Fig. 2: Exploded View Of Rear Suspension (Montero)
Courtesy of Mitsubishi Motor Sales of America.
ADJUSTMENTS & INSPECTION
WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES
NOTE: Wheel alignment is factory set and cannot be adjusted.
REMOVAL & INSTALLATION
Page 1246 of 1501
* SUSPENSION UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
Steering, Suspension, Wheel Alignment, Wheels and Tires
Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Steering and Suspension
AIR RIDE SUSPENSION
AIR RIDE SUSPENSION - AIR SHOCKS AND AIR STRUTS
AIR RIDE SUSPENSION - AIR SPRING VALVES
AIR RIDE SUSPENSION - AIR SPRINGS
AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - HEIGHT SENSORS
AIR RIDE SUSPENSION - MODULES
AIR RIDE SUSPENSION - RELAYS (COMPRESSOR)
AIR RIDE SUSPENSION - SWITCHES (ON/OFF)
AIR RIDE SUSPENSION - TORSION SPRINGS (COUNTER BALANCING)
AIR RIDE SUSPENSION - TUBING
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SUSPENSION - WIRING HARNESSES
BALL JOINTS
BUSHINGS
CENTER LINKS
CONTROL ARM SHAFTS
CONTROL ARMS
DRAG LINKS
ELECTRONIC RIDE CONTROL SHOCKS AND STRUTS
IDLER ARMS
KING PINS
PITMAN ARMS
POWER STEERING HOSES
POWER STEERING (HYDRAULIC) PUMPS
RADIUS ARMS
RELAY RODS
SHOCK ABSORBERS, STRUT CARTRIDGES AND STRUT ASSEMBLIES
SPINDLES
SPRINGS - COIL, LEAF AND TORSION BAR
STEEL POWER STEERING LINES
STEERING ARMS
STEERING DAMPERS
STEERING GEARS (EXCEPT RACK AND PINION)
STEERING GEARS - RACK AND PINION
STEERING KNUCKLES
STRIKE OUT BUMPERS
STRUT RODS
STRUT UPPER BEARING PLATE ASSEMBLIES
SWAY BAR LINKS
SWAY BARS
Page 1247 of 1501
TIE ROD ENDS (INNER AND OUTER)
TRACK BARS
TRAILING ARMS
WHEEL BEARINGS, RACES AND SEALS
Wheel Alignment
WHEEL ALIGNMENT
Wheels and Tires
TIRES
VALVE STEMS
WHEEL ATTACHMENT HARDWARE
WHEELS (RIMS)
MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
1) a Pledge of Assurance to their Customers and 2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
are continually re-published. In addition to these, standards for
Drive Train and Transmissions have recently been promulgated.
Participating shops utilize these Uniform Inspection & Communication
Standards as part of the inspection process and for communicating
their findings to their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
satisfied with a repair transaction, the Motorist Assurance Program
offers mediation and arbitration through MAP/BBB-CARE and other non-
Page 1248 of 1501
profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherence to the
Pledge and Standards and agreed to follow the UICS in communicating
the results of their inspection to their customers. To put some
"teeth" in the program, an accreditation requirement for shops was
initiated. The requirements are stringent, and a self-policing method
has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and your customers
will reap the benefits. Please visit MAP at our Internet site www.
motorist.org or contact us at:
1444 I Street, NW Suite 700
Washington, DC 20005
Phone (202) 712-9042 Fax (202) 216-9646
January 1999
MAP UNIFORM INSPECTION GENERAL GUIDELINES
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
It is MAP policy that all exhaust, brake, steering,
suspension, wheel alignment, drive-line, engine performance and
maintenance, and heating, ventilation and air conditioning, and
electrical services be offered and performed under the standards and
procedures specified in these sections.
Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement.
Although this list is extensive, it is not fully inclusive. In
addition to this list, a technician may make a suggestion. However,
any suggestions must be based on substantial and informed experience,
or the vehicle manufacturer's recommended service interval and must be
documented.
