MITSUBISHI iMiEV 2017 1.G Owners Manual

AM/FM electronically tuned radio with CD player (if so equipped)
Comfort controls 7-19
7
N00771900017
Press the SCAN button.
“SCAN” will appear
on the display and the CD player will playback the first 10 second
s of each track on the
selected disc (music
CDs only) or the cur-
rently selected folder (MP3 CDs only).The track number will blink while the scan mode is selected. To stop the scan mode, press the SCAN button again.
N00752100166
This audio system can
display CD text and
MP3 titles including ID3 tag information. The audio system can di
splay disc and track
titles for discs with converted disc and track title information. Press the DISP button repeatedly to make selections in the following sequence: disc name
 track name
 normal
display mode. The audio system can display folder and track titles for discs wi
th converted folder and track
information. Press the DISP button repeat- edly to make selections in the followingsequence: folder name
 track name
 nor-
mal display mode.
The audio system can
display ID3 tag infor-
mation for files that ha
ve been recorded with
ID3 tag information. 1. Press the DISP button for 2 seconds or longer to switch to the ID3 tag informa- tion. “TAG” will appear on the display.2. Press the DISP button repeatedly to make selections in th
e following sequence:
album name
 track name
 artist name
 normal display mode.
NOTE
With a disc that contains both CD-DA and MP3 files, the random
mode causes only
files of the same format (CD-DA only orMP3 files only) to be repeated.
To find the start of each track on a disc for playback

NOTE
 Once all tracks on the
disc (music CDs only)
or the currently selected folder (MP3 CDs only) have been scanne
d, playback of the
disc will restart from
the beginning of the
track that was play
ing when scanning
started.  With a disc that contains both CD-DA and MP3 files, the scan m
ode causes only files of
the same format (CD-DA only or MP3 filesonly) to be played.
CD text and MP3 title display

CD text
NOTE
 The display can show up to 11 characters. If a disc name or track
name has more than 11
characters, press the PAGE button to viewthe next 11 characters.  When there is no title information to be dis- played, the display shows “NO TITLE”.  Characters that the a
udio system cannot dis-
play are shown as “ ”.
ID3 tag information
NOTE
 To return from ID3 tag information to the folder name, press the DISP button again for2 seconds or longer.  When there is no title information to be dis- played, the display
shows “NO TITLE”.
a folder name, track name
, or item of ID3 tag
information has more than 11 characters, press the PAGE button to view the next 11characters.  Folder names, trac
k names and ID3 tag
information can each be displayed up to a length of 32 characters.  Characters that the a
udio system cannot dis-
play are shown as “ ”.
BK0220401US.book 19 ページ ２０１５年６月３日　水曜日　午前７時４２分

To play iPod/USB memory device tracks via voice op
eration (vehicles with
Bluetooth® 2.0 interface)
7-20 Comfort controls
7
N00772001025
Desired tracks can be
selected and played
from your iPod or USB memory device by “Artist”, “Album”, “Playlist” and “Genre” For information concerning the voice recog- nition function or speak
er registration func-
tion, refer to “Bluetooth
® 2.0 interface” on
page 5-53.The following explains how to prepare for voice operation and play the tracks.
N00772101026
To use the voice operation, press the PICK-UP button (1) first.
N00772200017
1. Say “Play” on the main menu. 2. After the voice guide says “Would you like to play by Artist, Album, Playlist orGenre?,” say “Artist”.
3. After the voice guide
says “What Artist
would you like to play?,” say the artistname. 4. If there is only one ma
tch, the system pro-
ceeds to step 6.5. If there are two or more matches, the voice guide will say “More than one match was found, would you like to play?” If you
say “Yes,” the sys-
tem proceeds to step 6. If you say “No,” the next matching artist is uttered by the system. 6. After the voice guide
says “Playing name>,” the system creates a playlist index for the artist.
To play iPod/USB memory device tracks via voice oper-ation (vehicles with Blue-tooth
® 2.0 interface)
Preparation for voice operation
To search by artist name
NOTE
 The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device. If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow the voice guide.NOTE
 If you say “Artist ,” you can skip step 3.
NOTE
 If you say “No” to three or all artist names uttered by the system, the voice guide will say “Artist not found, please try again” and the system returns to step 2.  Search time depends
on the number of songs
on your connected devi
ce. Devices contain-
ing a large number of songs may take longer to return search results.
BK0220401US.book 20 ページ ２０１５年６月３日　水曜日　午前７時４２分

