![MITSUBISHI MONTERO 1998 Owners Guide AXLE RATIO SPECIFICATIONS \
\
\
\
\
\
\
Application](/img/19/57333/w960_57333-360.png "MITSUBISHI MONTERO 1998 Owners Guide AXLE RATIO SPECIFICATIONS \
\
\
\
\
\
\
Application")
AXLE RATIO SPECIFICATIONS \
\
\
\
\
\
\
Application Ratio
Montero ..................................................... 4.27:1
Montero Sport .................................................. (1)
( 1) - On vehicles equipped with wide fender, ratio is 4.64:1. On
vehicles with narrow fender, ratio is 4.27:1.
\
\
\
\
\
\
\
LUBRICATION
CAPACITY
DIFFERENTIAL FLUID CAPACITY \
\
\
\
\
\
\
Application Specification
Montero & Montero Sport ............................ 2.4 Pts. (1.1L)\
\
\
\
\
\
\
\
FLUID TYPE
All models use fluid type SAE 80W-90/API GL-5.
TROUBLE SHOOTING
NOTE: See TROUBLE SHOOTING - BASIC PROCEDURES article in the
GENERAL TROUBLE SHOOTING section.
REMOVAL & INSTALLATION
AXLE SHAFTS R & I
Removal
1) Raise and support vehicle. Remove wheels and undercover.
Ensure hub is in free-wheeling position. Place transfer case in 2H
position. Remove drive hub cover, snap ring and shim from axle shaft.
See Fig. 3 . Remove brake calipers and support aside.
2) Disconnect tie rod assembly. Support lower control arm
with jack. Separate ball joints from knuckle. Remove knuckle and front
hub assembly. Using flat-blade pry bar, carefully remove left axle
shaft from differential carrier. DO NOT damage oil seal. On right axle
shaft, remove axle shaft-to-inner shaft flange retaining bolts. Remove
right axle shaft.
CAUTION: Replace circlips on BJ/DOJ splined shaft end.
Installation
1) Install right axle shaft on inner shaft flange. Install
new circlip on DOJ side of left axle shaft. Carefully install left
axle shaft into differential. DO NOT damage oil seal.
2) Reinstall knuckle with front hub assembly. To complete
installation, reverse removal procedure. Install shim and snap ring.
Check axle end play. See Fig. 4. End play should be .016-.028" (.4-.7
mm). If end play is not within specification, install correct shim.
Page 369 of 1501
DIFFERENTIAL & AXLE SHAFTS REAR
1998 Mitsubishi Montero
1997-98 DRIVE AXLES
Mitsubishi Differentials & Axle Shafts - Rear Non-Integral
Montero, Montero Sport
DESCRIPTION
Rear axle features a rigid banjo-type housing with semi-
floating axle shafts. Differential consists of hypoid reduction gears
and straight bevel differential gears. Limited Slip Differential (LSD)\
is available on some models. Locking rear differential is available on
1997-98 Montero and 1998 Montero Sport. See DIFFERENTIAL LOCK - REAR
article.
AXLE RATIO & IDENTIFICATION
Ratio is determined by dividing number of ring gear teeth by
number of drive pinion teeth.
AXLE RATIO SPECIFICATIONS
\
\
\
\
\
\
\
Application Ratio
Montero ..................................................... 4.27:1
Montero Sport
With Wide Fender
2WD ..................................................... 4.22:1
4WD ..................................................... 4.27:1
Without Wide Fender ....................................... 4.64:1
\
\
\
\
\
\
\
LUBRICATION
CAPACITY
REAR AXLE GEAR OIL CAPACITY \
\
\
\
\
\
\
Application Pts. (L)\
Montero .................................................. 6.8 (3.2)\
Montero Sport
Conventional & Locking ................................. 3.2 (1.5)\
Limited Slip ........................................... 5.5 (2.6)\
\
\
\
\
\
\
\
FLUID TYPE
Conventional differentials use SAE 80W or SAE 90W API GL-5.
