NOTE: Idle mixture is computer controlled on fuel injected engines
and is nonadjustable. CO level specifications are not
available from manufacturer.
THROTTLE POSITION SENSOR (TPS)
TPS ADJUSTMENT
NOTE: Ensure basic idle speed is set to specification before
adjusting TPS. See BASIC IDLE SPEED under IDLE SPEED &
MIXTURE. Perform all adjustments with engine at normal
operating temperature, front wheels in straight-ahead
position, cooling fan and all accessories off, and
transmission in Park or Neutral.
TPS TEST APPLICATION
\
\
\
\
Application Test
1.5L
Colt, Colt 200,
Mirage & Summit ............. TEST NO. 1
1.6L
Mirage ....................... TEST NO. 2
1.8L
Eclipse ...................... TEST NO. 3
2.0L (VIN V)
Colt Vista & Galant .......... TEST NO. 1
2.0L (VIN R & U)
Galant ....................... TEST NO. 1
Eclipse ...................... TEST NO. 3
2.4L
Pickup & Ram-50 .............. TEST NO. 1
3.0L
Montero, Pickup & Ram-50 ..... TEST NO. 4
Stealth & 3000GT ............. TEST NO. 5
\
\
\
\
Test No. 1
1) Turn ignition on for more than 15 seconds. DO NOT start
engine. Turn ignition off. ISC plunger should be retracted fully.
2) Ensure ISC plunger is in fully retracted position.
Disconnect harness connector(s) from ISC motor. Turn ignition on. DO
NOT start engine.
3) Using digital voltmeter, backprobe terminal No. 19
(Green/White wire) and terminal No. 24 (Black or Green/Black wire) a\
t
Engine Control Unit (ECU) wiring harness connector. Note TPS output
voltage.
4) If output voltage is .48-.52 volt, go to step 6). If
output voltage is not .48-.52 volt, loosen TPS mounting screw(s) and
rotate TPS clockwise, or counterclockwise, until output voltage is
within specification. Tighten TPS mounting screws.
5) Turn ignition off. Reconnect harness connector(s) at ISC
motor. Start engine. Ensure engine idles within curb idle speed
specification.
6) Turn ignition off. Disconnect negative battery cable for
at least 15 seconds to clear diagnostic trouble code. Reconnect
negative battery cable. Operate engine at idle for about 5 minutes to
ensure engine idles smoothly.
Test No. 2
1) Turn ignition on. DO NOT start engine. Loosen throttle
Page 161 of 1333
\003
AN TI- L O CK B RAK E S A FE TY P R EC AU TIO NS
1991 M it s u bis h i M onte ro
GENERAL INFORMATION
Anti-Lock Brake Safety Precautions
* PLEASE READ THIS FIRST *
This article is intended for general information purposes
only. This information may not apply to all makes and models. If
vehicle is equipped with Anti-Lock Brake System (ABS), refer to
appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES section for
description, operation, depressurizing, testing, system bleeding,
trouble shooting and servicing of specific system.
WARNING: Failure to depressurize ABS could lead to physical injury.
ANTI-LOCK BRAKE SAFETY PRECAUTIONS
WARNING: Failure to depressurize ABS could lead to physical injury.
* NEVER open a bleeder valve or loosen a hydraulic line
while ABS is pressurized.
* NEVER disconnect or reconnect any electrical connectors
while ignition is on. Damage to ABS control unit may result.
* DO NOT attempt to bleed hyudarulic system without first
referring to the appropriate ANTI-LOCK BRAKE SYSTEM article
in the BRAKES section.
* Only use specially designed brake hoses/lines on ABS equipped
vehicles.
* DO NOT tap on speed sensor components (sensor, sensor rings).
Sensor rings must be pressed into hubs, NOT hammered into
hubs. Striking these components can cause demagnetization or
a loss of polarization, affecting the accuracy of the speed
signal returning to the ABS control unit.