To play iPod/USB memory device tr
acks via voice operation (vehicles with Bluetooth® 2.0 interface)
Comfort controls 7-21
7
7. The system exits
the voice recognition
mode and starts playback.
N00772300018
1. Say “Play” on the main menu. 2. After the voice guide says “Would you like to play by Artist, Album, Playlist or Genre?,” say “Album”.
3. After the voice gui
de says “What Album
would you like to play?” say the albumtitle. 4. If there is only one match, the system pro- ceeds to step 6.5. If there are two or more matches, the voice guide will say “More than one match was found, would you like to play?” If yo
u say “Yes,” the sys-
tem proceeds to step 6. If you say “No,” the name of the next matching album is uttered by the system. 6. After the voice gui
de says “Playing
,” the system creates a playl-ist index for the album title.
7. The system exits the voice recognition mode and starts playback.
N00772400019
1. Say “Play” on the main menu. 2. After the voice guide says “Would you like to play by Artist, Album, Playlist or Genre?,” say
“Playlist”.
3. After the voice guide says “What Playlist would you like to play?,” say the playlist name. 4. If there is only one match, the system pro-ceeds to step 6.
NOTE
 If the confirmation f
unction is active, the
voice guide confirms if
the artist name is
correct. If the artist name is correct, say“Yes”. If not, say “No”. After the voice guide says “Artist not found, please try again,” the system returns to step 2.
To search by album title
NOTE
 The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device. If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow th
e voice guide.
NOTE
If you say “Album <
title>,” you can skip
step 3.
NOTE
 If you say “No” to three or all album titles uttered by the system, the voice guide will say “Album not found, please try again” and the system returns to step 2.NOTE
 If the confirmation function is active, the voice guide confirms if
the album title is cor-
rect. If the album title is correct, say “Yes”.
the voice guide says
“Album not found, please try again,” the sys- tem returns to step 2.
To search by playlist
NOTE
 The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device. If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow th
e voice guide.
NOTE
If you say “Playlist laylist>,” you can skip
step 3. If the device has no playlist, the voice guidewill say “There are no
playlists stored on
device” and the system returns to step 2.
BK0220401US.book 21 ページ ２０１５年６月３日　水曜日　午前７時４２分

Steering wheel audio remote cont
rol switch (if so equipped)
7-22 Comfort controls
7
5. If there are two or more matches, the voice guide will say “More than onematch was found, would you like to play ?” If you say “Yes,” the system proceeds to step 6.If you say “No,” the next matching playl- ist name is uttered by the system. 6. After the voice gui
de says “Playing
,” the system creates an index for the playlist. 7. The system exits the voice recognition mode and starts playback.
N00772500010
1. Say “Play” on the main menu. 2. After the voice guide says “Would you like to play by Artist, Album, Playlist or Genre?,” say “Genre”. would you like to play?,” say the musictype. 4. If there is only one match, the system pro- ceeds to step 6.5. If there are two or more matches, the voice guide will say “More than one match was found, would you like to play?” If you say “Yes,” the system proceeds to step 6.
If you say “No,” the next matching genre is uttered by the system. 6. After the voice gui
de says “Playing
,” the system creates an index forthe genre. 7. The system exits the voice recognition mode and starts playback.
N00714800471
The remote control switch is located on theleft side of th
e steering wheel.
NOTE
If you say “No” to three
or all playlist names
uttered by the system, the voice guide willsay “Playlist not found,
please try again” and
the system returns to step 2.NOTE
 If the confirmation function is active, the voice guide confirms if
the playlist name is
correct. If the playlist name is correct, say “Yes”. If not, say “No”. After the voice guidesays “Playlist not foun
d, please try again,”
the system returns to step 2. Refer to “Con- firmation function se
tting” on page 5-57.
To search by genre
NOTE
The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device.If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow the voice guide.NOTE
 If you say “Genre ,” you can skip step 3.
NOTE
 If you say “No” to three or all genres uttered by the system, the voice guide will say “Genre not found, please try again” and thesystem returns to step 2.NOTE
 If the confirmation function is active, the voice guide confirms if the genre is correct. If the genre is correct, say “Yes”. If not, say“No”. After the voice
guide says “Genre not
found, please try again,” the system returns to step 2. Refer to
“Confirmation function
setting” on page 5-57.
Steering wheel audio remote control switch
(if so equipped)
BK0220401US.book 22 ページ ２０１５年６月３日　水曜日　午前７時４２分

Steering wheel audio remote control switch (if so equipped)
Comfort controls 7-23
7
It can be used when the electric motor switch is in the “ON” or “ACC” position. Press the power switch to turn on the power. When the power is turned on, the last mode
used before turning off is displayed. To turn off the power, press and hold down the powerswitch for about 2 seconds until you hear a beep. While the button is pressed, the volume will continue to increase. While the button is pressed, the volume will continue to decrease. Press the mode selector button to select the desired mode.The mode changes in the following order. AM
 FM1
 FM2
 CD
 USB or iPod
*
 Bluetooth
®*  AM
* : If you connect these devices.
Press the mode selector button and select AM or FM mode. After pressing one of
these buttons, a receiv-
able station will be automatically selected and reception of the st
ation will begin.
Press the mode selector
button and select CD
mode. To fast forward or fast
reverse the disc, press
the fast-forward button or the fast-reverse button. You can fast forward the disc by holding down the fast-forward button. While the but-
1- Volume up button 2- Volume down button 3- Power switch/Mode selector button4- Seek up/Track up/File up/Fast-forward
button
5- Seek down/Track down/File
down/Fast-reverse buttonNOTE
 Do not press multiple buttons at the same time when using the steering wheel audioremote control switch.
To turn on the power

