fuse MITSUBISHI MONTERO 1998 Workshop Manual

2 - 10 Amp (Red)
Radio
3 - 10 Amp (Red)
Heater Relay
4 - 10 Amp (Red)
4A/T
5 - 20 Amp (Yellow)
Front & Rear Air Conditioner
6 - 10 Amp (Red)
Turn Signals
7 - 10 Amp (Red)
Meters
8 - 10 Amp (Red)
Horn
9 - 15 Amp (Light Blue)
Wiper
10 - 10 Amp (Red)
Power Window Control
11 - 10 Amp (Red)
Four Wheel Drive System, Overdrive Control (Vehicles With
Automatic Transmission Only)
12 - 15 Amp (Light Blue)
Power Door Locks
13 - 10 Amp (Red)
Doom Light, Clock
14 - 15 Amp (Light Blue)
Backup Lights
15 - 15 Amp (Light Blue)
Stoplights
16 - 25 Amp
Heater
17 - 15 Amp (Light Blue)
Accessory Socket
18 - 10 Amp (Red)
Rear Heater
19 - Spare Fuse
ENGINE COMPARTMENT
Fig. 4: Engine Compartment Fusible Links
Courtesy of Mitsubishi Motor Sales of America.

meter long with force of one Newton applied). Some conversions are:
* A meter kilogram is about 7.2 foot pounds.
* A foot pound is about 1.4 Newton-meters.
* A centimeter kilogram (cmkg) is equal to .9 inch pounds.
PRESSURE
Pressure is another complicated measurement. Pressure is
described as a force or weight applied to a given area. Our common
unit is pounds per square inch. Metric units can be expressed in
several ways. One is the kilogram per square centimeter (kg/cm
).
Another unit of pressure is the Pascal (force of one Newton on an area
of one square meter), which equals about 4 ounces on a square yard.
Since this is a very small amount of pressure, we usually see the
kiloPascal, or kPa (1000 Pascals). Another common automotive term for
pressure is the bar (used by German manufacturers), which equals 10
Pascals. Thoroughly confused? Try the examples below:
* Atmospheric pressure at sea level is about 14.7 psi.
* Atmospheric pressure at sea level is about 1 bar.
* Atmospheric pressure at sea level is about 1 kg/cm
.
* One pound per square inch is about 7 kPa.
CONVERSION FACTORS
CONVERSION FACTORS
\
\
\
\
\
\
\

TO CONVERT TO  MULTIPLY BY
\b
\
\
\
\
\
 \
\



LENGTH


Millimeters (mm) Inches  .03937

Inches Millimeters  25.4

Meters (M) Feet  3.28084

Feet Meters  .3048

Kilometers(Km) Miles  .62137
\b
\
\
\
\
\
 \
\



AREA


Square Centimeters (cm) Square Inches  .155

Square Inches Square Centimeters  6.45159
\b
\
\
\
\
\
 \
\



VOLUME


Cubic Centimeters Cubic Inches  .06103

Cubic Inches Cubic Centimeters  16.38703

Liters Cubic Inches  61.025

Cubic Inches Liters  .01639

Liters Quarts  1.05672

Quarts Liters  .94633

Liters Pints  2.11344

Pints Liters  .47317

Liters Ounces  33.81497

Ounces Liters  .02957
\b
\
\
\
\
\
 \
\



WEIGHT


Grams Ounces  .03527

Ounces Grams  28.34953

Kilograms Pounds  2.20462

Pounds Kilograms  .45359
\b
\
\
\
\
\
 \
\



WORK


Centimeter Kilograms Inch Pounds  .8676

Pounds/Sq. Inch Kilograms/Sq.Centimeter .07031

Bar Pounds/Sq. Inch  14.504

MIRRORS - POWER
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Power Mirrors
Eclipse, Galant, Mirage, Montero, Montero Sport, 3000GT
DESCRIPTION & OPERATION
Electric remote control mirrors are controlled by a dual-
control switch mounted on driver's door, dash or center console
depending on model. Left/right switch directs current to desired
mirror. Horizontal/vertical switch directs current to electric motor
in mirror assembly, controlling up/down and left/right adjustment.
Heated mirrors are controlled by defogger relay.
TROUBLE SHOOTING
POWER MIRRORS INOPERATIVE
Check for faulty fuse, faulty power mirror switch or faulty
power mirror motor. See POWER MIRROR FUSE IDENTIFICATION table.
POWER MIRROR FUSE IDENTIFICATION TABLE









\









\









\









\









\









\






Application Fuse No.
Eclipse ............................................... 13
Galant ................................................. 9
Mirage ................................................. 7
Montero & 3000GT ....................................... 5
Montero Sport .......................................... 8









\









\









\









\









\









\






COMPONENT TESTS
POWER MIRROR MOTOR TEST
Connect 12-volt power source to mirror connector terminals.
See Figs. 1 -6. Replace mirror as necessary.
Fig. 1: Identifying Power Mirror Operational Test Charts (Eclipse,
Galant, Montero - W/Heater & Montero Sport - W/Heater)
Courtesy of Chrysler Corp.

