Page 81 of 177
![MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to SIRIUS 7-12
9) [Text]
This switches the text display.
10) [
Channel], [Channel ]
Moves up and down one channel each time.
Touch and hold one of these buttons to
continuously MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to SIRIUS 7-12
9) [Text]
This switches the text display.
10) [
Channel], [Channel ]
Moves up and down one channel each time.
Touch and hold one of these buttons to
continuously](/img/19/7452/w960_7452-80.png)
Listening to SIRIUS 7-12
9) [Text]
This switches the text display.
10) [
Channel], [Channel ]
Moves up and down one channel each time.
Touch and hold one of these buttons to
continuously change the channel. Release the
button to stop on a channel.
11) Incoming Category Name
The name of the category being received is displayed.
12) Playback Mode
The currently selected playback mode is displayed.
13) Incoming Channel and Incoming Channel
Name
The channel and the name of the channel being
received is displayed.
Category List and Channel List
eng_a439
eng_a438
1) Category List This displays the category button. Touch the button to display the channel list.
2) Channel List This displays the channel button. Touch the button to start receiving the relevant channel.
3) [CAT-Scan]
This scans the channels in the currently selected category.
SIRIUS Satellite Radio Inc. “SIRIUS” and related marks
are trademarks of SIRIUS Satellite Radio Inc.
1)
2)
3)
Listening to SIRIUS
Only for vehicles equipped with satellite radio (SIRIUS) tuner
(if so equipped) Display Contents
Normal Reception Screen
eng_a437
1) Preset Number
If the channel being received has been preset, the preset number is displayed.
2) Band
Displays the band which is currently being listened to.
3) Band Switching Button
Touch this button to switch bands.
4) TEXT Display
Information about the current channel is displayed.
5) Preset Button
The preset number, channel number and channel name is displayed.
6) [ ]
Touch this button to display the Sub Menu.
7) [Direct]
The channel number entered to the screen directly is displayed.
8) [Category]
The category screen is displayed.
2)
3)
4)
5)
6) 7) 8) 9) 10)
12) 13)
1)
11 )
\b \b
\f \
\b
\b
\f
Page 82 of 177
![MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to SIRIUS 7-13
Audio
Selecting Stations
1 Press the [MODE] key, and touch
[SIRIUS]
eng_a310
NOTE
switched.
2 Touch either [ Channel] or
[Channel
] to select the channel to
be re MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to SIRIUS 7-13
Audio
Selecting Stations
1 Press the [MODE] key, and touch
[SIRIUS]
eng_a310
NOTE
switched.
2 Touch either [ Channel] or
[Channel
] to select the channel to
be re](/img/19/7452/w960_7452-81.png)
Listening to SIRIUS 7-13
Audio
Selecting Stations
1 Press the [MODE] key, and touch
[SIRIUS]
eng_a310
NOTE
switched.
2 Touch either [ Channel] or
[Channel
] to select the channel to
be received
eng_a440
The channels is changed one channel at a time.
Touch and hold one of these buttons to continuously
change the incoming channel. Release the button to
stop on a channel.
Selecting a Category to Be Received
1 Press the [MODE] key, and touch
[SIRIUS]
2 Touch [Category]
eng_a440The category list is displayed.
3 Touch the category button
eng_a439The list of channels within the selected category is
displayed.
4 Touch the channel button
eng_a441
The relevant channel is started to be received.
Scanning
It is possible to search for channels that
can be received in the current location.
Scanning Channels
Scan all channels.
1 Press the [MODE] key, and touch
[SIRIUS]
eng_a310
2 Touch [ ]
eng_a440
\b \b
\f \
\b
\b
\f
Page 98 of 177
![MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to MP3/WMA Disks 7-29
Audio
3 Touch [Repeat] again
REPEAT
eng_a332
FOLDER-REPEAT
eng_a333Each time [Repeat] is touched, the playback mode
changes.REPEAT The track currently being playe MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to MP3/WMA Disks 7-29
Audio
3 Touch [Repeat] again
REPEAT
eng_a332
FOLDER-REPEAT
eng_a333Each time [Repeat] is touched, the playback mode
changes.REPEAT The track currently being playe](/img/19/7452/w960_7452-97.png)
Listening to MP3/WMA Disks 7-29
Audio
3 Touch [Repeat] again
REPEAT
eng_a332
FOLDER-REPEAT
eng_a333Each time [Repeat] is touched, the playback mode
changes.REPEAT The track currently being played plays repeatedly.
