MITSUBISHI LANCER EVOLUTION VI 1999 Workshop Manual

CIRCUIT DIAGRAMS –
Oil Pressure Warning Lamp and
Seat Belt Warning LampC-57
OIL PRESSURE WARNING LAMP AND SEAT BELT WARNING LAMP

CIRCUIT DIAGRAMS –
Central Door Locking System
C-58
CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS –
Central Door Locking System
C-59

CIRCUIT DIAGRAMS –
Central Door Locking System
C-60
CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS –
Central Door Locking System
C-61

CIRCUIT DIAGRAMS –
Central Door Locking System
C-62
CENTRAL DOOR LOCKING SYSTEM
(CONTINUED)

CIRCUIT DIAGRAMS –
Central Door Locking System
C-63

CIRCUIT DIAGRAM – Heater and Air ConditionerC-64
HEATER AND AIR CONDITIONER

CIRCUIT DIAGRAM – Heater and Air ConditionerC-65

CIRCUIT DIAGRAM – Heater and Air ConditionerC-66
HEATER AND AIR CONDITIONER (CONTINUED)
