clock MITSUBISHI FTO 2003 1.G Owners Handbook

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-043 Hazard switch ..................................................................................................................36
Windscreen de-mist ......................................................................................................... 36
Fog / park light ................................................................................................................37
Ignition switch .................................................................................................................37
Park brake ........................................................................................................................ 38
Hand brake operation ...................................................................................................... 41
Adjustable items ......................................................................................................................... 42
Steering wheel adjustment ............................................................................................... 42
Interior mirror adjustment ............................................................................................... 42
Door mirrors ....................................................................................................................42
Door mirror parking ........................................................................................................ 43
ABS ................................................................................................................................. 43
Traction Control operation .............................................................................................. 44
Interior bits ...................................................................................................................... 44
Passenger interior lights................................................................................................... 46
Clock ............................................................................................................................... 46
Storage space .............................................................................................................................. 47
Coin holder ...................................................................................................................... 47
Glove box ........................................................................................................................ 47
Center console .................................................................................................................47
Storage in boot.................................................................................................................48
Climate control ..................................................................................................................................... 48
Climate controls...............................................................................................................50
Air flow indicator............................................................................................................ 51
Automatic air conditioning ......................................................................................................... 52
Operating the system as an automatic air conditioning ................................................... 53
Operating the system as a normal air conditioner............................................................ 54
Audio equipment .................................................................................................................................. 56
Antenna....................................................................................................................................... 56
Safety features ...................................................................................................................................... 58
Fitting of snow chains................................................................................................................. 58
Emergency flare .......................................................................................................................... 58
Tool kit and jack ......................................................................................................................... 59
Supporting the vehicle ................................................................................................................ 60
Changing the wheel and tyre. ..................................................................................................... 60
Starting the vehicle by external battery. .......................................................................... 64
Towing the vehicle. ......................................................................................................... 65
Service guide ......................................................................................................................................... 66
Capacities.................................................................................................................................... 66
Fuses ........................................................................................................................................... 66
Removal of fuses ............................................................................................................. 67
Engine oil.................................................................................................................................... 68
Belt adjustment. .......................................................................................................................... 69
Globes. ........................................................................................................................................ 69
Tyre information ......................................................................................................................... 70

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-046
General overview
Dashboard
1. Passenger air bag cover
2. Climate control screen
3. Analogue clock
4. Heated rear screen switch
5. Ammeter
6. Emergency hazard switch
7. Electric antenna switch
8. Windscreen wiper switch
9. Instrument panel10. Fog light switch
11. Indicator / light switch
12. Traction control switch
13. Exterior mirror control
14. Radio
15. Gear lever
16. Handbrake
17. Drivers air bag cover
18. Ignition switch

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0414
Opening / closing the vehicle
The key
The key number is located as shown. It
is advisable to make a note of the key
number.
Page 14
Unlocking the door
To unlock the vehicle with the key, turn
it anti-clockwise. To lock the vehicle
with the key, turn the key clockwise.
To lock the door without using the key:
1. Push inside door-lock lever forward.
2. Hold door handle open.
3. Push door closed.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0446
Passenger interior lights.
Fto-063-1a
Fto-063-1b
Clock
64-1a

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0453 temperature automatically to 25.0°C (AUTO).
Operating the system as an automatic air conditioning
1. Auto button and temperature set dial.
2. Front windscreen demister.
3. Outside air / recirculate.
4. Fan speed control.
5. Air condition control.
6. Set temperature / outside temperature control.
7. Off button.
8. Display screen.
9. Air flow control.
10. Rear windscreen demister control.
In normal conditions, use the system in AUTO mode and follow these procedures:
1. Press the “AUTO” button. The indicator will illuminate and the outlet port (except ? and ?),
interior/exterior air select and blower speed and ON/OFF of air conditioner will be controlled
automatically. The air conditioning compressor operation will change to (insert picture) (constant
air conditioning operation).
2. Turn the “TEMP” dial to set the desired temperature. The temperature can be set within a range
of 17.0°C to 32.0°C. the temperature will increase as the dial is turned in a clockwise direction.
Note: 1 If the outside air temperature drops below 0°C an alarm will sound, and the outside air
temperature is automatically displayed for a while.
Note: 2 When the vehicle is stopping or in some cases when the outside air temperature is likely to
be influenced by the engine compartment, or the sunshine reflected by the road surface, the
displayed temperature may be higher than the actual temperature.
Note: 3 Press the * button according to the need. Ever time the button is pressed, the mode
changes from ECO * to * to stop; and simultaneous with this, the display indicator changes
as well.