FOLDER-
REPEAT All tracks in the folder currently being
played play repeatedly.
(OFF) Cancels the repeat playback.
Scan PlaybackThe start of each track is played for approximately 10
seconds each. Use to nd a desired track.
1 Touch [ ]
eng_a328
2 Touch [Scan]
eng_a331Scan playback is started.
3 Touch [Scan] again
SCAN
eng_a334
FOLDER-SCAN
eng_a335Each time [Scan] is touched, the playback mode
changes.SCAN Performs scan playback on all the tracks in the folder currently being played.
FOLDER-
SCANPerforms scan playback on the first
track in all the folders on the disk.
(OFF) Cancels the scan playback.
4 Touch the name of the track
during playback
Scanning is stopped, and the selected track is played.
NOTE
returns to the rst track.
\b \b
\f \
\b \b
Page 99 of 177
![MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to MP3/WMA Disks 7-30
Random PlaybackThe track order can be changed and played randomly
on the MP3/WMA disk currently being played.
1 Touch [ ]
eng_a328
2 Touch [Random]
eng_a331Random MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to MP3/WMA Disks 7-30
Random PlaybackThe track order can be changed and played randomly
on the MP3/WMA disk currently being played.
1 Touch [ ]
eng_a328
2 Touch [Random]
eng_a331Random](/img/19/7452/w960_7452-98.png)
Listening to MP3/WMA Disks 7-30
Random PlaybackThe track order can be changed and played randomly
on the MP3/WMA disk currently being played.
1 Touch [ ]
eng_a328
2 Touch [Random]
eng_a331Random playback is started.
3 Touch [Random] again
RANDOM
eng_a336
ALL-RANDOM
eng_a337Each time [Random] is touched, the playback mode
changes.RANDOM Performs random playback on all the
tracks in the folder currently being
played.
ALL-RANDOMPerforms random playback on all the
tracks on the disk.
(OFF) Cancels the random playback.
\b \b
\f \
\b \b
Page 100 of 177

To play tracks from iPod or USB device 7-31
Audio
To play tracks from
iPod or USB device
(if so equipped)
“iPod” is a registered trademark of Apple Inc.
in the United States and other countries.
To play from an iPod
1 Press the [MODE] key, and touch [iPod]
eng_a676
NOTE
displayed.
iPod.
The display screen may differ depending on the file
composition of the iPod or the vehicle installation type.
iPod ScreenDisplay example (Category)
eng_a651
Display example (Track)
eng_a652
Display example (Sub Menu)
eng_a653
1) Title
[iPod] is displayed while an iPod is playing.
2) [ Home ]
Touch this button to move the cursor to the track currently being played.
3) [
Track], [Track ]
[
Track]Use to select the previous track or
the start of the track currently being
played. Touch and hold to rewind. Play
resumes when the button is released.
[Track ]Use to select the next track. Touch
and hold to fast-forward. Play
resumes when the button is released.
4) Category Button
Changes to display each of the categories.
: ROOT
: Playlists
: Artists
: Albums
: Songs
: Genres
5) Playback Mode
The currently selected playback mode is displayed.
6) Album Name (Folder name)
The name of the album (name of the folder) for the track currently being played is displayed.
7) Cursor
Displays the item currently selected.
8) Track Number and Track Name
The number and name of the track currently being played is displayed.
9) [ ]
Touch this button to display the Sub Menu.
10) Playback Time
The playback time for the track currently being played is displayed.
11) Artist Name
The name of the artist whose track is currently being played is displayed.
12) [Repeat]
Each time [Repeat] is touched, the playback mode changes.
REPEAT T h e t r a c k c u r re n tly being played
plays repeatedly.
(OFF) Cancels the repeat playback.
13) [Back]
Deletes the Sub Menu.
14) [Random]
Each time [Random] is touched, the playback mode changes.
RANDOM Performs random playback on all
tracks.
Album
RANDOM Performs random playback on all
Albums.
(OFF) Cancels the random playback.
12)
14)
13)
1)
2)
3)
5)
4)
8)
10)
11 )
6)
7)
9)
4)
\b \b
\f \
\b \b
Page 101 of 177
![MITSUBISHI LANCER 2012 8.G MMCS Manual To play tracks from iPod or USB device 7-32
To play from a USB memory device
1 Press the [MODE] key, and touch [USB]
eng_a677
NOTE
iPod] or [iPod] is displayed.
