USB input terminal (if so equipped) 5-184 Features and controls
5
The following explains how to connect and remove a USB memory device or iPod. Refer to the following sections for details on how to play music files:Refer to “Listen to Audio Files on a USB Device” on page 7-49.
N00566800074
1. Park your vehicle in a safe place and turn the ignition switch to the “LOCK” posi- tion. 2. Open the USB input terminal cover (A) inthe glove compartment.
3. Connect a commercially available USB connector cable (C) to the USB memory device (B). 4. Connect the USB connector cable (C) to the USB input terminal (D).
5. To remove the USB connector cable, turn the ignition switch to the “LOCK” posi- tion first and perform the installation steps in reverse.
N00566900020
1. Park your vehicle in a safe place and turnthe ignition switch to the “LOCK” posi- tion.
* :“iPod” is a registered trademark of Apple Inc. in the United States and other coun- tries.
How to connect a USB memory device

WA R N I N G An open glove compartment door can cause a serious injury or death to the front passenger in an accident, even if the pas- senger is wearing his/her seat belt. Always keep the glove compartment door closedwhen driving.NOTE
 Do not connect the USB memory device to the USB input terminal directly.The USB memory device may be damaged.  When closing the glove compartment, be careful not to trap the USB connector cable.
How to connect an iPod

USB input terminal (if so equipped)
Features and controls 5-185
5
2. Open the USB input terminal cover (A) in the glove compartment. 3. Connect the Dock connector (C) to the iPod (B).
4. Connect the Dock connector (C) to the USB input terminal (D). 5. To remove the Dock connector, turn the ignition switch to the “LOCK” positionfirst and perform the installation steps in reverse.
N00567000028 N00567100087
Devices of the following types can be con- nected. * : “iPod touch,” “iPod classic,” “iPod” and “iPod nano” are registered trademarks of
NOTE
 Use a genuine Dock connector from Apple Inc.
WA R N I N G An open glove compartment door can cause a serious injury or death to the front passenger in an accident, even if the pas-senger is wearing his/her seat belt. Always keep the glove compartment door closed when driving. NOTE
 When closing the glove compartment, be careful not to trap the connector cable.
Types of connectable devices and supported file specifica- tions

Device types

Model name
Condition
USB memory device
Storage capacity of 256 Mbytes or more
iPod touch
*
F/W Ver.1.1.1 or later
iPod classic
*
F/W Ver.1.0 or later
iPod (fifth genera- tion)
*
F/W Ver.1.2.2 or later
iPod nano (fifth gen- eration)
*
F/W Ver.1.2 or later
iPod nano (second generation)
*
F/W Ver.1.1.2 or later
Models other than USB memory devices and iPods
Digital audio player supporting mass storage class

Sun visors 5-186 Features and controls
5
Apple Inc. in the United States and other countries.
N00567200017
You can play music files of the following specifications that are saved in a USB mem- ory device or other device supporting massstorage class.
N00524600308
Fold the sun visor downward (1) to reduce front glare while driving. To reduce side glare, turn the visor to the side (2).
The vanity mirrors are located on the back of the sun visors.
NOTE
 Depending on the type of the USB memory device or other device connected, the con- nected device may not function properly orthe available functions may be limited.  It is recommended to use an iPod with firm- ware updated to the latest version.  You can charge your iPod by connecting it to the USB input terminal when the ignition switch is in the “ACC” or “ON” position.  Do not keep your USB memory device or iPod in your vehicle.  It is recommended that you back up the files in case of data damage.  Do not connect to the USB input terminal any device (hard disk, card reader, memory reader, etc.) other than the connectabledevices specified in the previous section. The device and/or data may be damaged. If any of these devices
was connected by mis-
take, remove it after turning the ignition switch to the “LOCK” position.
File specifications

Item
Condition
File format
MP3, WMA, AAC, WAV
Maximum number of levels(including the root)
Level 8
Number of folders 700 Number of files 65,535Sun visors
Vanity mirror

