ABBREVIATIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
COMMONLY USED ABBREVIATION
"A" ABBREVIATION TABLE
"A" ABBREVIATION TABLE







\









\








\









\









\









\









\







ABBREVIATION DEFINITION










\








\b
\









\









\









\









\









\






A Amperes

A/C Air Conditioning

A/T Automatic Transmission/Transaxle

AAP Auxiliary Accelerator Pump

AB Air Bleed

ABCV Air Bleed Control Valve

ABDC After Bottom Dead Center

ABRS Air Bag Restraint System

ABS Anti-Lock Brake System

AC Alternating Current

ACC A/C Clutch Compressor

ACCS A/C Cycling Switch

ACCUM Accumulator

ACCY Accessory

ACT Air Charge Temperature Sensor

ACV Thermactor Air Control Valve

ADJ Adjust or Adjustable

ADV Advance

AFS Airflow Sensor

AI Air Injection

AIR or A.I.R. Air Injection Reactor

AIS Air Injection System

ALCL Assembly Line Communications Link

ALDL Assembly Line Diagnostic Link

ARC Automatic Ride Control

ASCD Automatic Speed Control Device

ASCS Air Suction Control Solenoid

ASD Auto Shutdown

ASDM Air Bag System Diagnostic Module

ASV Air Suction Valve

ATC Automatic Temperature Control

ATDC After Top Dead Center

ATF Automatic Transmission Fluid

ATS Air Temperature Sensor

AXOD Automatic Transaxle Overdrive

Abs. Absolute

Accy. Accessory

Alt. Alternator or Altitude

Amp. Ampere

Assy. Assembly

Auto. Automatic

Aux. Auxiliary

Avg. Average











\








\









\









\









\









\









\





\f

"B" ABBREVIATION TABLE
"B" ABBREVIATION TABLE

COOLING SYSTEM SPECIFICATIONS & ENGINE COOLING FANS
1998 Mitsubishi Montero
1997-98 ENGINE COOLING
Mitsubishi Specifications & Electric Cooling Fans
Diamante, Eclipse, Galant, Mirage, Montero, Montero Sport,
3000GT
SPECIFICATIONS
BELT ADJUSTMENT
NOTE: Use illustration for water pump drive belt routing. See
Figs. 1-6. The terms alternator and generator are used
interchangeably.
BELT ADJUSTMENT









\









\









\









\









\









\









\







Application Deflection (1) In. (mm)
Diamante ....................................................... ( 2)
Eclipse & Galant
2.0L Non-Turbo ............................................... ( 2)
2.0L Turbo & 2.4L
Generator & Water Pump .................... 0.35-0.45 (9.0-11.4)\
Water Pump & Power Steering ................ 0.22-0.32 (5.6-8.1)\
Mirage
1.5L ........................................ 0.34-0.45 (8.6-11.4)\
1.8L ......................................................... ( 2)
Montero
A/C .......................................... 0.26-0.30 (6.6-7.6)\
Generator & Water Pump ................... ( 3) 0.22-0.26 (5.6-6.6)
Water Pump & Power Steering ................ 0.54-0.70 (13.7-17.8)\
Montero Sport
2.4L
A/C ........................................ 0.24-0.26 (6.1-6.6)\
Generator & Water Pump ................. ( 4) 0.28-0.35 (7.1-8.9)
Water Pump & Power Steering ................ 0.22-0.30 (5.6-7.6)\
3.0L
A/C ........................................ 0.22-0.26 (5.6-6.6)\
Generator & Water Pump ................. ( 3) 0.20-0.27 (5.1-6.8)
Water Pump & Power Steering .............. 0.52-0.68 (13.2-17.3)\
3000GT ......................................................... ( 3)
( 1) - With 22 lbs. (10 kg) pressure applied midway on belt run.
Values are for a used belt.
( 2) - Water pump is driven by timing belt. Timing belt deflection is
controlled by timing belt automatic tensioner.
( 3) - Measured between water pump pulley and crankshaft pulley.
( 4) - Measured between water pump pulley and generator pulley.









\









\









\









\









\









\









\

Fig. 1: Routing Timing/Water Pump Belt (Diamante & 3000GT SOHC)
Courtesy of Mitsubishi Motor Sales of America.
Fig. 2: Routing Alternator & Water Pump Belt (Eclipse - 2.0L
Turbo & 2.4L, Galant & Mirage - 1.5L)
Courtesy of Mitsubishi Motor Sales of America.

