Check blower switch and relay. Check A/C compressor clutch coil.
2) Ensure system is properly charged with correct amount of
refrigerant. Add refrigerant or evacuate and recharge system as
necessary. Ensure receiver-drier is not clogged. Check compressor belt
for proper tension. Check for clogged expansion valve. Check
compressor operation. Repair or replace compressor as necessary.
INSUFFICIENT AIRFLOW
Check for air leakage at air duct joint. Check for frost on
evaporator. Ensure blower motor is operating properly. Check for
obstructed air intake.
INSUFFICIENT COOLING
Ensure system is properly charged with correct amount of
refrigerant and free of air and moisture. Add refrigerant or evacuate
and recharge system as necessary. Ensure receiver-drier is not
clogged. Ensure sufficient airflow through condenser exists. Check
compressor belt for proper tension. Check compressor operation. Repair
or replace compressor as necessary. Check for clogged expansion valve.
Replace expansion valve as necessary.
INTERMITTENT COOL AIR
Check for air or moisture in system. Evacuate and recharge
system as necessary. Check for expansion valve malfunction. Replace
expansion valve if necessary. Check compressor belt for proper
tension.
TESTING
A/C SWITCH
1) Disconnect A/C switch harness connector. Using appropriate
wiring diagram as a guide, jumper appropriate terminals of A/C switch
wiring harness connector. See Fig. 4.
2) Turn blower on and momentarily turn ignition on without
starting engine. Listen for compressor clutch engagement. If
compressor clutch does not engage, check fuse and other components
wired in series with compressor clutch.
Fig. 4: A/C Switch Connector ID
Courtesy of Mitsubishi Motor Sales of America.
AIR THERMO & AIR INLET SENSORS

Fig. 21: 1991 Acturator Connector
Courtesy of Mitsubishi Motor Co.
CIRCUIT TESTS (1992)
NOTE: To identify circuit connector terminals, See Figs. 22-29.
For wiring diagram, See appropriate chassis wiring diagram in
the WIRING DIAGRAMS Section.
Test No. 1 (Power & Ground Circuit)
1) Turn ignition on. When cruise control main switch is
turned to ON position, battery voltage should be present on terminal
No. 2 of cruise control unit connector.
2) If voltage is not present, check fuse No. 11 and replace
as necessary. If fuse is okay, check and repair harness as necessary.
Terminal No. 8 should be grounded at all times. If terminal No. 8 is
not grounded, repair harness.
Test No. 2 (Set Switch Circuits)
When set switch is turned to ON position, 3 volts should be
present on terminal No. 18 of cruise control unit. When set switch is
turned to OFF position, voltage should not be present on terminal No.
18 of cruise control unit. If circuit does not test correctly, replace
switch as necessary or repair harness.
Test No. 3 (Resume Switch Circuit)
When resume switch is turned to ON position, 6 volts should
be present on terminal No. 18 of cruise control unit. When resume
switch is turned to OFF position, voltage should not be present on
terminal No. 18 of cruise control unit. If circuit does not test
correctly, replace switch as necessary or repair harness.
Test No. 4 (Cancel Switch Circuit)
When cancel switch is turned to On position, battery voltage
should be present on terminal No. 18 of cruise control unit. When
cancel switch is in Off position, voltage should not be present on
terminal No. 18 of cruise control unit. If circuit does not test
correctly, replace switch as necessary or repair harness.

ALTERNATOR article








\









\









\









\









\









\









\







Alternator Blown fuse See WIRING DIAGRAMS
Light Stays Off
With Ignition
Switch ON
Defective alternator See Testing in
ALTERNATOR article
Defective indicator light See Indicator Warning
bulb or socket Lights in STANDARD
INSTRUMENTS in the
ACCESSORIES &
EQUIPMENT section









\









\









\









\









\









\









\







Alternator Short in alternator wiring See On-Vehicle Tests
Light Stays OFF in ALTERNATOR article
With Ignition
Switch ON
Defective rectifier bridge See Bench Tests in
ALTERNATOR article









\









\









\









\









\









\









\







Lights or Fuses Defective alternator wiring See On-Vehicle Tests
Burn Out in ALTERNATOR article
Frequently
Defective regulator See Regulator Check in
ALTERNATOR article
Defective battery Check and replace as
necessary









\









\









\









\









\









\









\







Ammeter Gauge Loose or worn drive belt Check alternator drive
Shows Discharge belt tension and
condition. See Belt
Adjustment in TUNE-UP
article in the
TUNE-UP section
Defective wiring Check all wires and
wire connections
Defective alternator or See Bench Tests and
regulator On-Vehicle Tests in
ALTERNATOR article
Defective ammeter, or See Testing in
improper ammeter wiring STANDARD INSTRUMENTS
connection in the ACCESSORIES &
EQUIPMENT section