12 V power outlet
Features and controls 5-187
5
Cards can be slipped into the front (A) of the lid of the vanity mirror.
N00525000556
12 V power outlets are located in front of the floor console (Type 1, Type 2) and inside of the floor console box (Type 3). The accessory can be operated when the igni- tion switch is in the “
ON” or “ACC” position.
To use a “plug-in” type accessory, pull out the plug, then insert the plug in the socket.
The accessory can be operated when the igni- tion switch is in any position. To use a “plug-in” type accessory, open thecover, then insert the plug in the socket.
Card holder 12 V power outlet
CAUTION Be aware that using electronic equipment with the engine off may run the batterydown. When the 12 V power outlet is not in use, be sure to put on the plug or close the 12 V power outlet cover. This will prevent the 12 V power outlet from becoming dirty and pos-sibly short-circuiting.
NOTE
 If your vehicle is equipped with two 12 V power outlets, both power outlets can be used simultaneously.CAUTION Be sure to use a “plug-in” type accessory operating at 12 V and 120 W or less. When using two 12 V power outlets or 12 V power outlet and cigarette lighter simultane-ously, make sure that the total power con- sumption of these does not exceed 120 W at 12 V.
Type 1, Type 2
Ty p e 3
(if so equipped)
Type 1Type 2

Interior lights 5-188 Features and controls
5
N00525300461
N00525801261
The dome light can be turned on by sliding the dome light switch.
Interior lights 1- Dome light (Rear) (if so equipped)
 P.5-189
2- Dome light (Front)/Reading lights (if
so equipped)
P.5-188
Dome light (Front)/Reading lights
(if so equipped)
Dome light (Front)

1- (DOOR) The dome light comes on when any door is opened. When all
the doors are closed,
the dome light illuminates for about 30 seconds then goes off. However, the light goes off immediately if: The door is closed while the ignition switch is in the “ON” position.
 The driver’s door is closed after all the other doors are closed while the lockknob of the driver’s door is in the lock position.  The door is closed and the power door lock switch is used to lock the doors.  In vehicles equipped with the keyless entry system, the keyless entry systemremote control transmitter is used to lock the doors.  In vehicles equipped with the F.A.S.T.-key, the doors are lockedusing the F.A.S.T.-key.NOTE
 When the engine is started using the key while the doors are closed, if you remove the key, the dome light will illuminate for about 30 seconds before going off.  When the engine is started using the F.A.S.T.-key while the doors are closed, ifthe ignition switch is moved to the “LOCK” position, the dome light will illuminate for about 30 seconds before going off.  The time until the light goes off can be adjusted. See your authorized Mitsubishi Motors dealer for details.2- (OFF) The dome light goes off.

Interior lights
Features and controls 5-189
5
N00553800067
Regardless of the dome light switch position, when you press the lens, the light on the sidethat is pressed illuminates; when you press the lens again, the light goes off.
N00525401485
The dome light can be turned on by sliding the dome light switch.
N00526301465
If any of the interior lights are left on with theignition switch in the “LOCK” position, the lights go off automatically after about 30 minutes.
Reading lights

Dome light (Rear)
(if so equipped)
1- (ON) The dome light comes on. 2- (
)
The dome light comes on when any dooris opened. When all the doors are closed, the dome light illuminates for about 30 seconds then goes off. However, the lightgoes off immediately if: The door is closed while the ignition switch is in the “ON” position.  The driver’s door is closed after all the other doors are closed while the lock knob of the driver’s door is in the lock position. The door is closed and the power door lock switch is used to lock the doors. In vehicles equipped with the keyless entry system, the keyless entry sys- tem remote control transmitter is usedto lock the doors.
 In vehicles equipped with the F.A.S.T.-key, the doors are lockedusing the F.A.S.T.-key.NOTE
 When the engine is started using the key while the doors are closed, if you remove the key, the dome light will illuminate for about30 seconds before going off.  When the engine is started using the F.A.S.T.-key while the doors are closed, if the ignition switch is moved to the “LOCK” position, the dome light will illuminate forabout 30 seconds before going off.  The time until the light goes off can be adjusted. See your authorized Mitsubishi Motors dealer for details.3- (OFF) The dome light goes off.
Interior light auto-cutout func- tion (dome light and other lights)