If [USB] is not displayed, check the MITSUBISHI LANCER 2012 8.G MMCS Manual To play tracks from iPod or USB device 7-32
To play from a USB memory device
1 Press the [MODE] key, and touch [USB]
eng_a677
NOTE
iPod] or [iPod] is displayed.
If [USB] is not displayed, check the](/img/19/7452/w960_7452-100.png)
To play tracks from iPod or USB device 7-32
To play from a USB memory device
1 Press the [MODE] key, and touch [USB]
eng_a677
NOTE
iPod] or [iPod] is displayed.
If [USB] is not displayed, check the connection of the
USB memory device.
device being connected.
USB memory device ScreenDisplay example
eng_a654
Display example (Sub Menu)
eng_a655
1) Media type
Displays the le format during playback. [MP3], [WMA], [AAC], [WAV]
2) Title
[USB] is displayed while a USB memory device is playing.
3) Track Number and Track Name
The number and name of the track currently being played is displayed.
4) [ Home ]
Touch this button to move the cursor to the track currently being played.
5) Cursor
Displays the item currently selected.
6) [ ]
Touch this button to display the Sub Menu.
7) [
Folder] and [ Folder ]
[ Folder] Selects the previous folder
[Folder ] Selects the next folder
8) Playlist Button
Changes to playlist mode.
9) [
Track] and [Track ]
[ Track]Use to select the previous track or
the start of the track currently being
played. Touch and hold to rewind. Play
resumes when the button is released.
[Track ]Use to select the next track. Touch
and hold to fast-forward. Play
resumes when the button is released.
10) Layer Operation Button
Touch this button to display the list of upper layer folders.
11) Playback Mode
The currently selected playback mode is displayed.
12) Artist Name
The name of the artist whose track is currently being played is displayed. 13) Album Name (Folder name)
The name of the album (name of the folder) for the
track currently being played is displayed.
14) [SCAN]
Each time [Scan] is touched, the playback mode changes.
SCANPerforms scan playback on all the tracks
in the folder currently being played.
FOLDER-
SCANPerforms scan playback on the rst
track in all the folders on the USB
memory device.
(OFF) Cancels the scan playback.
15) [Repeat]
Each time [Repeat] is touched, the playback mode changes.
REPEAT The track currently being played plays repeatedly.
FOLDER-
REPEAT All tracks in the folder currently being
played play repeatedly.
(OFF) Cancels the repeat playback.
16) [Database]
Displays the Gracenote version.
17) [Help]
Displays the VR Command List.
18) [Back]
Deletes the Sub Menu.
19) [Random]
Each time [Random] is touched, the playback mode changes.
RANDOMPerforms random playback on all the
tracks in the folder currently being played.
ALL-RANDOMPerforms random playback on all the
tracks on the USB memory device.
(OFF) Cancels the random playback.
20) Playback Time
The playback time for the track currently being played is displayed.
2)
4)
8)6)
12) 13)1)
3)
5)
7) 9)
10)
11 )
14)
15)
16)17) 19)18)
20)
\b \b
\f \
\b \b
\f
Page 109 of 177
![MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to the Music Server 8-4
3 Touch [Track]
eng_a339The list of tracks is displayed.
NOTE
track list.
Changing the Playback Mode
Repeat playback, random playback, and
scan playback can all MITSUBISHI LANCER 2012 8.G MMCS Manual Listening to the Music Server 8-4
3 Touch [Track]
eng_a339The list of tracks is displayed.
NOTE
track list.
Changing the Playback Mode
Repeat playback, random playback, and
scan playback can all](/img/19/7452/w960_7452-108.png)
Listening to the Music Server 8-4
3 Touch [Track]
eng_a339The list of tracks is displayed.
NOTE
track list.
Changing the Playback Mode
Repeat playback, random playback, and
scan playback can all be performed from
the Music Server playback screen.
NOTE
playback cannot be performed by group.
Repeat PlaybackThe track currently being played can be listened to
repeatedly.
1 Touch [ ]
eng_a339
2 Touch [Repeat]
eng_a342The track currently being played plays repeatedly.
3 Touch [Repeat] again
REPEAT
eng_a343
PLAYLIST-REPEAT
eng_a344Each time [Repeat] is touched, the playback mode
changes.REPEAT The track currently being played plays
repeatedly.
PLAYLIST-
REPEAT All tracks in the playlist currently being
played play repeatedly.
(OFF) Cancels the repeat playback.
\b \b
\f \
\b \b \b
