MITSUBISHI LANCER 2015 8.G Owners Handbook

9DISPLAY AUDIO SYSTEM (if equipped)
System Settings
System related settings, such as the operation sound and the
time, can be made.
1. Press the MENU key. The top menu is displayed.
2. Touch Setting, and then System Setting.
Listening to the Radio
This explains how to listen to AM and FM radio broadcasts. HD RadioTM
broadcast or analog broadcast can be received.
1. Press the MENU key. The top menu is displayed.
2. Touch AM or FM. The radio broadcast information screen is displayed.
3. Touch TUNE to tune in a station. The station at the selected frequency is
played.
PSD Program Service Data: Contributes to the superior user
experience of HD Radio Technology. Presents song name, artist,
station IDs, HD2/HD3 Channel Guide, and other relevant data
streams.

HD2/HD3 Adjacent to traditional main stations are extra local FM
channels. These HD2/HD3 Channels provide new, original music
as well as deep cuts into traditional genre.
Digital Sound Digital, CD-quality sound. HD Radio Technology enables local
radio stations to broadcast a clean digital signal. AM sounds like
today’s FM and FM sounds like a CD.
The system setting screen is displayed.
This is a setting item displayed by touching Time Setting .
Settings name Settings value Settings content
Time
Adjustmen tT
ime
Touch the corresponding or and change the date and time.
Time Display
Settings Dat
e
The date and time display format can be set.
Time12h or 24h display can be set.
This HD Radio receiver enables:

10DISPLAY AUDIO SYSTEM (continued)
FM Radio Broadcast Information Screen (Display Audio System only)
3)
4) 1)
8)
6)
5)
2)
9)7)10) 16)
11),12)
13)
14)
17)
15)
1. Source plate - Displays the name of the currently selected source, preset channel nu\
mber, reception frequency, and station name.
2. HD Radio TM indicator - Displayed during digital sound output.
3. Preset switch - Allows you to register your favorite broadcast stations.
Touch and hold the switch for the desired preset channel number until you\
hear the “beep”. This registers the broadcast station currently being
received.
**→“Register Your Favorite Broadcast Stations”
4.
 - Touching it displays the sub-menu. The Scan, Radio Setting, Sound Control settings can be made.
5. - Used to change the frequency. Touching and holding until you hear the “beep” starts automatic sta\
tion selection (seek).
**→“Starting the Seek”
6. SSN - Displays the SSN (Short Station Name) that is currently being recei\
ved. If there is a sub-channel, “the received channel number/total number of sub-channels” is displayed.
7. PTY - Displays the PTY (Program Type) being received.
8. Info - Switches to information display.
9. Station List - Displays a list of the stations that can be received.
**→“Search for Broadcast Stations from the Station List”
10. FM1, FM2 - Allows you to register your favorite 6 stations for each band.
11. Title - Displays the acquired title name.
12. Radio Text - During analog reception, “Title” changes to “Radio Text”, and the acquired radio text is displayed. The “artist” an\
d “album” are not displayed.
13. Artist - Displays the acquired artist name.
14. Album - Displays the acquired album name.
15. Indicator - LIVE: Live event broadcasts are displayed as they are received.
RBDS: RBDS data is displayed as it is received.
16. Switch page - If the title, artist name, and album title cannot fit in one page, \
the display can be switched to Page 2 and beyond.
17. Preset - Switches to preset display.
**See Display Audio Owner’s Manual.

11BLUETOOTH® OPERATION WITH DISPLAY AUDIO SYSTEM (if equipped)
Calling by Entering a Telephone Number
1. On the mobile phone screen, enter the telephone number.
2. Touch the “OFF HOOK” key.
Making a Call from a Phonebook
1. Display the vehicle phonebook screen
or the mobile phonebook screen.
**→ “Display the Phonebook”
2. Select and touch the person to call.
Incoming Calls
The audio guide sounds and the
incoming call screen is displayed.
Registering a Bluetooth® Device
Register a Bluetooth® device with this product.
1. Press the MENU key. The top menu is displayed.
2. Touch Setting, and then Bluetooth
® Setting.
3. Touch Register Device.
4. Enter the pass key displayed on the screen into the Bluetooth
® device.
For a list of compatible Bluetooth
® devices please go to
http://www.mitsubishicars.com/owners
SPEECH button:
Change to voice
recognition
PICK-UP button:
Answer an
incoming call
HANG-UP button
End a call or voice
recognition
A
B
C
When the connection is complete, a screen is displayed for selecting
the Bluetooth® device. For details, refer to the user manual for the
Bluetooth® device.
“OFF HOOK” key
3. Touch the telephone number to call.
4. Touch Ye s.
**See Display Audio Owner’s Manual.
A
B
C
Bluetooth® Controls