Storage spaces 5-190 Features and controls
5
The lights come on again if the ignition switch is turned to the “ON” or “ACC” posi- tion, any door or the trunk lid is opened and closed, or the keyless entry system orF.A.S.T.-key is operated.
N00526400485
[Except for RALLIART]
[RALLIART]
N00551500246
To open the glove compartment, pull the lever (A).
NOTE
 The interior light auto-cutout function can be deactivated. The time until the lights auto- matically go off can be adjusted. See yourauthorized Mitsubishi Motors dealer for details.
Storage spaces
CAUTION Never leave lighters, carbonated drink cans, or spectacles in the cabin when parking the vehicle in hot sunshine. The cabin will become extremely hot, so lighters and otherflammable items may catch fire and unopened drink cans (including beer cans) may rupture. The heat may also deform or crack plastic spectacle parts. Keep the lids of storage spaces closed while driving the vehicle. A lid or the contents of a storage space could otherwise cause injuriesduring a sudden stop.
NOTE
 Do not leave valuables in any storage space when leaving the vehicle.1- Floor console box (if so equipped)
 P.5-192
2- Front console tray (if so equipped)
 P.5-191
3- Front console boxes (if so equipped)
 P.5-191
4- Glove compartment
P.5-190
1- Luggage floor boxes
P.5-192
2- Floor console box
P.5-192
3- Front console tray (if so equipped)
 P.5-191
4- Front console boxes (if so equipped)
 P.5-191
5- Glove compartment
P.5-190
Glove compartment

Storage spaces
Features and controls 5-191
5
There is a card holder on the inside of the glove compartment.
N00547800017
The front console tray is on the front console part.
N00546401071
To open, push the lid.
WA R N I N G An open glove compartment door can cause a serious injury or death to the front passenger in an accident, even if the pas- senger is wearing his/her seat belt. Alwayskeep the glove compartment door closed when driving. NOTE
 The USB input terminal (if so equipped) is located in the glove compartment. For details, refer to “USB input terminal” on page 5-183.
Card holder
NOTE
 Up to 2 cards will fit in the card holder.
Front console tray
(if so equipped)
CAUTIONDo not use the front console tray as an ash- tray. This could cause a fire.
Front console boxes
(if so equipped)
Upper box

Cup holder 5-192 Features and controls
5
N00551600188
To open the floor console box, lift the release lever (A) and raise the lid.
The tissue holder (A) is located on the under- side of the floor console box lid.
N00552400066
The boxes for storing articles are located inside the luggage compartment. To use the boxes, remove the floor mat (A)and raise the lids (B).
N00527300351
The cup holder is located the middle of thefloor console. The cup holder is designed for holding cups or drink-cans securely.
Lower box

CAUTION Do not use the front console boxes as an ash- tray. This could cause a fire.
Floor console box with lid
(if so
equipped)
Tissue holder

Luggage floor boxes
(if so
equipped)Cup holder For the front seat

Bottle holder
Features and controls 5-193
5
To use the cup holder, open up the lid.
N00537000159
This cup holder is located
in the rear seat arm
rest (A).Pull the rear arm rest down to use the cup holder.
N00502800049
There are bottle holders located on both sidesof the front seats.
Ty p e 1 Ty p e 2
CAUTION Do not drink beverages while driving your vehicle. This is distracting and could cause an acci- dent.
For the rear seat
(if so equipped)
Bottle holder
CAUTION Do not drink beverages while driving your vehicle. This is distracting and could cause an accident. Vibration and shaking while driving may cause beverages to spill. Be very careful, as spilling hot beverages could cause burns.NOTE
 Make sure all lids ar
e tightly closed when
storing beverages that are in plastic bottles, etc.  Some beverages may not be stored, depend- ing on the size and shape of the plastic bot-tles, etc.