PARASITIC LOAD EXPLANATION & TEST PROCEDURES
1998 Mitsubishi Montero
GENERAL INFORMATION
Parasitic Load Explanation & Test Procedures
* PLEASE READ THIS FIRST *
This article is provided for general information only. Not
all procedures apply to all makes and models.
GENERAL INFORMATION
The term Parasitic Load refers to electrical devices that
continue to use or draw current after the ignition switch is turned to
OFF position. This small amount of continuous battery draw is
expressed in milliamps (mA). On Ford Motor Co. and General Motors
vehicles produced after 1980, a typical Parasitic Load should be no
more than 50 milliamps (0.050 amps).
Vehicles produced since 1980 have memory devices that draw
current with ignition off for as long as 20 minutes before shutting
down the Parasitic Drain. When Parasitic Load exceeds normal
specifications, the vehicle may exhibit dead battery and no-start
condition.
Follow test procedure for checking Parasitic Loads to
completion. A brief overview of a suggested test procedure is included
along with some typical Parasitic Load specifications. Refer to the
GENERAL MOTORS PARASITIC LOAD TABLE chart.
TESTING FOR PARASITIC LOAD
INTRODUCTION
CAUTION: Always turn ignition off when connecting or disconnecting
battery cables, battery chargers or jumper cables. DO NOT
turn test switch to OFF position (which causes current to run
through ammeter or vehicle electrical system).
NOTE: Memory functions of various accessories must be reset after
the battery is reconnected.
The battery circuit must be opened to connect test switch
(shunt) and ammeter into the circuit. When a battery cable is removed,\
timer circuits within the vehicle computer are interrupted and
immediately begin to discharge. If in doubt about the condition of the
ammeter fuse, test it with an ohmmeter prior to beginning test. An
open fuse will show the same reading (00.00) as no parasitic drain.
Begin test sequence with the meter installed and on the 10-amp scale.
Select lower scale to read parasitic draw.
TEST PROCEDURE USING TEST SWITCH
1) Turn ignition off. Remove negative battery terminal cable.
Install Disconnect Tool (J-38758) test switch male end to negative
battery cable. Turn test switch knob to OFF position (current through
meter). Install negative battery cable to the female end of test
switch.
2) Turn test switch knob to ON position (current through
switch). Road test vehicle with vehicle accessories on (radio, air
conditioner, etc.). After road test, turn ignition switch to LOCKED
position and remove key. Connect ammeter terminals to test switch

terminals. See Fig. 1. Select 10-amp scale.
3) Turn off all electrical accessories. Turn off interior
lights, underhood lamp, trunk light, illuminated entry, etc. To avoid
damaging ammeter or obtaining a false meter reading, all accessories
must be off before turning test switch knob to OFF position.
4) Turn test switch knob to OFF position to allow current to
flow through ammeter. If meter reads wrong polarity, turn test switch
to ON position and reverse leads. Turn test switch to OFF position.
Observe current reading. If reading is less than 2 amps, turn test
switch to ON position to keep electrical circuits powered-up.
5) Select low amp scale. Switch lead to the correct meter
position. Turn test switch to OFF position and compare results to
normal current draw. See the GENERAL MOTORS PARASITIC LOAD TABLE . If
current draw is unusually high for the vehicle's overall electrical
system, remove system fuses one at a time until current draw returns
to normal.
6) Turn test switch to ON position each time door is opened
or fuse is removed. Turn switch to OFF position to read current draw
value through meter. When the cause of excessive current drain has
been located and repaired, remove test switch and reconnect negative
battery cable to the negative battery terminal.
Fig. 1: Connecting Kent-Moore Disconnect Tool (J-38758)
Courtesy of General Motors Corp.
GENERAL MOTORS PARASITIC LOAD TABLE (MILLIAMPS)









