coolant reservoir MITSUBISHI iMiEV 2015 Owner's Manual (in English)

Under the hood/Electric motor unit room
Overview 1-4
1
N00100800041
Under the hood/Electric motor unit room Under the hood Electric motor unit room
Coolant reservoir P. 9 - 4
Windshield washer fluid reservoir P. 9 - 7
On board charger/DC-DC converter P. 9 - 2
12V starter battery P. 9 - 7
Brake electric vacuum pump P.5-24
Hot water heater reservoir P. 9 - 4
Inverter P.3-30
Brake fluid reservoir P. 9 - 7
BK0209800US.book 4 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Driving during cold weather
Driving safety 6-5
6
N00629400416
 Check the 12V starter battery, including terminals and cables. During extremely cold weather, the 12V starter battery willnot be as strong and its power level may drop. Before driving the vehicle, check to see ifthe headlights are as bright as normal. Charge or replace th
e 12V starter battery
if necessary. During extreme cold weather, it is possible that a very low 12V starter battery
could freeze.
 Check the antifreeze. If there is not enough coolant because of aleak, add high-quality ethylene glycol antifreeze and water. Use Mitsubishi Motors Genuine Super Long Life CoolantPremium or an equivalent. The recom- mended blend is about 50 % water and 50 % anti-freeze. Use a higher concentration(not over 60 %) when the outside temper- ature is -31 °F (-35 °C) or lower. When the electric motor unit is working very hard (for example,
during mountain driv-
ing and/or when the outside temperatureis high), use a 50 % concentration. This blend will provide adequate protection from corrosion and boiling.
N00629501531
All the parts of the brake system are critical to safety. Have the vehicle serviced by a certi- fied i-MiEV dealer at regular intervalsaccording to the “WARRANTY AND MAINTENANCE MANUAL”.
Check the brake system while driving at a low speed immediately
after starting, espe-
cially when the brakes are wet, to confirmthey work normally. A film of water can be formed on the brake discs and prevent normal braking after driv-ing in heavy rain or through large puddles, or after the vehicle is washed. If this occurs, dry the brakes out by drivi
ng slowly while lightly
depressing the brake pedal. On snowy roads, ice can form on the braking system, making the brakes less effective. While driving in such
conditions, pay close
attention to preceding and following vehicles and to the condition of the road surface. From time to time, lightly depress the brake pedaland check how effective the brakes are. Put the selector lever to “B” (REGENERA- TIVE BRAKE MODE) or “ECO” (ECO MODE) position according to the grade of the slope and vehicle sp
eed. This will allow
Driving during cold weather
WA R N I N GThe 12V starter batter
y gives off explosive
hydrogen gas. Any spark or flame cancause the 12V starter battery to explode, which could cause serious injury or death. Always wear protecti
ve clothes and a face
mask when working wi
th your 12V starter
battery, or let a skil
led mechanic do it.
WA R N I N GNever open the coolan
t reservoir cap while
it is hot. You could be seriously burned.
Braking
When brakes are wet When driving in cold weather When driving downhill
BK0209800US.book 5 ページ ２０１４年１月１４日　火曜日　午前９時２６分