Some conditions indicate that service or part replacement is
required because the part in question is no longer providing the
function for which it is intended, does not meet a vehicle
manufacturer's design specification or is missing.
Example:
An exhaust pipe has corroded severely and has a hole in it
through which exhaust gases are leaking. Replacement of the
exhaust pipe in this case is required due to functional
failure.
Example:
A brake rotor has been worn to the point where it measures
less than the vehicle manufacturer's discard specifications.
Replacement of the rotor is required because it does not meet
design specifications.
Page 1290 of 1501
if possible. If proper
adjustment cannot be obtained,
require repair or replacement
of worn component.
Wheel bearing race
is loose in the
hub bore ............... A ...... Require replacement of hub
assembly and wheel bearings.
Wheel bearing races
are pitted ............. A .. Require replacement of bearing
assembly.
Wheel bearing races
are worn ............... A .. Require replacement of bearing
assembly.
Wheel bearing rollers
are pitted ............. A .. Require replacement of bearing
assembly.
Wheel bearing rollers
are worn ............... A .. Require replacement of bearing
assembly.
\
\
\
\
\
\
\
WHEEL ALIGNMENT
WHEEL ALIGNMENT
Wheel alignment is defined as the measurement, analysis, and
adjustment of steering and suspension angles to conform to OEM
specifications. These angles usually include, but are not limited to:
caster, camber, toe, and thrust angle. Where these angles are not
adjustable and not in specification, component replacement or
correction kits may be required. Errors in set-back and steering axis
inclination (SAI) are often attributable to failed or damaged
components and must be corrected prior to performing an alignment.
Failure to replace or correct suggested parts or service may
prevent a proper alignment.
Before performing an alignment check, inspect and verify the
following:
* Tire pressure and size
* Vehicle loading
* Ride height
* Steering and suspension parts
If the inspection reveals that all the above are within
published specifications, a wheel alignment check and an alignment, if
needed, may be performed.
CAUTION: Under no circumstances should a technician bend or heat
any steering or suspension component, unless specified by
the vehicle manufacturer, for example, Ford forged twin
"I" beam axles. All measurements and specifications must
be noted on the inspection report.
WHEEL ALIGNMENT INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Dog tracking, shown
to be caused by
faulty alignment ....... 2 ................ Suggest repair.
Lead, shown to
Page 1291 of 1501
be caused by
faulty alignment ....... A ............. Require alignment.
Part has been changed,
affecting alignment .... A ....... Require alignment check.
Pull, shown to be caused
by faulty alignment .... A ............. Require alignment.
Steering wheel
off-center ............. 2 ............. Suggest alignment.
Tire wear, shown
to be caused by
faulty alignment ....... A ............. Require alignment.
Wander, shown
to be caused by
faulty alignment ....... A ............. Require alignment.
\
\
\
\
\
\
\
WHEELS AND TIRES
TIRES
These guidelines do not apply to split rims. Some vehicle
manufacturers restrict replacement of tires to specific brands, types,
or sizes.
WARNING: High pressure temporary compact spare tires should not be
used with any other rims or wheels, nor should standard
tires, snow tires, wheel covers, or trim rings be used
with high pressure compact spare rims or wheels.
Attempting to mount a tire of one diameter on a wheel of
a different diameter or flange type may result in serious
injury or death.
WARNING: Only specially trained persons should dismount or mount
tires. Explosions of tire and wheel assembly can result
from improper mounting, possibly causing serious injury
or death.
WARNING: Consult the vehicle owner's manual or vehicle placard for
correct size, speed rating, designation, and cold
inflation pressure of the original tires. DO NOT exceed
the maximum load or inflation capacity of the tire
specified by the Tire and Rim Association
WARNING: When replacing tires, it is suggested that the
replacement tires match or exceed the OEM speed rating
designation. If tires of different speed rating
designations are mixed on the same vehicle, the tires may
vary in handling characteristics. DO NOT mix different
speed rating designations on the same axle.
