Diagrams MITSUBISHI LANCER IX 2006 Service Manual

METER AND GAUGE
CIRCUIT DIAGRAMS90-192
METER AND GAUGE
M1901003502224
IGNITION
SWITCH (IG1)
COMBINATION
METER
CONTROL CIRCUIT
ENGINE
COOLANT
TEMPERATURE
GAUGE UNITFUEL
GAUGE
UNIT
NOTE
: SEDAN
: WAGON
: M/T
: A/T
: 4G1
: 4G6
FRONT
SIDE ·TAIL LAMP, POSITION LAMP,
LICENCE PLATE LAMP AND
LIGHTING MONITOR BUZZER
·TURN-SIGNAL LAMP AND
HAZARD WARNING LAMP
·WINDSHIELD WIPER
AND WASHER ·FRONT FOG LAMP
·HEADLAMP
·REAR FOG LAMP
·REAR WIPER AND WASHER

METER AND GAUGE
CIRCUIT DIAGRAMS90-193
DIAGNOSIS
CONNECTOR
RELAY
BOXBATTERYFRONT-ECU
TAIL
LAMP RELAY
TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER
ODO/TRIP
ENGINE
SPEED
DETECTION
CONNECTOR ENGINE-
ECU
ENGINE-
A/T-ECU
RHEOSTAT ·TAIL LAMP, POSITION LAMP,
LICENCE PLATE LAMP AND
LIGHTING MONITOR BUZZER
·WINDSHIELD WIPER
AND WASHER
WINDSHIELD WIPER
AND WASHER ·FRONT FOG LAMP
·HEADLAMP
·HEADLAMP
LEVELLING SYSTEM
·REAR FOG LAMP

METER AND GAUGE
CIRCUIT DIAGRAMS90-194
METER AND GAUGE (CONTINUED)
VEHICLE
SPEED
SENSOR
ENGINE
CONTROL
SYSTEMINVECS-II 4A/T
ENGINE-A/T-ECU
OUTPUT
SHAFT
SPEED
SENSORA/T
CONTROL
RELAY
INVECS-II 4A/T
(FUSE )2
COMBINATION
METER(FUSE )3
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White
Y : Yellow SB : Sky blue BR : Brown O : Orange
GR : Grey R : Red P : Pink V : Violet PU : Purple

METER AND GAUGE
CIRCUIT DIAGRAMS90-195
NOTES

FUEL WARNING LAMP, OIL PRESSURE WARNING LAMP AND BRAKE WARNING LAMP
CIRCUIT DIAGRAMS90-196
FUEL WARNING LAMP, OIL PRESSURE WARNING LAMP
AND BRAKE WARNING LAMP
FUEL WARNING LAMP, OIL PRESSURE WARNING LAMP AND BRAKE WARNING
LAMP
M1901018700444
BATTERYIGNITION
SWITCH (IG1)
RELAY
BOX
CONTROL CIRCUIT
·FRONT
FOG LAMP
·TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER ·HEADLAMP
·WINDSHIELD
WIPER AND
WASHER ·REAR
FOG LAMP ·HEADLAMP
LEVELLING
SYSTEM
FUEL
TANK
GAUGE
UNIT
·HEADLAMP
WASHER
NOTE: SEDAN
: WAGON

FUEL WARNING LAMP, OIL PRESSURE WARNING LAMP AND BRAKE WARNING LAMP
CIRCUIT DIAGRAMS90-197
COMBINATION
METER
BRAKE
FLUID
LEVEL
INDICATOR
SWITCH
ENGINE OIL
PRESSURE
SWITCHPARKING
BRAKE
SWITCH
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Grey R : Red P : Pink V : Violet PU : Purple

FUEL WARNING LAMP, OIL PRESSURE WARNING LAMP AND BRAKE WARNING LAMP
CIRCUIT DIAGRAMS90-198
FUEL WARNING LAMP, OIL PRESSURE
WARNING LAMP AND BRAKE WARNING
LAMP
M1901018700455
RELAY
BOX BATTERYIGNITION
SWITCH (IG1)
CONTROL CIRCUIT·FRONT
FOG LAMP
·TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER ·HEADLAMP
·WINDSHIELD
WIPER AND
WASHER ·REAR
FOG LAMP
·TURN-SIGNAL LAMP
AND HAZARD
WARNING LAMP
FUEL
TANK
GAUGE
UNIT
·REAR WIPER
AND WASHER
·FRONT
FOG LAMP
·TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER ·HEADLAMP
·WINDSHIELD
WIPER AND
WASHER ·REAR
FOG LAMP ·HEADLAMP
LEVELLING
SYSTEM

FUEL WARNING LAMP, OIL PRESSURE WARNING LAMP AND BRAKE WARNING LAMP
CIRCUIT DIAGRAMS90-199
COMBINATION
METER
BRAKE
FLUID
LEVEL
INDICATOR
SWITCH
ENGINE OIL
PRESSURE
SWITCHPARKING
BRAKE
SWITCH
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Grey R : Red P : Pink V : Violet PU : Purple

POWER WINDOWS
CIRCUIT DIAGRAMS90-200
POWER WINDOWS
M1901004602127
ETACS-ECUIGNITION
SWITCH (IG1) BATTERY
POWER
SOURCE FUSIBLE
LINK
1
FRONT SIDE
DOOR
SWITCH
(FRONT: LH) DIAGNOSIS
CONNECTOR
·FRONT
FOG LAMP
·HEADLAMP
·HEADLAMP LEVELLING
SYSTEM
·HEADLAMP WASHER
·REAR FOG LAMP
·TAIL LAMP,
POSITION LAMP,
LICENCE PLATE LAMP
AND LIGHTING
MONITOR BUZZER
·WINDSHIELD
WIPER AND WASHER
J/B SIDE
RELAY
BOX

POWER WINDOWS
CIRCUIT DIAGRAMS90-201
HALL IC HALL IC FUSIBLE
LINK
5
FRONT
POWER WINDOW
MOTOR
(RH) POWER
WINDOW
RELAYCPUFRONT
POWER WINDOW
SUB SWITCH
(RH)
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White
Y : Yellow SB : Sky blue BR : Brown O : Orange
GR : Grey R : Red P : Pink V : Violet PU : Purple