View under the hood and
electric motor unit room
9-4 Vehicle care and maintenance
9
Make sure the hood is securely locked by softly lifting the centre of the hood. Slowly lower the hood about 12 inches (30 cm), then let it drop from its own weight.
N00937600700
N00937800539
CAUTION Always insert the support prop into the hole specially made for
it. Propping the hood at
any other place could
cause the prop to slip
out and lead to
an accident.
The hood prop can fall out if the hood is lifted by a strong wind.
To close
CAUTION Be careful not to trap your hands or fingers when closing the hood.
 Make sure the hood is firmly closed before driving.If you drive without the hood completelyclosed, it could open up while driving.NOTE
 If this does not close the hood properly, drop it again from a slightly higher position.  Do not push down strongly on the hood. Depending on how strongly or where you push down, you could create a dent in the hood.
View under the hood and electric motor unit room
CAUTION
Under the hood
1- Windshield washer fluid reservoir 2- 12V starter battery 3- Hot water heater reservoir 4- Brake fluid reservoir5- Coolant reservoirCoolant/Hot water heater fluid To check the coolant level
WA R N I N G Before checking the
coolant level, make
sure the electric motor switch is in the“Lock” position to
avoid the risk of an
electrical shock that can result in serious injury or death.Electric motor unit room
BK0209800US.book 4 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Coolant/Hot water heater fluid
Vehicle care and maintenance 9-5
9
1. Open the liftgate. 2. Peel off the Velcro fastener (A) to remove the luggage room floor carpet (B).
3. Turn the 4 screws on the front and rear of the electric motor unit room lid (C) coun- terclockwise to loosen and remove them,and then remove the electric motor unit room lid (C).
4. Check the coolant level in the reservoir (D).While the motor is cold, the coolant level must always be between the “F (FULL)” and the “L (LOW)”
marks. If necessary,
add coolant. Refer to
“To add coolant” on
page 9-6. 5. Reinstall the electric motor unit room lid and the luggage room floor carpet by fol- lowing the removal procedures in reverse.
The reservoir (A) is located under the hood.
 The room under the h
ood and the electric
motor unit room (loc
ated under the lug-
gage room carpet) can be very hot afterdriving. Wait until they have cooled down.
Coolant
WA R N I N G
NOTE
 A heat insulating material is attached to the luggage room floor ca
rpet. To remove the
luggage floor carpet, grasp and lift up boththe carpet fabric and the heat insulating material.NOTE
 When laying the electric motor unit room lid on the ground, leave the underside of the lid with the rubber surface facing up. If theunderside is facing downward debris and other foreign material
could get on the rub-
ber surface and prevent proper reinstallationof the electric motor unit room lid.
WA R N I N G Never touch components inside the elec- tric motor unit room except the reservoir (D).
Hot water heater fluid
FULL LOW
BK0209800US.book 5 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Coolant/Hot water heater fluid 9-6 Vehicle care and maintenance
9
The coolant level in th
is reservoir should be
kept between the “F (FULL)” and the “L(LOW)” marks when measured while the electric motor is cold. If necessary, add cool- ant. Refer to “To add coolant” on page 9-6.
N00955900024
Mitsubishi Motors Genui
ne Coolant provides
excellent protection against corrosion and rust formation on all metals, including alumi- num.
If you need to add coolant often, the cooling system should be pressure-tested for leaks.Take your vehicle to a certified i-MiEV dealer for testing.
N00955800010
The reservoir cap (E) must be tightly sealedto prevent losing coolant which may result in electric motor or nearby parts of the roomunder the hood damage. Only use a Genuine Mitsubishi Parts rese
rvoir cap, or an
approved equivalent.
N00955700019
 Do not overfill the reservoir.  Your vehicle uses a special reservoir cap that stays sealed and keeps the pressure inthe reservoir below the allowable pres- sure. If you need to change the cap, use the exact same kind.  Check the coolant freeze point in the radi- ator with the proper gauge, and only when it is safe. If you add antifreeze, the con-tents of the reservoi
r must be protected
against freezing.  Keep the front of the radiator and con- denser clean.
To add coolant Use “Mitsubishi Motors
Genuine Super Long
Life Coolant Premium”
or an equivalent
*.
* : similar high qual
ity ethylene glycol
based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technologyFULL LOW
CAUTION Do not use alcohol or
methanol antifreeze or
any coolants that c
ontain them. Using the
wrong antifreeze can corrode aluminumparts.  The required concentration of anti-freeze dif- fers depending on the
expected ambient tem-
perature. Above -31 °F (-35 °C):
50 % concentration
of anti-freeze Below -31 °F (-35 °C): 60 % concentration of anti-freezeYou can check the concen
tration level with a
gauge from an automotive supply store, or a certified i-MiEV dealer or service station cancheck it for you. Do not use water to adjust the concentration of coolant.  Do not top off the tank with plain water only. Water by itself boils at a lower temperature and does not stop rust or freezing. If the water freezes, it will
damage your cooling
system. Do not use tap water. It can cause corrosion and rust.
Reservoir cap
WA R N I N G Wait for the electric motor to cool down before opening the re
servoir cap. Other-
wise hot steam or bo
iling coolant could
spray up from the re
servoir and scald you.
Points to remember
BK0209800US.book 6 ページ ２０１４年１月１４日　火曜日　午前９時２６分

Refill capacities 11-6 Specifications
11
N01148001003
* : similar high quality ethylene
glycol based non-silicate, non-
amine, non-nitrate and non-borate
coolant with long life hybrid
organic acid tech-
nology These tires satisfy vehicle loading condit
ions described in th
is owner’s manual.
Refill capacities No.
Item
Capacity
Lubricants
1
Windshield washer fluid 2.0 qt (1.9 L) —
2
Brake As required Conforming to Brake fluid DOT 3 or DOT 4
3
Hot water heater fluid [Includes .42 qt (0.4 L) in reservoir]
2.0 qt (1.9 L)
Mitsubishi Motors Genui
ne Super Long Life
Coolant Premium or
an equivalent
*
4
Coolant [Includes 1.2 qt (1.1 L) in reservoir]
5.4 qt (5.1 L)
5
Transmission .79 qt (0.75 L) Mits
ubishi Motors Genuine ATF SP III
6
Refrigerant (air
conditioning)
Refer to the “Air con- ditioning label” on
page 11-2
HFC-134a
NOTE
