping, knocking, or scratching a halogen light bulb
can cause it to shatter.
Never hold the halogen light bulb with a bare hand,
dirty glove, etc. The oil from your hand could cause
the bulb to break the next time the headlights are
used.
If the glass surface is dirty, clean it with alcohol and
let it dry completely before installing the bulb.
* - Front of the vehicle
BK0115900US.book 53 ページ ２００９年１０月２７日　火曜日　午後１２時１分

7-54 Vehicle care and maintenance
7
2. Remove the socket and bulb assembly (B) together by
turning it counterclockwise.3. Remove the bulb by pulling it out.
4. To install the bulb, perform the removal steps in reverse.
BK0115900US.book 54 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Vehicle care and maintenance
7-55
7
Front turn signal lights (vehicles with high inten-
sity discharge headlights)
N00943400022
1. When replacing the bulb on the left side, remove the cap
(A) of the headlight by turning it counterclockwise.2. Remove the socket and bulb assembly (B) together by
turning it counterclockwise.* - Front of the vehicle
BK0115900US.book 55 ページ ２００９年１０月２７日　火曜日　午後１２時１分

7-56 Vehicle care and maintenance
7
3. Remove the bulb by pulling it out.
4. To install the bulb, perform the removal steps in reverse.
Front turn signal, parking and side-marker lights
(except for vehicles with high intensity discharge
headlights)
N00943400048
1. Remove the entire socket and bulb assembly (A) by turn-
ing it clockwise (the left side) or counterclockwise (the
right side).*- Front of the vehicle
BK0115900US.book 56 ページ ２００９年１０月２７日　火曜日　午後１２時１分