12FAQ’s
Q: What should I do when my engine is hard to start?
A: Pressing on the accelerator pedal about half way down while cranking the\
engine may make it easier to start. When the engine starts, release your foot
from the accelerator pedal.
Q: Is my phone compatible with the factory Mitsubishi Bluetooth
® Hands Free System?
A: Check the phone approval list, www.mitsubishicars.com/owners to see if the phone is Bluetooth® approved.
Q. Why doesn’t my device (USB, iPhone, Bluetooth
® Audio, etc.) work?
A: You need to press the Mode button to select the appropriate device you wa\
nt to use.
Q: How do I use Bluetooth
® Audio (if equipped)?
A: Turn the Audio System power on. Press the CD button several times until B\
(Bluetooth®) is shown. Connect your Bluetooth® device via pairing mode.
Playback will start automatically.
Q: How do I transfer calls from Bluetooth
® back to my mobile phone’s handset?
A: While on the call, press the speech button on your steering wheel and, o\
nce prompted, say “Transfer Call.”
Q: Why does the FUSE Hands-free Link System™ take so long to upload my music from my audio music device?
A: The Mitsubishi system can read multiple device structures in order to ca\
talog the music files for easy playing and listening. Depending on the amount
of music you have on your device, this may take a few minutes.
Q: What are the different ways of playing music from my portable music play\
er through the stereo system in my vehicle, when equipped with the FUSE Hands-free
Link System™?
A: There are three ways of playing music through your vehicle’s sound system.
• USB port - The FUSE system will find the songs in your device and cate\
gorize them according to Artist, Album, and Genre. Then you can have
the FUSE system find and play the song in your device that you prefer \
without physically searching your device. This is done via voice commands.
Note: In this mode the storage device will also be charged.
• Bluetooth
® Streaming - Once your device is paired to the FUSE system, you can stre\
am music from your device through the FUSE system to your
vehicle’s sound system. No wires or cords. Your music stops and restarts at the same song when you exit and when you\
re-enter the vehicle. Voice
commands are not available.
• RCA auxiliary ports (if equipped) - Music can be played through a vehi\
cle’s stereo system via the head phone port of your music device (An RCA
to mini headphone jack adapter cable will be needed) Voice command is not available.
Q: Why can’t I control the music track selection via voice commands whil\
e Bluetooth
® streaming?
A: The Mitsubishi system is not configured to support this functionality.
Q: My Lancer is equipped with “Micron Air Filtration”. Where is the fi\
lter located and does it need servicing?
A: The micron air filter is a small filter element which is located in \
the HVAC box just behind the glove box. The filter should be inspected frequ\
ently for
debris. The filter works well at filtering incoming air however the \
filter will clog and lead to reduced outlet air volume if not serviced on a regular basis.

13
Q: My Lancer has two 12V accessory outlets. What devices can be plugged int\
o these outlets?
A: Both of these outlets are protected with 15 amp fuses. Always check the \
current draw rating of any device prior to use in the vehicle. If the device is
rated above 12 amps, this could lead to circuit overload and the electri\
cal fuse opening (no current flow).
Q: I only have one remote for the remote start system on my Lancer. Can I get a second one?
A: No. Only one remote can be programmed per vehicle for security reasons. \
Q: How can I get the MPG stated on the window sticker?
A: Vehicle driving styles will greatly affect MPG. Avoid sudden abrupt starts from a stop and let the vehicle coast to the t\
raffic light. Both of these styles
will increase mileage and reduce brake lining wear.
• Vehicles are designed to achieve the best fuel mileage when they are driv\
en at the speed limits on the freeway. Avoid driving over 65 mph.
• Under inflated tires will increase rolling resistance and will reduce \
fuel mileage. Check tire pressure frequently to increase miles per gallon.
Proper tire pressure also ensures optimum tire performance (including t\
ire wear.)
Q: How does the Navigation System choose a certain route?
A: The system takes into account traffic conditions, road types, distance\
and road width to recommend the route.
Q: Why does my Anti-Lock Braking System (ABS) make a noise?
A: Each time your vehicle is started and driven a short distance, you will \
hear the sound of the ABS motor operating from the right front engine
compartment. This is the normal sound the Anti-Lock Braking System makes\
when performing a self check.
Q: Why do my Rain Sensing Windshield Wipers operate on their own when it’\
s not raining?
A: • When the lever is in the AUTO position, the rain sensor detects rain or \
snow and automatically turns on the wipers.
• The wipers may automatically operate when things such as insects or fore\
ign objects are affixed to the windshield on top of the rain sensor or
when the windshield is frosted over.
• To stop the wipers, place the lever in the OFF position.
Q: Why does my check engine light come on after I put gas in my car?
A: There are many reasons why your check engine light may illuminate. Befor\
e calling your dealership, make sure the fuel cap is fully engaged and
you have heard three clicks when tightening it. After checking and heari\
ng three clicks and driving for a while, if the light is still on, contact your
dealership.
Q: How do I use the emergency key when the F.A.S.T.-key battery or vehicle battery is run down?
A: Remove the emergency key from the F.A.S.T.-key fob and manually unlock the door. Once inside the vehicle remove the ignition switch cover
by pressing the release buttons on the top and bottom of the ignition sw\
itch cover. Once the ignition switch cover is removed insert the
emergency key into the ignition switch then re-insert (backwards) the \
F.A.S.T.-key fob onto the emergency key. Once the F.A.S.T.-key fob
is re-inserted (backwards) turn the emergency key to start the engine.\
FAQ’s
