MITSUBISHI LANCER RALLIART 2012 8.G Owners Handbook

9NAVIGATION SYSTEM
1 Press the [MENU] key to display.

2 Touch [Address/Intersection].

6 Input the street name

3
Touch the “State” and “City” button

7 Touch [List] to select a street from the
list

4
Input the “State” and “City” name

8 Touch House # or intersection 9 Touch [Set]

5
Touch [All Streets]
5
8
8
2 3
3
Searching for a Location by Address / Location

10TECHNOLOGY
Multi-information Meter Switch (INFO Button) Keyless Entry System
[F.A.S.T. Key][Normal Key]
LOCK
Press: Once – Lock all doors
UNLOCK
Press: Once – Unlock driver door
Twice – Unlock all doors
TRUNK (except Sportback)
Press twice to open trunk lid.
PANIC
Press and hold. Press any button
to turn off panic.
While carrying the F.A.S.T.
key, press the driver’s or
front passenger’s door
lock/unlock switch A .
Change element by
pushing the INFO
button: Warnings,
Odometer/Tripmeter,
Service reminder,
Engine coolant
temperature, Average
and momentary fuel
consumption, Driving
range and average
speed, etc. Pulling
up the emergency
brake offers additional
choices.
ECO Driving
When the ECO indicator light
is on, your current driving
style supports good fuel
economy.
Lancer and
Lancer Sportback
Multi-information meter
A
Tire Pressure Monitoring System (TPMS)
The Tire Pressure Monitoring System light illuminates when one
or more of your tires is significantly underinflated. Please note
that changes in the outside temperature may decrease tire
pressure causing the TPMS light to turn on. If the TPMS light
remains illuminated, check your tire pressure.
Warning light
illuminates when tire pressure is too low. Contact MITSUBISHI
dealer. (May be a
TPMS system issue or malfunction.)

11Bluetooth® Operation with FUSE Hands-free Link System™ (if so equipped)
Making a call by using the telephone number:
1. Press A button and Say “Dial.”
2. The voice guide says “Number please.”
3. Say the telephone number “XXX•••••••.”
4. The voice guide says “Dialing .”
Making a call using a phonebook:
1. Press A button and Say “Call.”
2. After the voice guide says “Name please.”
Say the name you want to call “XXX•••••••.”
3. If there is only 1 match, the voice guide says “Calling
” and then the system will dial the telephone
number.
Receiving calls:
1. If an incoming phone call is received while the ignition
switch is in the “ACC” or “ON” position, with the audio
system OFF, the audio system automatically turns ON.
2. Press B button.
Hanging up a call:
1. Press C button.
To import a devices phonebook:
1. Press A button and Say “Phonebook.”
2. The voice guide will say “Select one of the following: new
entry, edit number, edit name, list names, delete, erase all,
or import contact.” Say “Import contact.”
3. The voice guide will say “Would you like to import a single
entry or all contact?” Say “All contacts.”
4. The voice guide will say “Importing the contact list
from the mobile phonebook. This may take several
minutes to complete. Would you like to continue?”
Answer “Yes.”
5. When the import is complete, the voice guide
will say “Import complete.”
Tip on Getting Started:
Before using FUSE for the first time, press the SPEECH button and
say “Help”. This will walk you through some tips and help set-up your
recognition profile.
For a list of compatible Bluetooth® devices please go to
http://www.mitsubishicars.com/MMNA/jsp/owners-site/technology-
features.do
If you are having difficulties operating your
phone or connecting to the system, please call
Mitsubishi Handsfree at (888) 702-4100.
SPEECH button:
Change to voice
recognition
PICK-UP button:
Answer an incoming call
HANG-UP button
End a call or voice
recognition
A
B
C
A
B
C
To pair a Bluetooth® enabled device:
1.
Park your vehicle in a safe location.
2. Press A button and Say “Setup.”
3. Say “Pairing Options.”
4. The voice guide says: “Select one of the following: pair, edit, delete, or list.”
5. Say “Pair.”
6. The voice guide says “Please say a 4-digit pairing code.”
7. Say a 4-digit number “XXXX.”
8. When the confirmation function is on, the system will
confirm whether the number said is acceptable. Answer
“Yes.”
9. The voice guide says “Start pairing procedure on the device. See the device manual for instructions.” Enter in the
Bluetooth® device the 4-digit number you have registered in
step 8.

