JA C KIN G & H O IS TIN G

1991 M it s u bis h i M onte ro
1991 WHEEL ALIGNMENT
Jacking & Hoisting
Chrysler Motors: Ram-50
Mitsubishi: Montero, Pickup
JACKING & HOISTING
NOTE: The following illustrations DO NOT represent the exact
structure of vehicle's frame, underbody or body outline.
Illustrations are given to provide reference points for the
mechanic.
FRAME & UNDERBODY
The following illustrations indicate points for jacking and
hoisting vehicle. These points are indicated by shaded areas on the
frame and underbody. See Fig. 1.
OUTERBODY
Points on the outline of body were designated to be used
specifically with vehicle's own jack. See Fig. 2. If floor jack or
hoist is used at these points, use extreme care to avoid damaging
outer body shell. See Fig. 2 or 3.
Fig. 1: Jacking & Hoisting Points (Typical)

Fig. 2: Jacking & Hoisting Points (Montero)
Courtesy of Mitsubishi Motor Sales of America.
Fig. 3: Jacking & Hoisting Points (Pickup & Ram-50)
Courtesy of Mitsubishi Motor Sales of America.
