MITSUBISHI LANCER EVOLUTION VI 1999 Workshop Manual

FUEL SUPPLY – General / Fuel Tank13-69
FUEL SUPPLY
GENERAL
OUTLINE OF CHANGE
The service procedures have been revised as shown below because of change in the fuel pump & gauge
assembly and the fuel gauge unit.
FUEL TANK
REMOVAL AND INSTALLATION
4
32 1
65
7
11
Removal steps
1. Fuel hose
2. Fuel pump & gauge assembly
3. Packing
A4. High-pressure fuel hose5. Fuel pipe assembly
6. Fuel gauge unit
7. Packing
NOTE
The service procedures other than those mentioned above
remain unchanged.
INSTALLATION SERVICE POINT
AHIGH-PRESSURE FUEL HOSE INSTALLATION
Caution
After connecting the quick-release joint of the
high-pressure fuel hose, pull it gently in the direction
of removal to check that the hose is firmly connected
with a play of about 3 mm.

NOTES

21A-1
CLUTCH
CONTENTS
GENERAL 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outline of Change 2. . . . . . . . . . . . . . . . . . . . . . . . .
SERVICE SPECIFICATIONS 2. . . . . . . . . . . . . .
LUBRICANTS 2. . . . . . . . . . . . . . . . . . . . . . . . . . . ON-VEHICLE SERVICE 2. . . . . . . . . . . . . . . . . .
Clutch Pedal Inspection and Adjustment 2. . . . .
Bleeding 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLUTCH PEDAL 4. . . . . . . . . . . . . . . . . . . . . . . . .
CLUTCH CONTROL 5. . . . . . . . . . . . . . . . . . . . .
Clutch Master Cylinder 6. . . . . . . . . . . . . . . . . . . . .

CLUTCH –
General / Service Specifications /
Lubricants / On-vehicle Service21A-2
GENERAL
OUTLINE OF CHANGE

The service procedures for left-hand drive vehicles have been established as described below.
SERVICE SPECIFICATIONS
ItemsStandard value
Clutch pedal height mm163.5–166.5
Clutch pedal clevis pin play mm1–3
Clutch pedal free play mm6–13
Distance between the clutch pedal and the toeboard when
the clutch is disengaged mm85 or more
LUBRICANTS
ItemsSpecified lubricantsQuantity
Clutch fluidBrake fluid DOT 3 or DOT 4As required
Push rod assemblyRubber grease
Boot
Release cylinder push rodMITSUBISHI genuine grease
Part No. 0101011
ON-VEHICLE SERVICE

CLUTCH PEDAL INSPECTION AND
ADJUSTMENT
1. Turn up the carpet, etc. under the clutch pedal.
2. Measure the clutch pedal height.
Standard value (A): 163.5 – 166.5 mm
3. If the height of the clutch pedal is outside the standard
value, loosen the locking nut and adjust the pedal height
to the standard value using the adjusting bolt or push
rod.
Clutch pedal height
A
Setting nutAdjusting bolt
Locking
nut
13 Nm

CLUTCH – On-vehicle Service21A-3
4. Measure the clutch pedal play.
Standard value (B): 1 – 3 mm
5. If the clutch pedal play is not within the standard value,
loosen the setting nut and move the push rod to adjust.
Caution
Do not push in the master cylinder push rod at this
time.
6. After completing the adjustments, confirm that the clutch
pedal free play (measured at the face of the pedal pad)
and the distance between the clutch pedal (the face of
the pedal pad) and the toeboard when the clutch is
disengaged are within the standard value ranges.
Standard value (C): 6–13 mm
Standard value (D): 85 mm or more
7. If the clutch pedal free play and the distance between
the clutch pedal and the toeboard when the clutch is
disengaged do not agree with the standard values, it
is probably the result of either air in the hydraulic system
or a faulty master cylinder or clutch. Bleed the air, or
disassembly and inspect the master cylinder or clutch.
8. Turn back the carpet, etc.
BLEEDING
Specified fluid: Brake fluid DOT 3 or DOT 4
Caution
Use the specified brake fluid. Avoid using a mixture of
the specified fluid and other fluid.
Clutch pedal clevis pin play
B
Clutch pedal free play
Distance between the clutch pedal and the
toeboard when the clutch is disengagedC
D

CLUTCH – Clutch Pedal21A-4
CLUTCH PEDAL
REMOVAL AND INSTALLATION
Post-installation Operation
Clutch Pedal Adjustment (Refer to P. 21A-2.)
13 Nm
1
14 13
12 2
818
911
3
10
13 Nm
29 Nm
19
64
7
12 Nm
5
517
15 16 12
Removal steps
1. Clutch master cylinder installation
nut
2. Master cylinder member bracket
installation bolt
3. Clevis pin
4. Pedal support member and clutch
pedal assembly
5. Split pin
6. Clevis pin
7. Bushing
8. Rod A9. Rod B
10. Turn over spring
11. Bolt
12. Bushing
13. Pipe
14. Clutch pedal
15. Pedal pad
16. Stopper
17. Adjusting bolt
18. Locking nut
19. Pedal support member

CLUTCH – Clutch Control21A-5
CLUTCH CONTROL
REMOVAL AND INSTALLATION
Pre-removal Operation

Clutch Fluid Draining

Air Cleaner RemovalPost-installation Operation

Air Cleaner Installation

Clutch Fluid Supplying

Clutch Line Bleeding (Refer to P.21A-3.)

Clutch Pedal Adjustment (Refer to P. 21A-2.)
15 Nm
Specified grease:
MITSUBISHI genuine grease
Part No. 0101011
56 8
7
6
1
4
13 Nm
15 Nm
15 Nm
19 Nm
5
15 Nm
3
2
7
Release
fork
Clutch master cylinder removal
steps
1. Clevis pin
2. Clutch pipe connection
3. Clutch master cylinder
Clutch release cylinder removal
steps
4. Clutch pipe connection
5. Clutch release cylinderClutch line removal steps
6. Clutch pipe
7. Hose clip
8. Clutch hose

CLUTCH – Clutch Control21A-6
DISASSEMBLY AND REASSEMBLY
CLUTCH MASTER CYLINDER
13 Nm
6 7
3
1
2
Piston repair kitClutch fluid:
Brake fluid DOT3 or DOT4
Grease: Rubber grease
2 5
4
413
44 8
Disassembly steps
1. Piston stopper ring
A2. Push rod assembly
3. Boot
4. Piston assembly
5. Reservoir cap
6. Spring pin
7. Reservoir tank
8. Clutch master cylinder bodyCaution
Do not disassemble piston assembly.
INSTALLATION SERVICE POINT
APUSH ROD ASSEMBLY INSTALLATION
Set the length of the push rod assembly to the shown
dimension to make the adjustment of the clutch pedal easier.
122.5 mm

22B-1
MANUAL
TRANSMISSION
OVERHAUL
CONTENTS
GENERAL 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outline of Change 2. . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS 3. . . . . . . . . . . . . . . . . . . . . . . . TRANSMISSION 4. . . . . . . . . . . . . . . . . . . . . . . . .
CLUTCH HOUSING 5. . . . . . . . . . . . . . . . . . . . . .
REVERSE IDLER GEAR 6. . . . . . . . . . . . . . . . .

MANUAL TRANSMISSION OVERHAUL – General22B-2
GENERAL
OUTLINE OF CHANGE
Of the newly introduced transmission model, the service procedures for the following unit sections are
described.

Transmission

Clutch housing

Reverse idler gear
