odometer MITSUBISHI ECLIPSE 2011 4.G Owners Manual

Features and controls
3-105
3 Instrument cluster
N00519000186
1- Speedometer
2- Tachometer
3- Fuel gauge
4- Light dimmer/Trip odometer control
5- Odometer/Trip odometer
6- Engine coolant temperature gauge
BK0115900US.book 105 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Features and controls
3-107
3
Tachometer
N00519200159
The tachometer shows engine revolutions per minute. This
allows the driver to determine the most efficient gear range and
engine speed combinations.
This gauge also assists in evaluating engine performance.
Odometer/Trip odometer
N00519500282
When the ignition switch is in the “ON” position, an “ODO” or
“TRIP” indicator is displayed.
CAUTION
!
The red zone indicates an engine speed beyond the
range of safe operation.
Select the correct gear to control the engine speed so
that the tachometer indicator does not enter the red
zone.
1- Reset button
2- Odometer/Trip odometer
BK0115900US.book 107 ページ ２００９年１０月２７日　火曜日　午後１２時１分

3-108 Features and controls
3
Every time the reset button (1) is pressed lightly (less than one
second), the indicators are changed.
ODO-OdometerThe odometer shows the total distance the vehicle has traveled. TRIP-Trip odometerThe trip odometer shows the distance traveled since the last
time it was reset.
There are two trip odometer displays: and .
TRIP can be used to measure the distance traveled since
the current trip began.
At the same time, TRIP can be used to measure the dis-
tance from a second location.
To reset the trip odometer
To zero the counter, press and hold the reset button for more
than one second. Only the currently displayed value will be
reset.
If TRIP is displayed, for example, only TRIP will be
reset. NOTE
Both TRIP and TRIP can measure trips up to
9999.9 miles/kilometers.

Even when the engine has been stopped, the odometer/trip
odometer indication is given for about 30 seconds if any
of the following steps is taken.
• The ignition key is turned to the “OFF” position.
• The driver’s door is opened.
• The odometer/trip odometer reset button is pressed.

If the battery is disconnected for a long time, both of these
displays will be reset to “0”.
Ty p e 1Ty p e 2BK0115900US.book 108 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Alphabetical index
5
Replacement 7-66
Light dimmer control 3-110
Loading information 4-7
Low-fuel warning light 3-109
Lubricants 9-9
Luggage hooks 3-180
M
Manual transaxle 3-67
Fluid 9-9
Oil 7-14
Shift points (recommended speed) 3-69
Mirror
Inside rearview mirror 3-56
Outside rearview mirrors 3-58
Modifications to and racing of your vehicle 1-7
Multi center display 3-115
N
Notepad holder 3-177
O
Octane requirement 1-2
Odometer 3-107
Oil
Engine oil 7-7
Manual transaxle oil 7-14
Oil pressure warning light 3-114
Operation under adverse driving conditions 6-22Outside rearview mirrors 3-58
Overheating 6-6
P
Parking 4-6
Parking brake 3-54
Parking brake lever stroke 7-30
Parking and side-marker lights
Bulb capacity 7-48
Replacement 7-53
Pen holder 3-177
Polishing 7-75
Power brakes 3-81
Power door locks 3-15
Power outlet 3-169
Power steering
Fluid 7-16
,9-9
System 3-90
Power windows 3-26
Puncture (Tire changing) 6-9
R
Radiator cap 7-11
Radio
AM/FM electronically tuned radio with CD autochanger-
Type 2 5-39
AM/FM electronically tuned radio with CD player-Type 1
5-26
BK0115900US.book 5 ページ ２００９年１０月２７日　火曜日　午後１２時１分

Alphabetical index
7
Sun visors 3-167
Sunroof 3-28
Supplemental Restraint System 2-36
How the Supplement Restraint System works 2-39
Servicing 2-57
Warning light 2-44
T
Tachometer 3-107
Tank capacity 1-5
,9-9
Theft-alarm system 3-22
Timing belt 7-36
Tire pressure monitoring system 3-97
Tires 7-20
How to change a tire 6-9
Inflation pressure 7-23
Maintenance 7-25
Quality grading 8-2
Replacing tires and wheels 7-25
Rotation 7-26
Size (tire and wheel) 9-8
Snow tires 7-28
Tire and loading information placard 4-8
,9-4
Tire chains 7-29
Tread wear indicators 7-26
Tools 6-8
Storage 6-8
Top stack 3-31
Towing 6-20Traction control function 3-85
Trailer towing 4-13
Trip odometer 3-107
Trunk lid 3-16
Turn signal lights
Bulb capacity 7-48
Indicators 3-112
Lever 3-130
Replacement 7-53
,7-55
,7-56
,7-59
V
Vanity mirror 3-168
Vanity mirror lights
Bulb capacity 7-50
,7-51
Replacement 7-69
Vehicle care precautions 7-71
Vehicle dimensions 9-5
Vehicle emission control information label 9-2
Vehicle identification number plate 9-2
Vehicle information code plate 9-2
Vehicle labeling 9-2
Vehicle preparation before driving 4-3
Vehicle weights 9-6
Vents 5-2
W
Warning lights 3-112
Washer
Fluid 7-14
,9-9
BK0115900US.book 7 ページ ２００９年１０月２７日　火曜日　午後１２時１分

How to calculate your gasoline mileage
You can calculate your miles-per-gallon or kilometers-per-litre
by using the following process:
1. Fill your vehicle’s fuel tank and record the odometer mile-
age.
2. Drive your vehicle as you normally do.3. Refill the fuel tank. Record the odometer mileage again,
as well as the gallons/litres of fuel used.
4. Subtract the first mileage number from the second number
to know how many miles/kilometers were driven. Divide
the number of miles/kilometers driven by the number of
gallons/litres of fuel used. This is your approximate miles-
per-gallon or kilometers-per-litre.
Gas mileage record Gas mileage record
Date
Odometer
Gallons
/Litres
This Fill
Cost Per
Gallon
/Litre
Cost
This Fill
Miles Per Gallon/Kilo-
meters Per Litre
(Miles/Gals.)/(Kilome-
ters/Litres)
Date
Odometer
Gallons
/Litres
This Fill
Cost Per
Gallon
/Litre
Cost
This Fill
Miles Per Gallon/Kilo-
meters Per Litre
(Miles/Gals.)/(Kilome-
ters/Litres)
