Driver’s View
1 headlights and
f og lights .................. Page 4
2 Paddle shifters ......... Page 5
3 w indshield w iper
l ever ............................. Page 4
4 side
mirror
a djustment
................. Page 2
5 a udio Remote
c ontrol s witch ......... Page 8
6 cruise c ontrol .........Page 5
7 bluetooth®
c ontrols ....................... Page 10, 12
8 a udio s ystem ........... Page 8
9 air c onditioning ...... Page 4
10 navigation
system ......................... Page 6 - 7
11 Usb Port ..................... Page 8

7AUDIO SYSTEM
1. Press the LOAD button F briefly.
2. The autochanger will show “WAIT” on the display and start
making itself ready for disc loading.
3. When the autochanger is ready for disc loading, the LOAD
indicator will illuminate and the display will show “LOAD DISC
No. (1-6)”.
4. When a disc is inserted into the CD slot, the disc will begin to
play.
NOTE: Please refer to Comfort Controls in your Owner’s Manual
for more detailed information on how to use your audio
system.
NOTE: You can select desired tracks from
the “Playlist”, “Artists”, “Album” or
“Songs” menus stored in your iPod or
desired folder in your USB memory
device. Turn the FOLDER knob D to
the desired location then press it in to
select your folder.
USB and iPod Input (if -equipped)
Loading a CD




Audio Remote
Control Switch (if equipped)VOLUME UP
DOWNSEEK
Change
station or
track
MODE
Change
the audio
source
1. Park your vehicle in a safe place and turn the ignition to the
lock position.
2. Connect the cable
 (cable is not included with the vehicle)
to the USB memory device
 or the Dock connector  to
the iPod
.
3. Open the cover
 in the glove compartment. Connect the
cable
 to the USB input terminal .
4. Turn the ignition switch to the “ACC” position. Press A to
turn on the audio system.
5. Press the CD button B several times to switch to the USB
mode. The input mode changes as follows:
CD
 USB  Bluetooth® (if equipped)
6. Depending on your USB device, it may take longer for
playback to start.
7. Once the device is selected, playback starts.
AF
CB
D
To enter frequencies
into the memory
(AM/FM/SAT)
1. Press A to turn on
the audio system.
2. Press B to select
CD.
3. Press C to select
the desired band
(AM/FM/SAT).
4. Turn D to the desired frequency you wish to keep in the memory.
5. Press one of the Memory select buttons E (1-6) until it beeps.
Your station is now stored in that location.
E

11Bluetooth® Operation with FUSE Hands-free Link System™ (if so equipped)
Making a call by using the telephone number:
1. Press A button and Say “Dial.”
2. The voice guide says “Number please.”
3. Say the telephone number “XXX•••••••.”
4. The voice guide says “Dialing .”
Making a call using a phonebook:
1. Press A button and Say “Call.”
2. After the voice guide says “Name please.”
Say the name you want to call “XXX•••••••.”
3. If there is only 1 match, the voice guide says “Calling
” and then the system will dial the telephone
number.
Receiving calls:
1. If an incoming phone call is received while the ignition
switch is in the “ACC” or “ON” position, with the audio
system OFF, the audio system automatically turns ON.
2. Press B button.
Hanging up a call:
1. Press C button.
To import a devices phonebook:
1. Press A button and Say “Phonebook.”
2. The voice guide will say “Select one of the following: new
entry, edit number, edit name, list names, delete, erase all,
or import contact.” Say “Import contact.”
3. The voice guide will say “Would you like to import a single
entry or all contact?” Say “All contacts.”
4. The voice guide will say “Importing the contact list
from the mobile phonebook. This may take several
minutes to complete. Would you like to continue?”
Answer “Yes.”
5. When the import is complete, the voice guide
will say “Import complete.”
Tip on Getting Started:
Before using FUSE for the first time, press the SPEECH button and
say “Help”. This will walk you through some tips and help set-up your
recognition profile.
For a list of compatible Bluetooth® devices please go to
http://www.mitsubishicars.com/MMNA/jsp/owners-site/technology-
features.do
If you are having difficulties operating your
phone or connecting to the system, please call
Mitsubishi Handsfree at (888) 702-4100.
SPEECH button:
Change to voice
recognition
PICK-UP button:
Answer an incoming call
HANG-UP button
End a call or voice
recognition
A
B
C
A
B
C
To pair a Bluetooth® enabled device:
1.
Park your vehicle in a safe location.
2. Press A button and Say “Setup.”
3. Say “Pairing Options.”
4. The voice guide says: “Select one of the following: pair, edit, delete, or list.”
5. Say “Pair.”
6. The voice guide says “Please say a 4-digit pairing code.”
7. Say a 4-digit number “XXXX.”
8. When the confirmation function is on, the system will
confirm whether the number said is acceptable. Answer
“Yes.”
9. The voice guide says “Start pairing procedure on the device. See the device manual for instructions.” Enter in the
Bluetooth® device the 4-digit number you have registered in
step 8.

12FAQ ’ s
Q: What should I do when my engine is hard to start?
A: Pressing on the accelerator pedal about half way down while cranking the engine may make it easier to start. When the engine
starts, release your foot from the accelerator pedal.
Q: Is my phone compatible with the factory Mitsubishi Bluetooth® Hands Free System?
A: Check the phone approval list, www.mitsubishicars.com/owners to see if the phone is Bluetooth® approved.
Q. Why doesn’t my device (USB, iPhone, Bluetooth® Audio, etc.) work?
A: You need to press the Mode button to select the appropriate device you want to use.
Q: How do I use Bluetooth® Audio (if equipped)?
A: Turn the Audio System power on. Press the CD button several times until B (Bluetooth®) is shown. Connect your Bluetooth® device
via pairing mode. Playback will start automatically.
Q: How do I transfer calls from Bluetooth® back to my mobile phone’s handset?
A: While on the call, press the speech button on your steering wheel and, once prompted, say “Transfer Call.”
Q: Why does the FUSE Hands-free Link System™ take so long to upload my music from my audio music device?
A: The Mitsubishi system can read multiple device structures in order to catalog the music files for easy playing and listening.
Depending on the amount of music you have on your device, this may take a few minutes.
Q: What are the different ways of playing music from my portable music player through the stereo system in my vehicle, when
equipped with the FUSE Hands-free Link System™?
A: There are three ways of playing music through your vehicle’s sound system.
• USB port - The FUSE system will find the songs in your device and categorize them according to Artist, Album, and Genre. Then you can have the FUSE system find and play the song in your device that you prefer without physically searching your device.
This is done via voice commands.
• Bluetooth® Streaming - Once your device is paired to the FUSE system, you can stream music from your device through the FUSE system to your vehicles sound system. No wires or cords. Your music stops and restarts at the same song when you exit
and when you re-enter the vehicle. Voice commands are not available.
• RCA auxiliary ports - Music can be played through a vehicles stereo system via the head phone port of your music device (An RCA to mini headphone jack adapter cable will be needed) Voice command is not available.
Q: Why can’t I control the music track selection via voice commands while Bluetooth® streaming?
A: The Mitsubishi system uses AVRCP 1.3 (Audio Video Programing System) which does not support this function.
Q: My Lancer is equipped with “Micron Air Filtration”. Where is the filter located and does it need servicing?
A: The micron air filter is a small filter element which is located in the HVAC box just behind the glove box.
The filter should be inspected frequently for debris. The filter works well at filtering incoming air however the filter
will clog and lead to reduced outlet air volume if not serviced on a regular basis.
