MITSUBISHI iMiEV 2015 Owner's Manual (in English)

Vehicle labeling 11-2 Specifications
11
N01147400739
Keep a record of the chassis number and vehicle identification
number. This informa-
tion will assist the pol
ice if your vehicle is
ever stolen. The vehicle emission control information label is affixed in th
e location shown in the
illustration.
The vehicle identificati
on number is stamped
in the location shown in the illustration. It is visible from outside of the vehicle throughthe windshield. The air conditioning label is affixed on the bulkhead as shown in the illustration.
The vehicle information
code plate is located
on the driver’s door sill. The chassis number is stamped behind the lid on the right side of the luggage room.
Vehicle labeling 1 - Vehicle emission control information label
2 - Vehicle identification num- ber plate 3 - Air conditioning label
4 - Vehicle information code plate Chassis number
BK0209800US.book 2 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Vehicle dimensions
Specifications 11-3
11
The electric motor number is stamped on the cylinder block as shown
in the illustration.
N01148100599
The tire and loading information placard is located on the driver’s door sill.
N01148200239
The certification label is located on the driver’s door sill.
N01147500538 N01147600861
Electric motor number * - Front of the vehicle
Tire and loading information placard
Certification label Vehicle dimensions Overall length 144.8 in (3,675 mm) Overall width 62.4 in (1,585 mm) Overall height 63.6 in (1,615 mm)Wheel base 100.4 in (2,550 mm)Vehicle weights Gross vehicle weight rating (GVWR)
3,329 lb (1,510 kg)
BK0209800US.book 3 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Charging system specifications 11-4 Specifications
11
GVWR: maximum total we
ight (load) limit
specified for the vehicle GAWR: maximum weight (load) limit speci- fied for the front or rear axle
Seating capacity: the number of maximum occupants
N01148500027
Gross axle weight rating (GAWR)
Front 1,488 lb (675 kg)Rear 1,962 lb (890 kg)
Vehicle capacity weight
661 lb (300 kg)
Seating capacity 4 persons
Charging system specifications Regular charging system
Rated input voltage AC 240V (si
ngle phase) AC 120V (single phase)
Rated input frequency 50 Hz/60 HzRated current 15 A (max)
8 A/12 A (max)
*1
Maximum power consumption
3.3 kVA
*2
1.8 kVA
*2
Applicable standards
UL2594: Electric Vehicle Supply Equipment UL62: Flexible Cords and Cable UL2251: Plugs, Recept
acles and Couplers fo
r Electric Vehicle
SAE J1772: (R) SAE Electric Vehicl
e and Plug in Hybrid Electric
Vehicle Conductive Charge Coupler CSA C22.2 No.107.1-01: Ge
neral use power supplies
CSA C22.2 No.42-10: General use rece
ptacles, attachment plugs, and
similar wiring devicesCSA C22.2 No.49-10: Flexible Cords and Cables CSA C22.2 No.182.2-M1987: Industr
ial Locking Type, Special Use
Attachment Plugs, Rece
ptacles and
Connectors
Leakage current sensitivity in cable control box
20 mA
BK0209800US.book 4 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Electric motor specifications
Specifications 11-5
11
*1: When using a genuine charging cable with control box *2: When using a home or public charging device
(EVSE: Electric Vehicles Supply Equipment)
N01147300028
N01147800270
Battery is a 12 volt type.
N01147900734
PCD: Pitch Circle
Diameter (ins
tallation holes)
Quick charging system
Applicable standards CHAdeMOMaximum input current 125 A
Regular charging/ Quick charging system
Enclosure type
Charge connector: Type 3s Control box (CCID): Type 3
Electric motor specifications Electric motor model Y51Maximum output 49 kW
Maximum torque 196 N•m12V starter battery
34B19L(S)
Tires and wheels
Item
Front
Rear
Tire 145/65R15 72H 175/60R15 81HWheel
Size 15x4J 15x5JPCD 3.93 in (100 mm)Offset 1.37 in (35 mm)
NOTE
 Contact a certifie
d i-MiEV dealer for de
tails on the combination used on your vehicle.
BK0209800US.book 5 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Refill capacities 11-6 Specifications
11
N01148001003
* : similar high quality ethylene
glycol based non-silicate, non-
amine, non-nitrate and non-borate
coolant with long life hybrid
organic acid tech-
nology These tires satisfy vehicle loading condit
ions described in th
is owner’s manual.
Refill capacities No.
Item
Capacity
Lubricants
1
Windshield washer fluid 2.0 qt (1.9 L) —
2
Brake As required Conforming to Brake fluid DOT 3 or DOT 4
3
Hot water heater fluid [Includes .42 qt (0.4 L) in reservoir]
2.0 qt (1.9 L)
Mitsubishi Motors Genui
ne Super Long Life
Coolant Premium or
an equivalent
*
4
Coolant [Includes 1.2 qt (1.1 L) in reservoir]
5.4 qt (5.1 L)
5
Transmission .79 qt (0.75 L) Mits
ubishi Motors Genuine ATF SP III
6
Refrigerant (air
conditioning)
Refer to the “Air con- ditioning label” on
page 11-2
HFC-134a
NOTE
BK0209800US.book 6 ページ ２０１４年１月１４日　火曜日　午前９時２６分