12FAQ ’ s
Q: What should I do when my engine is hard to start?
A: Pressing on the accelerator pedal about half way down while cranking the engine may make it easier to start. When the engine
starts, release your foot from the accelerator pedal.
Q: Is my phone compatible with the factory Mitsubishi Bluetooth® Hands Free System?
A: Check the phone approval list, www.mitsubishicars.com/owners to see if the phone is Bluetooth® approved.
Q. Why doesn’t my device (USB, iPhone, Bluetooth® Audio, etc.) work?
A: You need to press the Mode button to select the appropriate device you want to use.
Q: How do I use Bluetooth® Audio (if equipped)?
A: Turn the Audio System power on. Press the CD button several times until B (Bluetooth®) is shown. Connect your Bluetooth® device
via pairing mode. Playback will start automatically.
Q: How do I transfer calls from Bluetooth® back to my mobile phone’s handset?
A: While on the call, press the speech button on your steering wheel and, once prompted, say “Transfer Call.”
Q: Why does the FUSE Hands-free Link System™ take so long to upload my music from my audio music device?
A: The Mitsubishi system can read multiple device structures in order to catalog the music files for easy playing and listening.
Depending on the amount of music you have on your device, this may take a few minutes.
Q: What are the different ways of playing music from my portable music player through the stereo system in my vehicle, when
equipped with the FUSE Hands-free Link System™?
A: There are three ways of playing music through your vehicle’s sound system.
• USB port - The FUSE system will find the songs in your device and categorize them according to Artist, Album, and Genre. Then you can have the FUSE system find and play the song in your device that you prefer without physically searching your device.
This is done via voice commands.
• Bluetooth® Streaming - Once your device is paired to the FUSE system, you can stream music from your device through the FUSE system to your vehicles sound system. No wires or cords. Your music stops and restarts at the same song when you exit
and when you re-enter the vehicle. Voice commands are not available.
• RCA auxiliary ports - Music can be played through a vehicles stereo system via the head phone port of your music device (An RCA to mini headphone jack adapter cable will be needed) Voice command is not available.
Q: Why can’t I control the music track selection via voice commands while Bluetooth® streaming?
A: The Mitsubishi system uses AVRCP 1.3 (Audio Video Programing System) which does not support this function.
Q: My Lancer is equipped with “Micron Air Filtration”. Where is the filter located and does it need servicing?
A: The micron air filter is a small filter element which is located in the HVAC box just behind the glove box.
The filter should be inspected frequently for debris. The filter works well at filtering incoming air however the filter
will clog and lead to reduced outlet air volume if not serviced on a regular basis.

13
Q: My Lancer has two 12V accessory outlets. What devices can be plugged into these outlets?
A: Both of these outlets are protected with 15 amp fuses. (The DE Model only has one 12V accessory outlet.) Always check the current
draw rating of any device prior to use in the vehicle. If the device is rated above 12 amps, this could lead to circuit overload and the
electrical fuse opening (no current flow).
Q: I only have one remote for the remote start system on my Lancer. Can I get a second one?
A: No. Only one remote can be programmed per vehicle for security reasons.
Q: How can I get the MPG stated on the window sticker?
A: Vehicle driving styles will greatly affect MPG. Avoid sudden abrupt starts from a stop and let the vehicle coast to the traffic light. Both of these styles will increase mileage and reduce brake lining wear.
• Vehicles are designed to achieve the best fuel mileage when they are driven at the speed limits on the freeway. Avoid driving over 65 mph.
• Under inflated tires will increase rolling resistance and will reduce fuel mileage. Check tire pressure frequently to increase miles per gallon. Proper tire pressure also ensures optimum tire performance (including tire wear.)
Q: How does the Navigation System choose a certain route?
A: The system takes into account traffic conditions, road types, distance and road width to recommend the route.
Q: Why does my Anti-Lock Braking System (ABS) make a noise?
A: Each time your vehicle is started and driven a short distance, you will hear the sound of the ABS motor operating from the right front
engine compartment. This is the normal sound the Anti-Lock Braking System makes when performing a self check.
Q: Why do my Rain Sensing Windshield Wipers operate on their own when it’s not raining?
A: • When the lever is in the AUTO position, the rain sensor detects rain or snow and automatically turns on the wipers.
• The wipers may automatically operate when things such as insects or foreign objects are affixed to the windshield on top of the rain sensor or when the windshield is frosted over.
• To stop the wipers, place the lever in the OFF position.
Q: Why does my check engine light come on after I put gas in my car?
A: There are many reasons why your check engine light may illuminate. Before calling your dealership, make sure the
fuel cap is fully engaged and you have heard three clicks when tightening it. After checking and hearing three clicks and
driving for a while, if the light is still on, contact your dealership.
Q: How do I use the emergency key when the F.A.S.T. key battery or vehicle battery is run down?
A: Remove the emergency key from the F.A.S.T key fob and manually unlock the door. Once inside the vehicle remove the
ignition switch cover by pressing the release buttons on the top and bottom of the ignition switch cover. Once the
ignition switch cover is removed insert the emergency key into the ignition switch then re-insert (backwards) the
F.A.S.T. key fob onto the emergency key. Once the F.A.S.T. key fob is re-inserted (backwards) turn the emergency
key to start the engine.
FAQ ’ s
