service indicator MITSUBISHI MONTERO 1998 User Guide

If equipped, the EMR light (some models may use a reminder
flag) reminds vehicle operator that an emission system maintenance is
required. This indicator is activated after a predetermined
time/mileage.
When performing a smog check inspection, ensure EMR indicator
is not activated. On models using an EMR light, light should glow when
ignition switch is turned to ON position and should turn off when
engine is running.
If an EMR flag is present or an EMR light stays on with
engine running, fail vehicle and service or replace applicable
emission-related components. To reset an EMR indicator, refer to
appropriate MAINTENANCE REMINDER LIGHTS in the MAINTENANCE section.
MALFUNCTION INDICATOR LIGHT (MIL)
The Malfunction Indicator Light (MIL) is used to alert
vehicle operator that the computerized engine control system has
detected a malfunction (when it stays on all the time with engine
running). On some models, the MIL may also be used to display trouble
codes.
As a bulb and system check, malfunction indicator light will
glow when ignition switch is turned to ON position and engine is not
running. When engine is started, light should go out.

98V220000: FRONT BRAKE LINE INSPECTION
1998 Mitsubishi Montero
NHTSA RECALL BULLETIN
Model(s): 1997-98 Mitsubishi Montero
Campaign No: 98V220000
Number of Affected Vehicles: 61800
Beginning Date of Manufacture: 1996 JUN
Ending Date of Manufacture: 1998 MAY
VEHICLE DESCRIPTION:
Sport utility vehicles.
DESCRIPTION OF DEFECT:
The front brake lines can develop pin holes due to chaffing against
the edge of the pass-through hole in the inner fender.
CONSEQUENCE OF DEFECT:
Brake fluid can leak resulting in deteriorated braking performance and
illumination of the brake indicator lamp.
CORRECTIVE ACTION:
Dealers will inspect the front brake lines for signs of wear and
routing. If the lines are not correctly centered in the pass-through
hole, the lines will be repositioned by bending slightly to correct.
If there is evidence of brake line wear, the brake line will be
replaced.
OWNER NOTIFICATION:
Owner notification is expected to begin October 19, 1998. Owners who
take their vehicles to an authorized dealer on an agreed upon service
date and do not receive the free remedy within a reasonable time
should contact Mitsubishi at 1-800-222-0037. Also contact the
National Highway Traffic Safety Administration's Auto Safety Hotline
at 1-888-dash-2-dot (1-888-327-4236).
ADDITIONAL INFORMATION:
The National Highway Traffic Safety Administration operates Monday
through Friday from 8:00 AM to 4:00 PM, Eastern Time. For more
information call (800) 424-9393 or (202) 366-0123. For the hearing
impaired, call (800) 424-9153.

Tighten wheel lug nuts to 72-87 ft. lbs. (100-120 N.m).
BATTERY SPECIFICATIONS
CAUTION: When battery is disconnected, vehicles equipped with
computers may lose memory data. When battery power is
restored, driveability problems may exist on some vehicles.
These vehicles may require a relearn procedure. See
COMPUTER RELEARN PROCEDURES article in the GENERAL
INFORMATION Section.
Battery is maintenance-free and does not normally require
additional water. However, under severe conditions it is advisable to
check battery fluid periodically. Use only distilled water to fill
battery cell should it become necessary to add water. Charge condition
can be checked by a visual test indicator on top of battery.
CAUTIONS & WARNINGS
SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)
NOTE: See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT
Section.
Modifications or improper maintenance, including incorrect
removal and installation of the Supplemental Restraint System (SRS),
can adversely affect system performance. DO NOT cover, obstruct or
change the steering wheel horn pad in any way, as such action could
cause improper function of the system. Use only plain water when
cleaning the horn pad. Solvents or cleaners could adversely affect the
air bag cover and cause improper deployment of the system.
WARNING: Service on or around Air Bag System Components or Wiring must
be preformed only by an authorized Suzuki dealer. Please
observe all WARNINGS and SERVICE PRECAUTIONS.
WARNING: Technical service work must be started at least 90 seconds
after the ignition switch is turned to the LOCK position and
the cable is disconnected from the battery.
WARNING: Never attempt to disassemble or repair the passenger air
bag (inflator) module. If any abnormality is found, be sure
to replace it with new one as an assembly.
WARNING: To avoid injury from accidental air bag deployment, read and
carefully follow all warnings and service precautions. See
appropriate AIR BAG RESTRAINT SYSTEM article in the
ACCESSORIES/SAFETY EQUIPMENT section.
CAUTION: Disconnect negative battery cable before servicing any air
bag system, steering column or passenger side dash
component. After any repair, turn ignition key to the ON
position from passenger's side of vehicle in case of
accidental air bag inflation
AIR CONDITIONING SERVICING
WARNING: Avoid breathing R-134a refrigerant and PAG lubricant vapors,
exposure may irritate eyes, nose and throat. To remove
R-134a from system use R-134a recycling equipment that meets