* DO NOT mix tire sizes. Increasing the width, as long as tires
remain close to the original diameter, is acceptable. Rolling
diameter must be identical for all 4 tires. Some
manufacturers recommend tires of the same brand, style and
type. Failure to follow this precaution may cause inaccurate
wheel speed readings.
* DO NOT contaminate speed sensor components with grease. Only
use recommended coating, when system calls for an
anti-corrosion coating.
* When speed sensor components have been removed, ALWAYS check
sensor-to-ring air gaps when applicable. These specifications
can be found in each appropriate article.
* ONLY use rocommended brake fluids. DO NOT use silicone brake
fluids in an ABS equipped vehicle.
* When instlling transmittion devices (CB's, telephones, etc.)
on ABS equipped vehicles, DO NOT locate the antenna near the
ABS control unit (or any control unit).
* Disconnect all on-board computers, when using electric
welding equipment.
* DO NOT expose the ABS control unit to prolonged periods of
high heat (185
F/85 C for 2 hours is generally considered a
maximum limit).
Page 163 of 1333
2.0L (VIN R) DOHC ......................... 137 (9.6)
2.0L (VIN U) DOHC Turbo ................... 114 (8.0)
2.0L (VIN V) SOHC ......................... 119 (8.4)
2.4L (VIN W) SOHC ......................... 119 (8.4)
3.0L (VIN S) SOHC ......................... 119 (8.4)
3.0L (VIN B) DOHC ......................... 139 (9.8)
3.0L (VIN C) DOHC Turbo ................... 115 (8.1)
(1) - Maximum variation between cylinders 14 psi
(1.0 kg/cm
) \
\
\
\
\
\
Exhaust System Backpressure
Exhaust system can be checked with a vacuum or pressure
gauge. Remove O2 sensor or air injection check valve (if equipped).
Connect a 1-10 psi pressure gauge and run engine at 2500 RPM. If
exhaust system backpressure is greater than 1 3/4-2 psi, exhaust
system or catalytic converter is plugged. If a vacuum gauge is used,
connect vacuum gauge hose to intake manifold vacuum port and start
engine. Observe vacuum gauge. Open throttle part way and hold steady.
If vacuum gauge reading slowly drops after stabilizing, exhaust system
should be checked for a restriction.
FUEL PRESSURE
Basic diagnosis of fuel system should begin with determining
fuel system pressure.
FUEL INJECTED ENGINES
WARNING: ALWAYS relieve fuel pressure before disconnecting any fuel
injection-related component. DO NOT allow fuel to contact
engine or electrical components.
Fuel Pressure
1) On all models except Colt and Mirage, disconnect fuel pump
harness connector at fuel tank. On Colt and Mirage, remove rear seat
cushion to disconnect fuel pump harness connector.
2) On all models, start engine. Let engine run until it
stops. Turn ignition off. Disconnect negative battery terminal.
Connect fuel pump harness connector.
WARNING: Before disconnecting high pressure fuel hose at fuel delivery
pipe, cover fuel hose connection with a rag. Some residual
fuel pressure may still be in system.
3) On Galant 2.0L (DOHC), remove brace for access to high
pressure fuel delivery pipe. On all engines, disconnect high pressure
fuel hose at fuel delivery pipe.
4) Connect fuel pressure gauge with adapter between fuel
delivery pipe and high pressure hose. See Fig. 1. Connect negative
battery terminal. Connect battery voltage to fuel pump test terminal.
See FUEL PUMP TEST TERMINAL LOCATION table. Ensure no fuel leaks are
present. Disconnect battery voltage to fuel pump test terminal.
Page 165 of 1333
pump. If fuel pressure drops slowly, fuel injector is leaking or fuel
pressure regulator valve seat is leaking. Check for faulty fuel
injector or fuel pressure regulator. Repair as required.
11) When fuel pressure test is complete, repeat fuel pressure
release procedure in steps 1) and 2) before disconnecting fuel
pressure gauge. Install new "O" ring at end of high pressure hose.