Limited slip differentials use Mitsubishi Gear Oil (8149630 EX), or
Mopar Gear Oil (4318058) and Mopar Friction Modifier (4318060).
TROUBLE SHOOTING
NOTE: See TROUBLE SHOOTING - BASIC PROCEDURES article in the
GENERAL TROUBLE SHOOTING section.
Page 414 of 1501
* DRIVETRAIN SYSTEMS UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
Drivetrain/Transmission Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Drive/Power Train Assemblies
AUTOMATIC TRANSMISSION/TRANSAXLE ASSEMBLIES
DIFFERENTIAL AND FINAL DRIVE ASSEMBLIES
MANUAL TRANSMISSION/TRANSAXLE ASSEMBLIES
TRANSFER CASE ASSEMBLIES
Drive/Power Train Components
ACTUATORS (ELECTRICAL)
ACTUATORS (VACUUM)
AXLES
BEARINGS AND RACES
BELL CRANKS
BELL HOUSINGS
BUSHINGS (EXTERNAL)
CABLES (SPEEDOMETER)
CABLES (TV, DETENT AND SHIFT)
CARRIER BEARINGS
CLUTCH CABLES AND CABLE HOUSINGS
CLUTCH DISCS (MANUAL TRANSMISSION)
CLUTCH FORKS
CLUTCH LINKAGES (MECHANICAL)
CLUTCH MASTER CYLINDERS
CLUTCH PEDALS
CLUTCH PIVOTS
CLUTCH PRESSURE PLATES
CLUTCH RELEASE BEARINGS
CLUTCH SLAVE CYLINDERS (CONCENTRIC)
CLUTCH SLAVE CYLINDERS (CONVENTIONAL OR EXTERNAL)
COMPANION FLANGES
CONNECTORS
COOLER BYPASS VALVES
COOLER LINES
COOLERS
CV JOINTS
DIP STICK TUBES
DIP STICKS (FLUID LEVEL INDICATORS)
DOWEL PINS, GUIDES AND PILOT HOLES
DRIVE SHAFT FLANGES
DRIVE SHAFTS AND HALF SHAFTS
DUST BOOTS
ENGINE MOUNTS
EXCITER RINGS
FILLER TUBES
FILTERS AND SCREENS
Page 415 of 1501
FLANGES
FLEX PLATES
FLUID LEVEL INDICATORS
FLUIDS AND LUBRICANTS
FLYWHEELS
FORCE MOTORS
GUIDES
HALF SHAFTS
HOSES, LINES AND TUBES
HOUSINGS (BELL, CASE, TAIL (EXTENSION) AND AUXILIARY)
INTERMEDIATE SHAFT SUPPORT BEARINGS
KEY INTERLOCK SYSTEMS
LIMITED SLIPS
LINES
LINKAGES (EXTERNAL)
LOCKING HUB ASSEMBLIES
LOCKING HUB CONTROL KNOBS
LUBRICANTS
METAL-CLAD SEALS
METALASTIC JOINTS
MODULATOR PINS
MODULATORS
MOUNTS (ENGINE, TRANSAXLE AND TRANSMISSION)
ODOMETER DRIVES (MECHANICAL)
ODOMETER HEADS (MECHANICAL)
OIL PANS
PANS
PILOT HOLES
PRESSURE PLATES
PRESSURE SWITCHES
RACES
RUBBER JOINTS (METALASTIC)
SCREENS
SEALS
SEALS (METAL-CLAD)
SELECTOR INTERLOCK SYSTEMS
SERVOS
SHIFT INTERLOCK SYSTEMS (SELECTOR AND KEY INTERLOCK SYSTEMS)
SENSORS
SIDE COVERS
SLIP YOKES
SOLENOIDS
SPEED SENSORS (ELECTRONIC WHEEL AND VEHICLE)
SPEEDOMETER-DRIVEN GEAR HOUSINGS
SPEEDOMETER/ODOMETER DRIVES (MECHANICAL)
SPEEDOMETER/ODOMETER HEADS (MECHANICAL)
SPEEDOMETERS AND ODOMETERS (ELECTRONIC)
SWITCHES
TONE WHEELS
TOOTHED RINGS (TONE WHEELS)
TORQUE CONVERTERS
TRANSAXLE MOUNTS
TRANSDUCERS (TRANSMISSION)
TRANSMISSION COOLERS
TRANSMISSION MOUNTS
TRANSMISSION PANS
TRANSMISSION RANGE INDICATORS (PRNDL)
TUBES
UNIVERSAL JOINTS (CARDON OR CROSS TYPE)
VACUUM CONTROLS
VACUUM HOSES
VACUUM MOTORS
VACUUM-OPERATED SWITCHES
Page 428 of 1501
![MITSUBISHI MONTERO 1998 Owners Guide CLUTCH LINKAGES (MECHANICAL)
See LINKAGES (EXTERNAL) .