allowing metal objects to contact the battery posts and the
vehicle at the same time.
CAUTION: Never disconnect the battery while the engine is running;
doing so could damage the car's electrical components.
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off
all lights and accessories to avoid damaging the electrical system. Be
sure to use fuse with the correct indicated amperage rating. The use
of an incorrect amperage rating fuse may result in a dangerous
electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning
that brake pads need replacement.
BRAKE FLUID
WARNING: DO NOT use reclaimed fluid or fluid that has been stored
in old or open containers. It is essential that foreign
particles and other liquids are kept out of the brake fluid
reservoir.
CATALYTIC CONVERTER
Continued operation of vehicle with a severe malfunction
could cause converter to overheat, resulting in possible damage to
converter and vehicle.
ENGINE COOLANT SERVICE
WARNING: To avoid the danger of being scalded never change the coolant
when the engine is hot.
WARNING: Never remove the radiator cap when the engine is hot Serious
burns could be caused by high pressure fluid escaping from
the radiator.
CAUTION: When adding or replacing engine coolant, use a high quality
ethylene glycol antifreeze diluted with 50% distilled water.
When putting the cap on the reserve tank, line up the arrow
on the cap and the arrow on the tank, or coolant can leak out
ENGINE DRIVE BELT SERVICE
WARNING: Be sure the ignition key is OFF. The engine could rotate
unexpectedly.
ENGINE OIL
WARNING: The engine oil may be high enough to burn your fingers
when the drain plug is loosened. Wait until the drain plug
is cool enough to touch with you bare hands.
WARNING: Continuous contact with used engine oil has been found to
cause skin cancer in laboratory animals. Brief contact with
used engine oil may irritate skin. To minimize your exposure
to used oil, wear a long sleeve shirt and moisture-proof
gloves when changing oil. If oil contacts your skin, wash

(chunking),
exposing cord .......... A ............ Require replacement.
Tread missing pieces
(chunking), not
exposing cord .......... 1 ............ Suggest replacement.
Tread separations A ............ Require replacement.
Tube in tubeless tire 3 .... (4) Suggest removal of tube.
Weather-checking ........ .. ......... No service required or
suggested.
Worn to tread wear
indicators ............. B ............ Require replacement.
( 1) - Determine and correct cause of irregular tire wear.
( 2) - If radials and bias or bias-belted ply tires are on the
same vehicle, the radials must be on the rear axle,
except for high-pressure temporary spares.
( 3) - Excessive is defined as enough to contribute to
performance problems. Match mounting may correct
run-out. If not, require replacement of appropriate
part. Refer to manufacturer's specifications.
( 4) - Most manufacturers do not recommend tubes in tubeless
tires. Inspect tire and wheel assembly to determine
the reason for a tube in tubeless tire. Recommendation
for repair or replacement should be based upon condition
of tires and/or wheel listed in these guidelines.









\









\









\









\









\









\









\


VALVE STEMS
VALVE STEM INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Bent .................... 1 ........... Suggest replacement.
Broken .................. A ........... Require replacement.
Cut, but not leaking .... 1 ........... Suggest replacement.
Deteriorated
(cracking, dry rot) .... 1 ........... Suggest replacement.
Leaking ................. A . Require repair or replacement.
Missing ................. C ........... Require replacement.
Threads damaged ......... A . Require repair or replacement.
Threads stripped ........ A ........... Require replacement.
Valve cap missing ....... C .... Require replacement of cap.
Weather-checking ........ 1 ........... Suggest replacement.
Won't take air .......... A . Require repair or replacement.









\









\









\









\









\









\









\


WHEEL ATTACHMENT HARDWARE
For conditions noted below, also check conditions of wheel
stud holes.
CAUTION: Proper lug nut torque is essential. Follow recommended
torque specifications and tightening sequence. DO NOT
lubricate threads unless specified by the vehicle
manufacturer.
WHEEL ATTACHMENT HARDWARE INSPECTION









\









\









\









\









\









\









\


Condition Code Procedure
Bent .................... A ............ Require replacement.
Broken .................. A ........ ( 1) Require replacement.

(chunking),
exposing cord .......... A ............ Require replacement.
Tread missing pieces
(chunking), not
exposing cord .......... 1 ............ Suggest replacement.
Tread separations A ............ Require replacement.
Tube in tubeless tire 3 .... (4) Suggest removal of tube.
Weather-checking ........ .. ......... No service required or
suggested.
Worn to tread wear
indicators ............. B ............ Require replacement.
( 1) - Determine and correct cause of irregular tire wear.
( 2) - If radials and bias or bias-belted ply tires are on the
same vehicle, the radials must be on the rear axle,
except for high-pressure temporary spares.
( 3) - Excessive is defined as enough to contribute to
performance problems. Match mounting may correct
run-out. If not, require replacement of appropriate
part. Refer to manufacturer's specifications.
( 4) - Most manufacturers do not recommend tubes in tubeless
tires. Inspect tire and wheel assembly to determine
the reason for a tube in tubeless tire. Recommendation
for repair or replacement should be based upon condition
of tires and/or wheel listed in these guidelines.









\









\









\









\









\









\









\


VALVE STEMS
VALVE STEM INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Bent .................... 1 ........... Suggest replacement.
Broken .................. A ........... Require replacement.
Cut, but not leaking .... 1 ........... Suggest replacement.
Deteriorated
(cracking, dry rot) .... 1 ........... Suggest replacement.
Leaking ................. A . Require repair or replacement.
Missing ................. C ........... Require replacement.
Threads damaged ......... A . Require repair or replacement.
Threads stripped ........ A ........... Require replacement.
Valve cap missing ....... C .... Require replacement of cap.
Weather-checking ........ 1 ........... Suggest replacement.
Won't take air .......... A . Require repair or replacement.









\









\









\









\









\









\









\


WHEEL ATTACHMENT HARDWARE
For conditions noted below, also check conditions of wheel
stud holes.
CAUTION: Proper lug nut torque is essential. Follow recommended
torque specifications and tightening sequence. DO NOT
lubricate threads unless specified by the vehicle
manufacturer.
WHEEL ATTACHMENT HARDWARE INSPECTION









\









\









\









\









\









\









\


Condition Code Procedure
Bent .................... A ............ Require replacement.
Broken .................. A ........ ( 1) Require replacement.