\









\









\









\









\









\









\







Noisy Loose drive pulley Tighten drive pulley
Alternator attaching nut
Loose mounting bolts Tighten all alternator
mounting bolts
Worn or dirty bearings See Bearing
Replacement
ALTERNATOR article

WIR IN G D IA G RAM S

1991 M it s u bis h i M onte ro
1991 Wiring Diagrams
Mitsubishi
Montero
IDENTIFICATION
COMPONENT LOCATION MENU
COMPONENT LOCATIONS TABLE








\









\









\









\









\









\






Component Figure No. (Location)
A/C RELAYS .......................... 4 (C 12), 4 (A-B 15)
A/C SYSTEM ................................. 4 (A-C 12-15)
ALTERNATOR ................................... 1 (B-C 1-2)
ALTERNATOR RELAY ............................... 1 (C 1-2)
AUTO FREE-WHEELING HUB CONTROL UNIT ............. 3 (D 11)
BACK DOOR LOCK SW ............................... 7 (B 27)
BACK-UP LT SW (M/T) ............................. 7 (A 26)
BATTERY .......................................... 1 (A 1)
BLOWER SWITCH ................................. 4 (A-B 12)
BUZZER .......................................... 5 (E 17)
CARGO LIGHT ..................................... 6 (A 23)
CIG LIGHTER ..................................... 3 (E 11)
CLOCK ........................................... 3 (E 11)
COLUMN SW ..................................... 5 (A-E 19)
CRUISE CONTROL SYSTEM ...................... 4 (D-E 13-15)
DEFOGGER ...................................... 7 (C-D 27)
DIAG CONNECTION .................................. 2 (E 7)
DIMMER CONTROL SWITCH ............................ 3 (E 8)
DIR FLASHER ..................................... 5 (C 16)
DIR SWITCH ...................................... 5 (C 19)
DOME LT ............................... 6 (A 23), 7 (A 24)
DOOR LOCK SYSTEM ........................... 6 (D-E 21-23)
DOOR SWITCHES ......................... 5 (D 17), 6 (C 23)
FRONT WIPER SYSTEM ........................... 5 (A 16-17)
FUEL GAUGE UNIT ................................. 6 (C 22)
FUEL PUMP ........................................ 2 (C 4)
FUSE BLOCK .................................... 3 (C 9-10)
HAZARD FLASHER .................................. 5 (C 16)
HAZARD SW ....................................... 5 (B 16)
HEAD LIGHT WASHER RELAY ....................... 5 (C-D 17)
HEATER RELAY .................................... 4 (A 12)
HORN SWITCH ..................................... 5 (E 19)
IGNITION COIL .................................... 2 (E 4)
IGNITION SW ..................................... 3 (A 11)
ILLUMINATION LIGHTS ............................ 3 (D-E 8)
INHIBITOR SW ..................................... 3 (A 9)
INSTRUMENT CLUSTER ............................ 6 (A-D 20)
KEY REMINDER SW ................................. 5 (E-17)
LIGHT CONTROL RELAY ............................. 5 (E 19)
LIGHT SWITCH .................................... 5 (D 19)
MAIN FUSE LINKS ................................ 1 (A 1-2)
METER UNIT ...................................... 6 (E 20)
MPI CONTROL RELAY ................................ 2 (B 4)
MPI CONTROL UNIT ............................... 2 (A 4-7)
NOISE FILTER ..................................... 2 (E 6)
OVERDRIVE CONTROL RELAY .......................... 3 (A 8)

OVERDRIVE SWITCH ................................. 3 (A 8)
PARKING BRAKE SWITCH ............................ 6 (A 21)
POWER TRANSISTOR ................................. 2 (D 4)
POWER WINDOWS .............................. 7 (B-E 24-26)
RADIO (PARTIAL) ............................... 3 (D-E 10)
REAR BLOWER SWITCH .............................. 4 (D 12)
REAR WIPER .................................... 5 (D-E 16)
SEAT BELT WARNING TIMER ......................... 5 (D 18)
STARTER .......................................... 1 (C 3)
STOP LIGHT SWITCH ..................... 4 (E 13), 5 (C 16)
SUB FUSE LINKS ................................... 1 (A 3)
SUNROOF ...................................... 7 (A 24-25)
WIPER SWITCH .................................. 5 (A-B 19)









\









\









\









\









\









\