Vo l u m e c o n t r o l

Volume up button

Volume down button

Mode selection

To listen to the radio

Automatic tuning

Seek up button/Seek down buttonTo listen to a CD

To fast forward/reverse the disc (music CDs only)

Fast forward
BK0220401US.book 23 ページ ２０１５年６月３日　水曜日　午前７時４２分

Error codes 7-24 Comfort controls
7
ton is kept pressed, th
e disc will be fast-for-
warded. You can fast reverse the disc by holding down the fast-reverse button. While the button is kept pressed, the disc
will be fast-reversed.
You can select your desired track by using the track up button or the track down button.
Press the mode select
or button and select
iPod mode. Press the button repeatedly until the desired track number appears on the display. Press the button repeatedly until the desired track number appears on the display.
Press the mode select
or button and select
USB mode. Press the button repeated
ly until the desired
track number appears on the display. Press the button repeated
ly until the desired
track number appears on the display.
N00736100777
If an error code appears in the display, take action in accordance with the table below. Fast reverse
NOTE
 With an MP3 CD, you can fast forward and fast reverse tracks in the same folder.
To select a desired track

NOTE
 Pressing the track down button once during the song will cause the system to restart playing from the beginning of the song.
To listen to an iPod

To select a desired track

Track up button
NOTE
 The track number continues to increase while the button is pressed.
Track down button
NOTE
 The track number cont
inues to decrease
while the button is pressed.
To listen to a USB memory device

To select a desired file

File up button
NOTE
 The track number continues to increase while the button is pressed.
File down button
NOTE
 The track number cont
inues to decrease
while the button is pressed.
Error codes BK0220401US.book 24 ページ ２０１５年６月３日　水曜日　午前７時４２分

Handling of compact discs Comfort controls 7-25
7
N00734100340
 Use only the type of compact discs that have the mark shown in the illustration below. (Playback of CD-R or CD-RW discs may cause problems.)
 The use of special shaped, damaged com- pact discs (like cracked discs) or low- quality compact discs (like warped discsor burrs on the discs)
such as those shown
will damage the CD player.
Error display
Problem
Item
Repair
NO DISC No disc inserted Disc is
not in CD player. Insert disc.
CHECK DISC Focus error
Disc is not loaded correctly, or condensation on disc.
Insert disc with label facing up. Remove moisture from disc.
DISC ERROR Disc error
Disc is dirty, scratched,
or deformed; or exces-
sive vehicle vibration.
Clean or replace disc.
Retry when vibrations
stop.
INTERNAL E Mechanism error
Loading or eject error. Pick-up is out of posi- tion.
Eject disc and reload. If di
sc will not eject, bring
your vehicle to a certified i-MiEV dealer.
HEAT ERROR
Inside of audio system is hot.
Internal protection agai
nst high temperatures.
Allow radio to cool
by waiting about 30 min-
utes.
ERROR DC DC offset output voltage Foreign materi
al is inside of radio or amplifier. Bri
ng your vehicle to a certified i-MiEV deale
r.
ERROR
Communication or power supply error
Communication error betw
een external device
and equipment. Power supply error of external device.
Bring your vehicle to a certified i-MiEV dealer.
Handling of compact discs
BK0220401US.book 25 ページ ２０１５年６月３日　水曜日　午前７時４２分