CLUTCH MASTER CYLINDERS
CLUTCH MASTER CYLINDER INSPECTION \
\
\](/img/19/57333/w960_57333-427.png "MITSUBISHI MONTERO 1998 Owners Guide CLUTCH LINKAGES (MECHANICAL)
See LINKAGES (EXTERNAL) .
CLUTCH MASTER CYLINDERS
CLUTCH MASTER CYLINDER INSPECTION \
\
\")
CLUTCH LINKAGES (MECHANICAL)
See LINKAGES (EXTERNAL) .
CLUTCH MASTER CYLINDERS
CLUTCH MASTER CYLINDER INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Cover gasket distorted .. A .... Require replacement of cover
gasket.
Cover gasket gummy ...... A .... Require replacement of cover
gasket.
Cylinder leaking fluid
from rear of bore ...... A .. Require repair or replacement.
Cylinder leaking fluid
internally ............. A ............ Require replacement.
Dust boot missing ....... C ..... Require replacement of dust
boot.
Dust boot punctured ..... A ..... Require replacement of dust
boot.
Dust boot torn .......... A ..... Require replacement of dust
boot.
Fluid level incorrect ... B . Require fluid level adjustment.
Housing damaged, affecting
performance ............ A .. Require repair or replacement.
Master cylinder has
residue in reservoir
(make parallel w/brakes
when they are done) .... 2 .......... ( 1) Further inspection
required.
Threads damaged ......... A ...... Require repair replacement
Threads stripped (threads
missing) ............... A ............ Require replacement.
( 1) - DO NOT replace master cylinder unless it exhibits
conditions listed for replacement. You may suggest fluid
change according to OEM service intervals.
\
\
\
\
\
\
\
CLUTCH PEDALS
CLUTCH PEDAL INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Bent, affecting
performance ............ A .. Require repair or replacement.
Broken .................. A .. Require repair or replacement.
Pedal pad missing ....... C .......... Require replacement of
pedal pad.
Pivot bushings worn,
affecting performance .. A .... Require replacement of pivot
bushings.
\
\
\
\
\
\
\
CLUTCH PIVOTS
CLUTCH PIVOT INSPECTION \
\
\
\
\
\
\
Page 432 of 1501
not leaking ............ 2 . Suggest replacement of CV boot.
Cage broken ............. A ... Require repair or replacement
of CV joint.
Housing damaged to the
extent that it no longer
performs its intended
function ............... A ........... (1) Require repair or
replacement of CV joint.
Housing worn to the extent
that it no longer performs
its intended function .. A ........... ( 1) Require repair or
replacement of CV joint.
Holes elongated ......... A ............ Require replacement.
Internal parts binding .. A .. Require repair or replacement.
Internal parts worn ..... A .. Require repair or replacement.
Lubricant missing ....... C ... Require cleaning, inspection,
and repacking of CV joint.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
( 1) - Housing assembly may appear blue in color from normal
manufacturing process of heat-treating the housing.
\
\
\
\
\
\
\
DIP STICK TUBES
DIP STICK TUBE INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Broken .................. A .. Require repair or replacement.