Check for fuel leaks.
FUEL PUMP TEST TERMINAL LOCATION TABLE
\
\
\
\
\
\
\
Application Wire Color Location
Colt, Colt 200 ......... BLK/WHT .............. Center Of Firewall
Colt Vista ............. BLK/WHT ........ Right Center Of Firewall
Eclipse ................ BLK/WHT .......... Rear Of Battery Compt.
Galant ................. YEL/GRN ........... Left Rear Eng. Compt.
Mirage 1.5L ............ BLK/WHT .............. Center Of Firewall
Mirage 1.6L ............ BLK/BLU .............. Center Of Firewall
Montero .................. WHT .......... Right Center Of Firewall
Pickup ................. BLK/BLU ....... Right Side Of Eng. Compt.
Precis ................... YEL ............. Left Rear Eng. Compt.
Summit ................. BLK/WHT .............. Center Of Firewall
Ram-50 ................. BLK/BLU ....... Right Side Of Eng. Compt.
Stealth, 3000GT ........ BLK/BLU .......... Rear Of Battery Compt.
\
\
\
\
\
\
\
REGULATED FUEL PRESSURE TABLE \
\
\
\
\
\
\
At Idle At Idle
w/Vacuum w/o Vacuum
Application psi (kg/cm
) psi (kg/cm)
Non-Turbo .................. 38 (2.7) ....... 47-50 (3.3-3.5)
Turbo
Except Eclipse A/T ....... 27 (1.9) ....... 36-38 (2.5-2.7)
Eclipse A/T .............. 33 (2.3) ....... 36-38 (2.9-3.2)
\
\
\
\
\
\
\
Control Relay
Multipurpose relay switches power to vehicle sensors and
actuators including airflow sensor, crank angle sensor, idle speed
control, injectors and fuel pump. When ignition switch is turned to ON
position, ECU energizes coils controlling injectors, airflow sensor
and idle speed control. When ignition switch is turned to START
position, ECU energizes coils (through inhibitor switch on A/T models)\
to supply power to fuel pump. Relay failure will cause a no-start
condition. For testing procedure, see SYSTEM & COMPONENT TESTING
article.
IGNITION CHECKS
SPARK
Check for spark at coil wire (if applicable) and at each
spark plug wire using a high output spark tester. Check spark plug
wire resistance on suspect wires. For wire resistance specification,
see C - SPECIFICATIONS article in the ENGINE PERFORMANCE Section.
CRANK ANGLE SENSOR
For crank angle sensor testing procedure on all models except
Ram-50, Stealth, Eclipse, Laser, Pickup and 3000GT, see TEST NS-5:
Page 166 of 1333
TESTING CRANK ANGLE SENSOR CIRCUIT - G - TESTS W/CODES article in the
ENGINE PERFORMANCE section.
On Eclipse and Laser, see NS-4A: REPAIRING CRANK ANGLE SENSOR
in G - TESTS W/CODES - 1.8L article.
On Ram-50, Stealth, Pickup and 3000GT testing information not
available at time of publication.
DISTRIBUTORLESS IGNITION SYSTEM (DIS)
Ignition Coil Resistance (4-Cyl Vehicles Except Eclipse 2.0L)
1) Using a Digital Volt/Ohmmeter (DVOM), measure primary coi\
l
resistance between ignition coil connector terminals No. 2 and No. 3
(coils for cylinders No. 1 and No. 4) and terminals No. 1 and No. 3
(coils for cylinders No. 2 and No. 3). See Fig. 2.
Fig. 2: Testing Ignition Coil Primary Resistance (4-Cylinder)
Courtesy of Mitsubishi Motor Sales of America.
2) Measure secondary coil resistance between coil towers for
cylinders No. 1 and No. 4 and between coil towers for cylinders No. 2
and No. 3. See Fig. 3. Primary and secondary coil resistance should be
within specification. See DIS IGNITION COIL RESISTANCE table.
