MPI – Throttle Body13-37
THROTTLE BODY
REMOVAL AND INSTALLATION
Pre-removal Operation
(1) Engine Coolant Draining
(2) Air Hose D Removal
(Refer to GROUP 15 – Intercooler.)
(3) Strut Tower Bar RemovalPost-installation Operation
(1) Strut Tower Bar Installation
(2) Air Hose D Installation
(Refer to GROUP 15 – Intercooler.)
(3) Engine Coolant Supplying
(4) Accelerator Cable Adjustment
34 2
61
7
19 {1.9}
5
Unit: Nm {kgf
m}
5 {0.5}
Removal steps
1. Accelerator cable connection
2. Throttle position sensor connector
3. Idle speed control servo connector
4. Vacuum hose connection5. Water hose connection
6. Throttle body
A7. Throttle body gasket
INSTALLATION SERVICE POINT
ATHROTTLE BODY GASKET INSTALLATION
Place the gasket so that the projecting part is positioned
as shown in the illustration, and then install it between the
intake manifold and the throttle body.
Towards front
of vehicle
Up

14-1
ENGINE
COOLING
CONTENTS
SERVICE SPECIFICATIONS 2. . . . . . . . . . . . . .
LUBRICANT 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 2. . . . . . . . . . . . . . . . . .
Coolant Replacement 2. . . . . . . . . . . . . . . . . . . . . .
THERMOSTAT 3. . . . . . . . . . . . . . . . . . . . . . . . . . .
WATER PUMP 5. . . . . . . . . . . . . . . . . . . . . . . . . . .
WATER HOSE AND WATER PIPE 6. . . . . . . .
RADIATOR 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ENGINE COOLING – Service Specifications / Lubricant / On-vehicle Service14-2
SERVICE SPECIFICATIONS
ItemsStandard value
Thermostat valve opening temperature
CWhen open76.5 ± 1.5
When fully open90
Thermostat lift mm8.5 or more
LUBRICANT
ItemsBrandQuantity dm3 {
}
Coolant capacity (in condenser tank)MITSUBISHI GENUINE DIA QUEEN SUPER
LONG LIFE COOLANT6 {6}
ON-VEHICLE SERVICE
COOLANT REPLACEMENT
CYLINDER BLOCK DRAIN PLUG
Unit: Nm {kgfm}
Drying sealant: HELMESEAL H-1M
44 {4.5}
RADIATOR CAP VALVE OPENING PRESSURE
CHECK
On EVOLUTION-V, the radiator cap valve opening pressure
must be as shown below.
Standard value: 93 – 123 kPa {0.95 – 1.25 kgf/cm
2}
Limit: 83 kPa {0.85 kgf/cm
2}

ENGINE COOLING – Thermostat14-3
THERMOSTAT
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
Engine Coolant Draining and Supplying
(Refer to P.14-2.)
Air Intake Hose Assembly Removal and Installation
(Refer to GROUP 15 – Intercooler.)
4 3
5
1
Unit: Nm {kgfm}
13 {1.3}
Removal steps
AB1. Radiator lower hose connection
2. Control wiring harness connection
3. Water inlet fitting
A4. Thermostat
REMOVAL SERVICE POINT
ARADIATOR LOWER HOSE DISCONNECTION
After making mating marks on the radiator hose and the hose
clamp, disconnect the radiator hose.

ENGINE COOLING – Thermostat14-4
INSTALLATION SERVICE POINTS
ATHERMOSTAT INSTALLATION
(1) Install the thermostat so that the jiggle valve is facing
straight up.
Caution
Make absolutely sure that no oil is adhering to the
rubber ring of the thermostat. If the rubber ring is
damaged, replace the thermostat.
(2) When assembling the thermostat, be careful not to fold
over or scratch the rubber ring.
BRADIATOR LOWER HOSE CONNECTION
(1) Insert each hose as far as the projection of the water
inlet fitting.
(2) Align the mating marks on the radiator hose and hose
clamp, and then connect the radiator hose.
INSPECTION
THERMOSTAT CHECK
(1) Immerse the thermostat in water, and heat the water while
stirring. Check the thermostat valve opening temperature.
Standard value: 76.5 ± 1.5
C
(2) Check that the amount of valve lift is at the standard
value when the water is at the full-opening temperature.
Standard value:
Full-opening temperature: 90
C
Amount of valve lift: 8.5 mm or more
NOTE
Measure the valve height when the thermostat is fully
closed, calculate the valve lift by subtracting this
measurement from the valve height when the thermostat
is fully open.
Jiggle valve
Rubber ring
Valve lift