Handling of compact discs 7-26 Comfort controls
7
 In the following circumstances, moisture can form on compact discs and inside theaudio system, preventing normal opera- tion. • When there is high humidity (for exam-ple, when it is raining). • When the temperature suddenly rises, such as right after the heater is turned onin cold weather. In this case, wait until the moisture has had time to dry out.
 When the CD player is subjected to vio- lent vibrations, such as during off-roaddriving, the tracking may not work.  When storing compact discs, always store them in their separate
cases. Never place
compact discs in direct sunlight, or in any place where the temperature or humidity is high. Never touch the flat surface of the disc where there isn’t a label. This will damage the disc surface and could affect the sound quality. When handli
ng a compact disc,
always hold it by the outer edge and thecenter hole.  To clean a disc, use a soft, clean, dry cloth. Wipe directly
from the center hole
toward the outer edge. Do not wipe in a circle. Never use any chemicals such as benzine, paint thi
nner, a disc spray
cleaner, or an anti-static agent on the disc.  Do not use a ball point
pen, felt pen, pen-
cil, etc. to write on the label surface of thedisc.  Do not put additional la
bels or stickers on
compact discs. Also, do not use any com-pact disc on which a label or sticker has started to peel off or any compact disc that has stickiness or ot
her contamination left
by a peeled-off label or sticker. If you use such a compact disc, the CD player may stop working properly and you may not beable to eject the compact disc.
N00751900112
 You may have trouble playing back some CD-R/RW discs recorded on CD record- ers (CD-R/RW drives), either due to theirrecording characteristics or dirt, finger- prints, scratches, etc.
on the disc surface.
 CD-R/RW discs are less resistant to high temperatures and high humidity than ordi- nary music CDs and can therefore be damaged and rendered unplayable if left inside your vehicle for a long time.  Depending on the combination of the writing software, the CD recorder (CD- R/RW drive), and the disc used to create a CD-R/RW, the disc might not play suc-cessfully.  This player cannot play the CD-R/RW discs if the sessi
on is not closed.
 This player cannot play CD-R/RW discs which contain data other than CD-DA or MP3 data (Video CD, etc.). Be sure to observe the handling instruc- tions for the CD-R/RW disc.
Notes on CD-Rs/RWs
BK0220401US.book 26 ページ ２０１５年６月３日　水曜日　午前７時４２分

Antenna
Comfort controls 7-27
7
N00734200471
Turn the pole (A) counterclockwise. Screw the pole (A) clockwise into the base (B) until it is securely retained.
N00755000124
The time is displayed when the electric motorswitch is in the “
1. Press and hold the clock button and the clock display flashes. 2. Press the SEEK button to adjust the“hours” digit. If you keep pressing the button, fast-for- ward begins.3. When the “hours” digit is adjusted, press the clock button to flash the “minutes” digit.Press the SEEK button to adjust the “min- utes” digit. If you keep pressing the button, fast-for-ward begins.
WA R N I N G Operating the CD player in a manner other than specifically instructed hereinmay result in hazardous radiation expo-sure. Do not remove the cover and attempt to repair the CD player by yourself. There are no user serviceable parts inside. Incase of malfunction, contact a certified i- MiEV dealer.
Antenna To remove To install
NOTE
 Be sure to remove the roof antenna in the following cases: • When using an automatic car wash • When covering your vehicle with a car cover • When driving into a structure that has a low ceiling.
Clock
(if so equipped)
To set the time

A- Clock button B- SEEK (clock adjustment up) buttonC- SEEK (clock adjustment down) but-
ton
BK0220401US.book 27 ページ ２０１５年６月３日　水曜日　午前７時４２分

General information about your radio 7-28 Comfort controls
7
4. When the time is set, press the clock but- ton to stop the clock display from flash-ing.
N00733900439
Your vehicle’s radio receives both AM andFM stations. The quality of your reception is affected by distance, obstacles, an
d signal interference.
This radio complies with Part 15 of Federal Communications Commission (FCC) Rules (for vehicles sold in U.S.A.). Operation is subject to the following conditions:  The device may not cause harmful inter- ference.  This device must ac
cept any interference
recieved, including interference that maycause undesirable operation.
FM signals do not follow the earth surface nor are they reflected by the upper atmo-sphere. For this reason,
FM broadcasts cannot
be received over long distances. AM signals follow the earth’s surface and are reflected bythe upper atmosphere. For this reason, AM broadcasts can be received over longer dis- tances.
Because of the limite
d range of FM signals
and the way FM waves transmit, you may experience weak or fading FM reception.When the broadcast is blocked by mountains or similar obstructions,
reception ca
n be dis-
turbed. The reason why one can hear FM but not AM in parking garages, unde
r bridges etc., is that
FM signals, unlike AM
signals, are reflected
by solid objects such
as buildings, etc.
Because FM signals are easily reflected by buildings, this can also
cause reception dis-
turbances.The direct signal from
the broadcast station
reaches the antenna slightly before the reflected signal. This
time difference may
cause some reception di
sturbance or flutter.
This problem occurs primarily in urban areas.
NOTE
 Reset the time after the 12V starter battery terminals are disconnect
ed and reconnected.
 Seconds do not appear
in the clock display,
but after adjusting the
“minutes” setting, the
clock begins to opera
te from 0 seconds.
General information about your radio
CAUTION Changes or modifica
tions not expressly
approved by the party meeting the aboveconditions could void th
e user’s authority to
operate the equipment.
Signal transmission FM AM 25 to 40 mile radius (25 to 40 miles)
100 mile radius (100 miles)
Weak reception (fading) Reflection
BK0220401US.book 28 ページ ２０１５年６月３日　水曜日　午前７時４２分
