Page 229 of 1333

CRUISE CONTROL SWITCH FUNCTION TEST
NOTE: If vehicle speed decreases approximately 9 MPH below set
speed, set speed will be cancelled.
1) Cruise control switch is part of multifunction switch
mounted on steering column. To operate cruise control system, turn
ignition on. Turn cruise control switch to ON position. Ensure switch
indicator light comes on.
NOTE: Speed will not set beyond system limit of 90 MPH.
2) With cruise control switch in ON position, drive vehicle
between 25 and 90 MPH. Press and release SET button. Vehicle speed
should stay at set speed. Instrument cluster cruise indicator light
should come on. To increase set speed, turn control switch to RESUME
position and hold until new set speed is reached.
3) To lower set speed, press SET button and hold until new
set speed is reached. To return to set speed after cancellation, move
resume switch from ON to OFF position. Vehicle speed should return to
previous setting before cancellation. Set speed should cancel when any
of the following occurs:
* Brake pedal is pressed.
* Clutch pedal is pressed.
* Transmission is shifted to Neutral or Park.
* Cruise control main switch is turned off.
* Ignition switch is turned off.
SELF-DIAGNOSTICS
1) Self-diagnostics should be performed when cruise control
cancels without the driver using normal cancel modes. Diagnosis
connector is located on right side of fuse box. Use analog voltmeter
or Multi-Use Tester (MB991341) for code retrieval.
2) Use multi-use tester according to operating instructions
provided with tester. Connect leads of analog voltmeter between cruise
control terminal and ground terminal of self-diagnostic connector. See
Fig. 6 . Read voltmeter needle sweeps to determine trouble code.
NOTE: On 1991 models, codes No. 13, 14, 15, 16 and 17 will be
displayed whether malfunction is present or not.
3) Once trouble codes have been displayed, see SELF-
DIAGNOSTIC CODE CHART to determine appropriate CIRCUIT TEST. See
Fig. 7 or 8.
4) To clear trouble codes, either disconnect battery cable or
turn ignition on. Turn main cruise control switch and set switch to ON
position. Within one second turn resume switch to ON position.
5) Hold stoplight switch and cruise control switch in ON
position for more than 5 seconds. Verify codes are cleared.
Fig. 6: Identifying Self-Diagnostic Connector Terminals
Courtesy of Mitsubishi Motor Co.
Page 872 of 1333

Figs. 1 and 2. After recording abnormal code(s), perform necessary
repair.
4) After repair, turn ignition off and disconnect negative
battery cable for 10 seconds to erase ECU memory. Reconnect power
supply and repeat self-diagnostics to confirm repair.
SELF-DIAGNOSTIC TEST CONNECTOR LOCATION TABLE
\
\
\
\
\
\
Application Location
Colt, Colt 200, Colt Wagon & Summit
1.5L ................................ Next to fuse block
1.6L .................................. Right kick panel
Colt Wagon & Colt Vista
1.8L & 2.0L SOHC .................... Next to fuse block
Eclipse ............................... Next to fuse block
Galant ................................... Left kick panel
Mirage ................................... Left kick panel
Montero .......................... Inside top of glove box
Precis ................................... Left kick panel
\
\
\
\
\
\
Fig. 1: Diagnostic Fault Chart (1 of 2)
Courtesy of Mitsubishi Motor Sales of America.
