Engine specificationsE01100602416ItemStandard power engineHigh power engineM/TA/T2WD with 15 inch tyres2WD with 16 inch tyres, 4WD
Engine type
Four-cylinder, in line, water
cooled four-cycle, doubleoverhead camshaft with
small-sized intercooler and turbocharger
Four-cylinder, in line, water cooled four-cycle, double overhead camshaft with intercooler and turbocharger
Engine models4D56Total displacement2,477 ccBore91.1 mmStroke95.0 mmCompression ratio17.0:116.5:1Valve clearanceIntake0.09 mm (cold)Exhaust0.14 mm (cold)Maximum output (EEC net)94 kW/4,000 r/min100 kW/4,000 r/min,
100 kW/3,500 r/min *131 kW/4,000 r/minMaximum torque (EEC net)240 Nm/1,500 to 3,500 r/min314 Nm/2,000 r/min400 Nm/2.000 to 2.850 r/min350 Nm/1.800 to 3,500 r/min*
: Vehicles for Ukraine and Kazakhstan.