Fig. 3: Testing Ignition Coil Secondary Resistance (4-Cylinder)
Courtesy of Mitsubishi Motor Sales of America.
Page 174 of 1333
\003* B RAK E S YSTE M U NIF O RM IN SPEC TIO N G UID ELIN ES *
1 991 M it s u bis h i M onte ro
GENERAL INFORMATION
Brake Systems - Motorist Assurance Program
Standards For Automotive Repair
All Makes & Models
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS AND SUGGESTIONS
ACCELEROMETERS (G SENSOR OR LATERAL)
ACCUMULATORS
ANCHOR PINS
ANTI-LOCK BRAKE SYSTEMS
BACKING PLATES
BRAKE FLUID
BRAKE FRICTION MATERIAL
BRAKE PADS
BRAKE PEDALS
BRAKE SHOES
BRAKE SHOE HARDWARE
BRAKE STOPLIGHT SWITCHES
BULB SOCKETS
BULBS AND LEDS
CALIPER HARDWARE
CALIPERS
CONTROLLERS
DIGITAL RATIO AXLE CONTROLLERS AND BUFFERS (DRAC AND DRAB)
DISABLE SWITCHES
DRUMS
ELECTRICAL PUMPS AND MOTORS
ELECTRONIC CONTROLLERS
FLUID
FLUID LEVEL SENSOR SWITCHES
FOUR WHEEL DRIVE SWITCHES
FRICTION MATERIAL
G SENSORS
HOSES
HYDRAULIC MODULATORS
HYDRO-BOOSTERS
HYDRO-ELECTRIC BOOSTERS (POWERMASTER)
IGNITION DISABLE SWITCHES
LATERAL ACCELERATION SWITCHES
LEDS
LENSES
MASTER CYLINDERS
MODULATORS
MOTORS
PARKING BRAKE SWITCHES
PARKING BRAKE SYSTEMS
PADS
PEDAL TRAVEL SWITCHES
PEDALS
POWERMASTER
PUMPS
PRESSURE DIFFERENTIAL SWITCHES
PRESSURE SWITCHES
RELAYS
ROTORS
SELF-ADJUSTING SYSTEMS
Page 175 of 1333
SHOE HARDWARE
SHOES
SOCKETS
SPEED SENSORS (ELECTRONIC WHEEL AND VEHICLE)
STEEL BRAKE LINES
STOPLIGHT SWITCHES
SWITCHES
TIRES
TOOTHED RINGS (TONE WHEEL)
VACUUM BOOSTERS
VACUUM HOSES
VALVES
WHEEL ATTACHING HARDWARE
WHEEL BEARINGS, RACES AND SEALS
WHEEL CYLINDERS
WIRING HARNESSES
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt:\
1) a Pledge of Assurance to their Customers and
2) the Motorist Assurance Program Standards of Service.
All participating service providers have agreed to subscribe
to this Pledge and to adhere to the promulgated Standards of Service
demonstrating to their customers that they are serious about customer
satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
are continually re-published. In addition to these, standards for
Drive Train and Transmissions have recently been promulgated.
Participating shops utilize these Uniform Inspection & Communication
Standards as part of the inspection process and for communicating
their findings to their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
Page 178 of 1333
and make an informed decision about how to proceed.
BRAKES
SERVICE PROCEDURES REQUIRED & SUGGESTED FOR PROPER
VEHICLE OPERATION
Some states may have specifications that differ from OEM.
Check your local/state regulations. Where state or local laws are
stricter, they take precedence over these guidelines.
ACCELEROMETERS (G SENSOR OR LATERAL)
ACCELEROMETER INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Broken .................. A ............ Require replacement.
Connector loose ......... A .. Require repair or replacement.
Loose ................... B .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Out of position ......... B ....... Require re-positioning to
vehicle manufacturer's
specifications.