Checkball missing ....... C .. Suggest repair or replacement.
Cracked ................. A .. Require repair or replacement.
Hold down bracket
broken ................. A .. Require repair or replacement.
Hold down bracket
missing ................ C ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
\
\
\
\
\
\
\
DIP STICKS (FLUID LEVEL INDICATORS)
DIP STICK (FLUID LEVEL INDICATOR) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Application incorrect ... B ............ Require replacement.
Broken .................. A ............ Require replacement.
Compressed .............. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Modified ................ A ............ Require replacement.
Stretched ............... A .. Require repair or replacement.
\
\
\
\
\
\
\
DOWEL PINS, GUIDES AND PILOT HOLES
DOWEL PIN, GUIDE AND PILOT HOLE INSPECTION \
\
\
\
\
\
\
Page 435 of 1501
![MITSUBISHI MONTERO 1998 Owners Guide performs its intended
function ............... A ............ Require replacement.
Weights missing ......... A ............ Require replacement.
\
\](/img/19/57333/w960_57333-434.png "MITSUBISHI MONTERO 1998 Owners Guide performs its intended
function ............... A ............ Require replacement.
Weights missing ......... A ............ Require replacement.
\
\")
performs its intended
function ............... A ............ Require replacement.
Weights missing ......... A ............ Require replacement.
\
\
\
\
\
\
\
FLUID LEVEL INDICATORS
See DIP STICKS (FLUID LEVEL INDICATORS) .
FLUIDS AND LUBRICANTS
FLUID AND LUBRICANT INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Application incorrect ... B ........ ( 1) Require replacement.
At service interval ..... 3 ............ Suggest replacement.
Beyond service interval . 3 ............ Suggest replacement.
Burned .................. .. ......... ( 2) Further inspection
required.
Contaminated, for example,
fluid other than hydraulic
fluid present .......... A or B .... ( 3)( 4) Require service.
Exceeding service
interval ............... 3 ............ Suggest replacement.
Hydraulic fluid
incorrect .............. B ............ ( 5) Require service.
Level incorrect ......... B ..... Require correction of fluid
level.
Near service interval ... 3 ............ Suggest replacement.
Rubber master cylinder
cover gasket distorted
and gummy .............. A ............ ( 3) Require service.
Varnished ............... .. ......... ( 6) Further inspection
required.
( 1) - Determine and correct cause.
( 2) - Fluid that is burned indicates a serious problem.
Determine and correct the cause.
( 3) - If a fluid other than hydraulic fluid is present in the
hydraulic system which DOES affect the rubber parts, the
required service is to: 1) remove all components having
rubber parts from the system, 2) flush lines with
denatured alcohol or hydraulic cleaner, 3) repair or
replace all components having rubber parts, and 4) bleed
and flush with correct hydraulic fluid. (Code A)
( 4) - If a fluid other than hydraulic fluid is present in the
hydraulic system which DOES NOT affect the rubber parts,
the required service is to flush and fill with the
correct hydraulic fluid. (Code B)
( 5) - If a fluid other than specification hydraulic fluid is
present in the hydraulic system, the required service
is to flush and fill with the correct hydraulic fluid.
( 6) - Fluid that is varnished may indicate a serious problem.
Determine and correct the cause.
\
\
\
\
\
\
\
FLYWHEELS
NOTE: Clutch disc replacement does not necessitate flywheel
reconditioning, unless other conditions justify the
reason to do so.
Page 440 of 1501
Damaged, affecting
performance ............ A ............ Require replacement.
Missing ................. C ............ Require replacement.
Worn, affecting
performance ............ A ............ Require replacement.
\
\
\
\
\
\
\
LUBRICANTS
See FLUIDS AND LUBRICANTS .
METAL-CLAD SEALS
See SEALS.
METALASTIC JOINTS
See RUBBER JOINTS (METALASTIC) .
MODULATOR PINS
MODULATOR PIN INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Application incorrect ... B ............ Require replacement.