WARNING: DO NOT mix radials with non-radial tires on the same
axle, as this may affect vehicle handling and stability.
If radial tires and bias or bias-belted ply tires are
mixed on the same vehicle, the radials must be on the
rear. High-pressure temporary compact spare tires are
exempt from this rule.
WARNING: DO NOT mix size or type (all season, performance, mud and
snow) of tires on the same axle.
TIRE INSPECTION
\
\
\
\
\
\
\
Page 1376 of 1501
![MITSUBISHI MONTERO 1998 Owners Manual BRAKE SYSTEM TROUBLE SHOOTING CHART \
\
\
\
\
\
\
CONDITION](/img/19/57333/w960_57333-1375.png "MITSUBISHI MONTERO 1998 Owners Manual BRAKE SYSTEM TROUBLE SHOOTING CHART \
\
\
\
\
\
\
CONDITION")
BRAKE SYSTEM TROUBLE SHOOTING CHART \
\
\
\
\
\
\
CONDITION POSSIBLE CAUSE CORRECTION \
\
\
\
\
\
\
Brakes Pull Left
or Right Incorrect tire pressure Inflate tires to proper
pressure
Front end out of alignment See WHEEL ALIGNMENT
Mismatched tires Check tires sizes
Restricted brake lines
or hoses Check hose routing
Loose or malfunctioning
caliper See DISC BRAKES or
BRAKE SYSTEM
Bent shoe or oily linings See DRUM BRAKES or
BRAKE SYSTEM
Malfunctioning rear brakes See DRUM, DISC BRAKES
or BRAKE SYSTEM
Loose suspension parts See SUSPENSION
\
\
\
\
\
\
\
Noises Without
Brakes Applied Front linings worn out Replace linings
Dust or oil on drums See DRUM, DISC BRAKES
or rotors or BRAKE SYSTEM
\
\
\
\
\
\
\
Noises With
Brakes Applied Insulator on outboard See DISC BRAKES or
shoe damaged BRAKE SYSTEM
Incorrect pads or linings Replace pads or linings
\
\
\
\
\
\
\
Brake Rough, Chatters
or Pulsates Excessive lateral runout Check rotor runout
Parallelism not to
specifications Reface or replace rotor
Wheel bearings not adjusted See SUSPENSION
Rear drums out-of-round Reface or replace drums
Disc pad reversed, steel
against rotor Remove and reinstall
pad
\
\
\
\
\
\
\
Excessive Pedal
Effort Malfunctioning power unit See POWER BRAKES or
BRAKE SYSTEM
Partial system failure Check fluid and pipes
Worn disc pad or lining Replace pad or lining
Caliper piston stuck or
Page 1409 of 1501
![MITSUBISHI MONTERO 1998 Owners Manual \
\
\
\
\
\
\
CONDITION POSSIBLE CAUSE](/img/19/57333/w960_57333-1408.png "MITSUBISHI MONTERO 1998 Owners Manual \
\
\
\
\
\
\
CONDITION POSSIBLE CAUSE")
\
\
\
\
\
\
\
CONDITION POSSIBLE CAUSE CORRECTION \
\
\
\
\
\
\
Chattering or Incorrect clutch adjustment Adjust clutch
Grabbing
Oil, grease or glaze on Disassemble and clean
facings or replace
Loose "U" joint flange See DRIVE AXLES
article
Worn input shaft spline Replace input shaft
Binding pressure plate Replace pressure plate
Binding release lever See CLUTCH article
Binding clutch disc hub Replace clutch disc
Unequal pressure plate Replace worn/misaligned
contact components
Loose/bent clutch disc Replace clutch disc
Incorrect transmission Realign transmission
alignment
Worn pressure plate, disc Replace damaged
or flywheel components
Broken or weak pressure Replace pressure
springs plate
Sticking clutch pedal Lubricate clutch pedal
& linkage
Incorrect clutch disc Replace clutch disc
facing
Engine loose in chassis Tighten all mounting
bolts
\
\
\
\
\
\
\
Failure to Oil or grease on clutch Clean or replace clutch