Output signal incorrect . B ............ Require replacement.
\
\
\
\
\
\
\
ACCUMULATORS
ACCUMULATOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Leaking ................. B ............ Require replacement.
Missing ................. C ............ Require replacement.
Pre-charge incorrect .... B ............ Require replacement.
\
\
\
\
\
\
\
ANCHOR PINS
See BACKING PLATES .
ANTI-LOCK BRAKE SYSTEMS
NOTE: Anti-lock brakes are an integral part of the brake system. It
is essential that the anti-lock brakes function properly when
brake service is performed.
Anti-lock brake systems are commonly referred to as "ABS" and
will be referred to as "ABS" throughout these guidelines. Some ABS
components also function as part of a traction control system (TCS).
WARNING: When diagnosing and servicing high pressure components,
observe safety procedures and equipment requirements
established by the vehicle manufacturer to reduce the
possibility of serious personal injury.
NOTE: Intermittent electrical conditions are often caused by a loss
of ground, poor connection, or water intrusion into the
wiring harness.
Page 188 of 1333
hardware.
Attaching hardware threads
damaged ................ A ... Require repair or replacement
of hardware.
Attaching hardware threads
stripped (threads
missing) ............... A ... Require repair or replacement
of hardware.
Code set (if
applicable) ............ A .......... (1) Further inspection
required.
Connector broken ........ A .. Require repair or replacement.
Connector melted ........ A ........... ( 2) Require repair or
replacement.
Connector missing ....... A ................. Require repair.
Contaminated ............ A .. Require repair or replacement.
Inoperative ............. B .. Require repair or replacement.
( 3) Further inspection required.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 2) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
( 1) - Refer to manufacturer's diagnostic trouble code procedure
and require repair or replacement of affected component(s).
( 2) - Determine cause and correct prior to repair or replacement
of part.
( 3) - Inoperative includes intermittent operation or out of OEM
specification. Some components may be serviceable. Check
for accepted cleaning procedure.
\
\
\
\
\
\
\
FLUID
See BRAKE FLUID.
FLUID LEVEL SENSOR SWITCHES
See SWITCHES.
FOUR WHEEL DRIVE SWITCHES
See SWITCHES.
Page 190 of 1333
Wear indicator device
(mechanical) contacts
rotor .................. .. ......... (6) Further inspection
required.
Worn close to minimum
specifications ......... 1 ........ ( 7) Suggest replacement.
Worn to, or below minimum
specifications ......... B ............ Require replacement.
( 1) - Identify and repair cause of contamination prior to
replacing friction material.
( 2) - When reconditioning or replacing drums or rotors,
replacement of friction material may be suggested
depending on the severity of the grooves or ridges.
( 3) - Some vehicles use pads that are tapered by design. Refer
to specific vehicle application. If not normal, require
replacement of pads and correction of cause.
( 4) - Uneven pad thickness is normal on some vehicles. Refer to
specific vehicle applications.
( 5) - The pad wear indicator light may come on due to other
electrical problems.
( 6) - Explain to the customer that the purpose of the wear
indicator is to alert him or her to check for friction
wear. Wear indicators may be bent or broken. Therefore,
the friction material must be measured. The need for
friction material replacement is determined based upon
the conditions stated in this section. Periodic inspection
is suggested.
( 7) - When the part appears to be close to the end of its useful
life, replacement may be suggested.
\
\
\
\
\
\
\
G SENSORS
See ACCELEROMETERS .
HOSES
HOSE INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............. A ... Require repair or replacement
of hardware.
Blistered ............... B ............ Require replacement.
Fitting threads damaged . A .. Require repair or replacement.
Fitting threads stripped
(threads missing) ...... A ............ Require replacement.
Incorrectly secured ..... B ................. Require repair.
Inner fabric
(webbing) cut .......... B ............ Require replacement.
Leaking ................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
Outer covering is cracked
to the extent that
inner fabric of hose