ENGINE COOLING – Water Pump14-5
WATER PUMP
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
Engine Coolant Draining and Supplying
(Refer to P.14-2.)Timing Belt and Timing Belt B Removal and Installation
(Refer to GROUP 11.)
12 – 15 {1.2 – 1.5} 24 {2.4}
8 × 22 8 × 14
Bolt specifications
8 × 24
Screw diameter × length mm
1
2
4
3
2
22 {2.2}
8 × 70
Unit: Nm {kgfm}
Removal steps
1. Alternator brace
2. Water pump
3. Water pump gasket
A4. O-ring
INSTALLATION SERVICE POINT
AO-RING INSTALLATION
Fit the O-ring in the O-ring groove in the water inlet pipe,
and coat the outer circumference of the O-ring or the inside
surface of the water pump with water before inserting the
pipe.
Water pump
O-ring
Water inlet pipe

ENGINE COOLING – Water Hose and Water Pipe14-6
WATER HOSE AND WATER PIPE
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
(1) Coolant Draining and Refilling (Refer to P.14-2.)
(2) Air Hose C Removal and Installation
(Refer to GROUP 15 – INTERCOOLER.)
(3) Air Control Valve Bracket Removal and Installation
(Refer to GROUP 15 – AIR CONTROL VALVE.)
6 2
10
8
Semi-drying sealant:
THREEBOND 1207F
57

3mm
6
9 1 3
Unit: Nm {kgfm}
24 {2.4}
48 {4.9}
10 {1.0}
141112
13 {1.3}
41 {4.2} 13 {1.3} 10 {1.0}24 {2.4}
41 {4.2}
13
4
Removal steps
AC1. Radiator upper hose connection
AC2. Radiator lower hose connection
3. Water hose
4. Water hose
5. Water inlet fitting
B6. Thermostat case assembly
7. Water hose
8. Water hose9. Heater hose connection
A10. O-ring
11. Water inlet pipe
A12. O-ring
Turbocharger (Refer to GROUP 15.)
13. Water pipe assembly A
14. Water pipe assembly B

ENGINE COOLING – Radiator14-7
RADIATOR
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
Engine Coolant Draining and Supplying (Refer to
P.14-2.)
2
3 611
12 6
810
796
1513
4
Unit: Nm {kgfm}
12 {1.2} 12 {1.2}
12 {1.2}
9
Radiator removal steps
1. Drain plug
2. Radiator cap
3. Overflow hose
4. Reserve tank
5. Reserve tank bracket
AA6. Radiator upper hose
AA7. Radiator lower hose
8. Radiator assembly
9. Lower insulator
10. Radiator fan motor assemblyRadiator fan motor removal steps
1. Drain plug
2. Radiator cap
AA6. Radiator upper hose
Air intake hose
(Refer to GROUP15 – Intercooler.)
10. Radiator fan motor assembly
11. Fan
12. Radiator fan motor
13. Shroud

ENGINE COOLING – Radiator14-8
REMOVAL SERVICE POINTS
ARADIATOR UPPER HOSE / RADIATOR LOWER
HOSE DISCONNECTION
After making mating marks on the radiator hose and the hose
clamp, disconnect the radiator hose.
INSTALLATION SERVICE POINT
ARADIATOR LOWER HOSE / RADIATOR UPPER
HOSE CONNECTION
(1) Insert each hose as far as the projection of the water
inlet or outlet fitting.
(2) Align the mating marks on the radiator hose and hose
clamp, and then connect the radiator hose.
Caution
Fit the clamp on the hose at the same position as
before.
INSPECTION
1. RADIATOR FAN MOTOR CHECK
Apply the battery voltage across connector terminals 1 and
2, and terminals 3 and 4, of the radiator fan motor and check,
at that time, that the radiator fan turns.
2. POWER RELAY CONTINUITY CHECK
Battery voltageTerminal number
1345
When deenergized
When energized
Radiator fan motor relay LO

ENGINE COOLING – Radiator14-9
Battery voltageTerminal number
1234
When deenergized
When energized
Radiator fan motor relay HI