Release facings clutch disc
Incorrect release lever or See CLUTCH article
pedal adjustment
Worn or broken clutch Replace clutch disc
facings
Bent clutch disc or Replace damaged
pressure plate components
Clutch disc hub binding on Clean or replace clutch
input shaft disc and/or input shaft
Binding pilot bearing Replace pilot bearing
Sticking release bearing Replace release bearing
sleeve and/or sleeve
Binding clutch cable See CLUTCH article
Page 1415 of 1501
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
BASIC FWD AXLE SHAFTS & CV JOINTS TROUBLE SHOOTING CHART
\
\
\
\
\
\
\
CONDITION POSSIBLE CAUSE \
\
\
\
\
\
\
Grease Leaks CV boot torn or cracked \
\
\
\
\
\
\
Clicking Noise on Cornering Damaged outer CV \
\
\
\
\
\
\
Clunk Noise on Acceleration Damaged inner CV \
\
\
\
\
\
\
Vibration or Shudder Sticking, damaged or worn CV
on Acceleration Misalignment or spring height
\
\
\
\
\
\
\
STEERING & SUSPENSION
MANUAL STEERING GEAR TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
BASIC MANUAL STEERING GEAR TROUBLE SHOOTING CHART
\
\
\
\
\
\
\
CONDITION POSSIBLE CAUSE CORRECTION \
\
\
\
\
\
\
Rattle or Rack and pinion mounting Tighten all mounting
Chucking Noise bracket loose bolts
in Rack and
Pinion Lack of/or incorrect Correct as necessary
lubricant
Steering gear mounting Tighten all mounting
bolts loose bolts
\
\
\
\
\
\
\
Excessive Play Front wheel bearing See FRONT SUSPENSION
improperly adjusted article
Loose or worn steering See STEERING LINKAGE
linkage article
Loose or worn steering See MANUAL STEERING
gear shift GEAR article
Steering arm loose on See MANUAL STEERING
gear shaft GEAR article
Steering gear housing Tighten all mounting
bolts loose bolts
Steering gear adjustment See MANUAL STEERING
too loose GEAR article
Steering arms loose on Tighten and check
Page 1416 of 1501
knuckles steering linkage
Rack and pinion mounting Tighten all mounting
loose bolts
Rack and pinion out of See adjustment in
adjustment STEERING article
Tie rod end loose Tighten and check
steering linkage
Excessive Pitman shaft-to- Repair as necessary
ball nut lash
\
\
\
\
\
\
\
Poor Lack of lubricant in ball Lubricate and service
Returnability joint or linkage systems
Binding in linkage or ball See STEERING LINKAGE
joints and SUSPENSION article
Improper front end alignment See WHEEL ALIGNMENT
article
Improper tire pressure Inflate to proper
pressure
Tie rod binding Inflate to proper
pressure
Shaft seal rubbing shaft See STEERING COLUMN
article
\
\
\
\
\
\
\
Excessive Improper tire pressure Inflate to proper
Vertical Motion pressure
Tires, wheels or rotors Balance tires then
out of balance check wheels and
rotors
Worn or faulty shock Check and replace if
absorbers necessary
Loose tie rod ends or Tighten or replace if
steering necessary
Loose or worn wheel See SUSPENSION article
bearings
\
\
\
\
\
\
\
Steering Pulls Improper tire pressure Inflate to proper
to One Side pressure
Front tires are different Rotate or replace if
sizes necessary
Wheel bearings not See FRONT SUSPENSION
article
adjusted properly
Bent or broken suspension See FRONT SUSPENSION
components article
Improper wheel alignment See WHEEL ALIGNMENT
article