\









\









\









\









\









\









\

POWER WINDOWS
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Power Windows
Mirage, Montero, Montero Sport & 3000GT
DESCRIPTION & OPERATION
With ignition switch in RUN position, battery voltage is
applied to master power window switch located on driver's door. Master
power window switch provides power and ground for all power window
switches and motors. Master power window switch offers one-touch
operation of driver's window. A solid state control unit, incorporated
in master switch, fully lowers driver's window when switch is
completely depressed. Master switch also includes lock-out feature to
prevent passengers from operating any of the other power window door
switches.
COMPONENT LOCATIONS
COMPONENT LOCATIONS TABLE








\









\









\









\









\









\






Component Location
Power Window Relay ( 1) .......... In Passenger Compartment
Fuse/Relay Block
( 1) - See Fig. 1.









\









\









\









\









\









\






TROUBLE SHOOTING
POWER WINDOWS INOPERATIVE
Check for faulty fusible link, faulty power window relay or
faulty power window switches. See WIRING DIAGRAMS.
ONE WINDOW FAILS TO OPERATE
If one window does not operate, even if both master and
passenger side power window switches are pressed, check for faulty
master power window switch or power window motor that is inoperative.
If one window does not operate only when either master or passenger
side power window switch is pressed, but does operate when both
switches are pressed, check power window switch that is inoperative.
ONE-TOUCH SWITCH FUNCTION INOPERATIVE
Replace master power window switch.
COMPONENT TESTS
CIRCUIT BREAKER TEST
Press UP switch to fully close window. Continue to press
switch for 10 seconds. Release UP switch and immediately press DOWN
switch. If window begins to open within 60 seconds, circuit breaker is

okay. Circuit breaker is part of window motor.
POWER WINDOW RELAY TEST
Mirage & 3000GT
1) Remove power window relay from fuse/relay block. See
Fig. 1 . Check for continuity between power window relay terminals No.
1 and 3. See Fig. 5. Continuity should be present.
2) Connect positive lead of a 12-volt battery to power window
relay terminal No. 1, and negative lead of battery to terminal No. 3.
Continuity should be present between terminals No. 4 and 5 with
voltage applied. Replace power window relay if continuity is not as
specified.
Montero & Montero Sport
1) Remove power window relay from fuse/relay block. See
Fig. 2 or 3. Check for continuity between power window relay terminals
No. 2 and 4. See Fig. 6. Continuity should be present.
2) Connect positive lead of a 12-volt battery to power window
relay terminal No. 2, and negative lead of battery to terminal No. 4.
Continuity should be present between terminals No. 1 and 3 with
voltage applied. Replace power window relay if continuity is not as
specified.
Fig. 1: Locating Power Window Relay (Mirage)
Courtesy of Mitsubishi Motor Sales of America

terminal to relay terminal No. 3. Continuity should exist between
relay terminals No. 4 and 5. Replace relay as necessary.
Eclipse (M/T With Theft Alarm)
1) Remove starter relay. See STARTER RELAY LOCATIONS table.
With no power supplied to any relay, continuity should exist between
relay terminals No. 1 and 3. See WIRING DIAGRAMS.
2) Connect a jumper wire from positive battery terminal to
relay terminal No. 3 and another jumper wire from negative battery
terminal to relay terminal No. 1. Continuity should exist between
relay terminals No. 2 and 5. Replace relay as necessary.
Eclipse (M/T Without Theft Alarm)
1) Remove starter relay. See STARTER RELAY LOCATIONS table.
With no power supplied to any relay, continuity should exist between
relay terminals No. 1 and 2. See WIRING DIAGRAMS.
2) Connect a jumper wire from positive battery terminal to
relay terminal No. 1 and another jumper wire from negative battery
terminal to relay terminal No. 2. Continuity should exist between
relay terminals No. 3 and 4. Replace relay as necessary.
Mirage
1) Remove starter relay. See STARTER RELAY LOCATIONS table.
With no power supplied to any relay, continuity should exist between
relay terminals No. 1 and 3. See WIRING DIAGRAMS.
2) Connect a jumper wire from positive battery terminal to
relay terminal No. 3 and another jumper wire from negative battery
terminal to relay terminal No. 1. Continuity should exist between
relay terminals No. 2 and 4. Replace relay as necessary.
Montero Sport With A/T
1) Remove starter relay. See STARTER RELAY LOCATIONS table.
With no power supplied to any relay, continuity should exist between
relay terminals No. 1 and 3. See WIRING DIAGRAMS.
2) Connect a jumper wire from positive battery terminal to
relay terminal No. 3 and another jumper wire from negative battery
terminal to relay terminal No. 1. Continuity should exist between
relay terminals No. 2 and 5. Replace relay as necessary.
Montero Sport With M/T
1) Remove starter relay. See STARTER RELAY LOCATIONS table.
With no power supplied to any relay, continuity should exist between
relay terminals No. 1 and 3. See WIRING DIAGRAMS.
2) Connect a jumper wire from positive battery terminal to
relay terminal No. 1 and another jumper wire from negative battery
terminal to relay terminal No. 3. Continuity should exist between
relay terminals No. 2 and 4. Replace relay as necessary.
3000GT
1) Remove starter relay. See STARTER RELAY LOCATIONS table.
With no power supplied to any relay, continuity should exist between
relay terminals No. 1 and 2 and between relay terminals No. 3 and 4.
See Fig. 1 .
2) Connect a jumper wire from positive battery terminal to
relay terminal No. 1 and another jumper wire from negative battery
terminal to relay terminal No. 2. Continuity should exist between
relay terminals No. 3 and 5. See Fig. 1. Replace relay as necessary.
STARTER RELAY LOCATIONS TABLE