Missing ................. C ............ Require replacement.
\
\
\
\
\
\
\
MODULATORS
MODULATOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Bent, affecting
performance ............ A ............ Require replacement.
Contaminated (water, fuel,
etc.) .................. A ........ ( 1) Require replacement.
Housing cracked ......... A ............ Require replacement.
Inoperative ............. A ........ ( 2) Require replacement.
Leaking fluid
externally ............. A .. Require repair or replacement.
Leaking fluid
internally ............. A ............ Require replacement.
Leaking vacuum .......... A ............ Require replacement.
Nipple broken ........... A ............ Require replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
( 1) - Further inspection is required to determine the cause
of the contamination.
( 2) - Inoperative includes intermittent operation or out of OEM
specification.
\
\
\
\
\
\
\
MOUNTS (ENGINE, TRANSAXLE AND TRANSMISSION)
MOUNT (ENGINE, TRANSAXLE AND TRANSMISSION) INSPECTION \
\
\
\
\
\
\
Page 443 of 1501
![MITSUBISHI MONTERO 1998 Owners Guide vent may force fluid past the seal. \
\
\
\
\
\
\
SEALS](/img/19/57333/w960_57333-442.png "MITSUBISHI MONTERO 1998 Owners Guide vent may force fluid past the seal. \
\
\
\
\
\
\
SEALS")
vent may force fluid past the seal. \
\
\
\
\
\
\
SEALS (METAL-CLAD)
See SEALS.
SELECTOR INTERLOCK SYSTEMS
See
SHIFT INTERLOCK SYSTEMS (SELECTOR AND KEY INTERLOCK SYSTEMS) .
SERVOS
See ACTUATORS (VACUUM) .
SHIFT INTERLOCK SYSTEMS (SELECTOR AND KEY INTERLOCK SYSTEMS)
See:
ACTUATORS (ELECTRICAL)
CABLES
LINKAGES (EXTERNAL)
SWITCHES
SENSORS
SENSOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Inoperative ............. A ........... ( 2) Require repair or
replacement.
Leaking
(vacuum/fluid/air) ..... A ............ Require replacement.
Out of adjustment ....... B .......... ( 3) Further inspection
required.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
Page 452 of 1501
![MITSUBISHI MONTERO 1998 Owners Guide VENT INSPECTION \
\
\
\
\
\
\
Condition Code](/img/19/57333/w960_57333-451.png "MITSUBISHI MONTERO 1998 Owners Guide VENT INSPECTION \
\
\
\
\
\
\
Condition Code")
VENT INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Broken .................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
Plugged ................. A ........... (1) Require repair or
replacement.
( 1) - A plugged vent may force fluid past the seal.
\
\
\
\
\
\
\
VIBRATION DAMPERS
VIBRATION DAMPER INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Broken .................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
Out of position ......... B .. Require repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
\
\
\
\
\
\
\
WHEEL ATTACHMENT HARDWARE
NOTE: For conditions noted below, also check conditions of
wheel stud holes.
CAUTION: Proper lug nut torque is essential. Follow recommended
torque specifications and tightening sequence. DO NOT
lubricate threads unless specified by the vehicle
manufacturer.
WHEEL ATTACHMENT HARDWARE INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Bent .................... A ............ Require replacement.
Broken .................. A ........ ( 1) Require replacement.
Loose ................... B ... Require repair or replacement
of affected component.
Lug nut installed
backward ............... B .. Require repair or replacement.
Lug nut mating surface
dished ................. A ..... Require replacement of nut.
Lug nut mating type
incorrect .............. B ..... Require replacement of nut.
Lug nut rounded ......... A . ( 2) Require replacement of nut.
Lug nut seized .......... A . ( 2) Require replacement of nut.
Stud incorrect .......... B .... Require replacement of stud.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
( 1) - Some manufacturers require replacement of all studs on
that wheel if two or more studs or nuts on the same wheel
are broken or missing.
( 2) - Only required if removing wheel.
\
\
\
\
\
\
\