\









\









\









\









\









\









\







Application Location
Diamante ............. At Left Front Fender, Inside Fuse/Relay Block

Eclipse
Without Theft Alarm ........................ Behind Center Of Dash
With Theft Alarm .... Under Left Of Instrument Panel, On Relay Box
Galant ................................... Inside Right Front Fender
Mirage .......................... In Left Underhood Fuse/Relay Block
Montero ...................................... Behind Center Of Dash
Montero Sport ................... In Left Underhood Fuse/Relay Block
3000GT ......................... In Right Underhood Fuse/Relay Block









\









\









\









\









\









\









\







Fig. 1: Identifying Starter Relay Connector Terminals (3000GT)
Courtesy of Chrysler Corp.
BENCH TESTING
* PLEASE READ THIS FIRST *
CAUTION: Perform tests in less than 10 seconds to prevent damage to
coil.
NO-LOAD TEST
1) Install starter in soft-jawed vise. Connect starter in
series with a fully-charged 12-volt battery. Connect a 100-amp ammeter
and carbon pile rheostat in series with positive battery post and
starter motor terminal. See Fig. 2.
2) Install voltmeter across starter motor. Adjust carbon pile
rheostat to full resistance. Connect cable from starter motor body to
negative battery terminal. Adjust carbon pile rheostat to proper test
voltage. Ensure maximum amperage is as specified and starter rotates

STEERING COLUMN SWITCHES
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Steering Column Switches
Diamante, Eclipse, Galant, Mirage, Montero, Montero Sport,
3000GT
* PLEASE READ THIS FIRST *
WARNING: Deactivate air bag system before performing any service
operation. See AIR BAG RESTRAINT SYSTEMS article. DO NOT
apply electrical power to any component on steering column
without first deactivating air bag system. Air bag may
deploy.
DESCRIPTION
Headlight and turn signal switch and wiper/washer switch are
part of combination switch. For information on cruise control switch
(right side of column), see appropriate CRUISE CONTROL SYSTEMS
article.
COMPONENT LOCATIONS
COMPONENT LOCATIONS TABLE








\









\









\









\









\









\






Component Location
Headlight Relay .................... In Engine Compartment
Fuse/Relay Block
Foglight Relay
Except Montero & Montero Sport ... In Engine Compartment
Fuse/Relay Block
Taillight Relay
Except Montero Sport ............. In Engine Compartment
Fuse/Relay Block
Turn Signal/Hazard Flasher Unit
Diamante ............................ At Left Kick Panel
Eclipse .......................... Behind Center Of Dash
Except Diamante & Eclipse ..... Behind Left Side Of Dash
Wiper Relay
Front
Except Diamante & 3000GT .......... On Steering Column
Rear
Eclipse ........................ Behind Center Of Dash
Montero & Montero Sport .............. On Relay Block,
Behind Left Side Of Dash
3000GT ................ Behind Left Rear Quarter Panel









\









\









\









\









\









\






COMPONENT TESTS
DIAMANTE
Turn Signal, Lighting & Dimmer/Passing Switch Tests
Disconnect steering column combination switch connector. See
Fig. 1 . Check continuity between specified terminals. See
STEERING COLUMN COMBINATION SWITCH CONTINUITY CHECK TABLE (DIAMANTE) .