* ELECTRICAL SYSTEM UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
Electrical System Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
ACTUATOR MOTORS (SOLENOIDS) (ELECTRIC)
ACTUATOR MOTORS (VACUUM)
AIR BAGS
ALTERNATORS AND GENERATORS
AMPLIFIERS
ANTENNAS
BATTERIES
BATTERY CABLES
BATTERY CABLES
BATTERY HOLD DOWN HARDWARE
BATTERY TRAYS AND HOLD DOWN HARDWARE
BATTERY WIRES
BELTS
BULB SOCKETS
BULBS, SEALED BEAMS AND LEDS
CD PLAYERS
CIGARETTE LIGHTER ASSEMBLIES
CIRCUIT BREAKERS
CLUTCH SWITCHES
CONNECTORS
CONTROL MODULES
CRUISE CONTROL BRAKE SWITCHES
CRUISE CONTROL CABLES
CRUISE CONTROL CLUTCH SWITCHES
CRUISE CONTROL LINKAGES AND CABLES
CRUISE CONTROL RESERVOIRS
CRUISE CONTROL TUBES
CRUISE CONTROL VACUUM DUMP RELEASE VALVES
CRUISE CONTROL VACUUM HOSES, TUBES AND RESERVOIRS
CRUISE CONTROL VEHICLE SPEED SENSORS
DEFOGGERS
DEFROSTERS
DELAYS
DIMMERS
ELECTRIC HEATERS
EQUALIZERS
FUSE BLOCKS
FUSE BOXES AND BLOCKS
FUSES, FUSIBLE LINKS AND CIRCUIT BREAKERS
FUSIBLE LINKS
GAUGES
GENERATORS
GROUND CABLES AND STRAPS
GROUND STRAPS
HEADLIGHT ADJUSTERS
HEATING ELEMENTS (DEFROSTERS, DEFOGGERS, ELECTRIC HEATERS AND SEATS)
HORNS AND SIRENS

hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... (1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Inoperative ............. A ........ ( 2) Require replacement.
Leaking (vacuum) ........ A .. Require repair or replacement.
Linkage bent,
affecting performance .. A ... Require repair or replacement
of linkage.
Linkage bent, not
affecting performance .. 2 ... Suggest repair or replacement
of linkage.
Linkage binding,
affecting performance .. A ... Require repair or replacement
of linkage.
Linkage binding, not
affecting performance .. 1 .. Suggest repair or replacement
of linkage.
Linkage broken .......... A ... Require repair or replacement
of linkage.
Linkage loose, affecting
performance ............ A ... Require repair or replacement
of linkage.
Linkage loose, not
affecting performance .. 1 ... Suggest repair or replacement
of linkage.
Linkage missing ......... C ............ Require replacement.
Linkage noisy ........... 2 .. Suggest repair or replacement.
Missing ................. C ............ Require replacement.
Noisy ................... 2 .. Suggest repair or replacement.
Out of adjustment ....... A .. Require repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Inoperative includes intermittent operation or out of
OEM specification.









\









\









\









\









\









\









\


AIR BAGS
For all air bag components and conditions, refer to vehicle
manufacturer's specifications for diagnosis and parts replacement.
ALTERNATORS AND GENERATORS
NOTE: If components have been added that increase vehicle
electrical load requirement (for example, sound systems,
air conditioning, alarm systems, etc.), charging system
output must meet the increased demand.
ALTERNATOR AND GENERATOR INSPECTION









\









\









\









\









\









\









\


Condition Code Procedure
Alternator output meets
OEM specification but is
insufficient for add-on

electrical load ........ 2 ... Suggest upgrade of alternator
or removal of excess electrical
load.
Alternator's rated output
is below OEM
specification .......... B ............ Require replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware non-
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... (1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Diode inoperative ....... A ........... ( 2) Require repair or
replacement.
Housing broken, affecting
performance ............ A .. Require repair or replacement.
Housing broken, not
affecting performance .. .. ........ No service suggested or
required.
Housing cracked, affecting
performance ............ A .. Require repair or replacement.
Housing cracked, not
affecting performance .. 1 .. Suggest repair or replacement.
Inoperative ............. A ........... ( 2) Require repair or
replacement.
Noisy ................... 2 .. Suggest repair or replacement.
Pulley incorrect ........ B ............ Require replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Terminal resistance
(voltage drop) out of
specification .......... A .. Require repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Voltage drop out of
specification .......... A .. Require repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Inoperative includes intermittent operation or out of OEM
specification.

GENERATORS
See ALTERNATORS AND GENERATORS .
GROUND CABLES AND STRAPS
GROUND CABLE AND STRAP INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Corroded, affecting
performance ............ A .. Require repair or replacement.
Corroded, not affecting
performance ............ 2 .. Suggest repair or replacement.
Insulation damaged,
exposing conductors .... 2 ............ Suggest replacement.
Loose ................... A ................. Require repair.
Missing ................. C ............ Require replacement.
Open .................... A .. Require repair or replacement.
Resistance high ......... A .. Require repair or replacement.
Terminal resistance
(voltage drop) is out of
specification .......... B .. Require repair or replacement.
Voltage drop out of
specification .......... B .. Require repair or replacement.









\









\









\









\









\









\









\


GROUND STRAPS
See GROUND CABLES AND STRAPS .
HEADLIGHT ADJUSTERS
HEADLIGHT ADJUSTER INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Bent, preventing
adjustment ............. A .. Require repair or replacement.
Broken .................. A .. Require repair or replacement.
Indicator broken ........ A ............ Require replacement.
Indicator missing ....... C ............ Require replacement.
Missing ................. C .......... Require replacement of

GENERATOR & REGULATOR
1998 Mitsubishi Montero
1998 STARTING & CHARGING SYSTEMS
Mitsubishi - Generators & Regulators
Diamante, Eclipse, Galant, Mirage, Montero, Montero Sport,
3000GT
DESCRIPTION & OPERATION
NOTE: The terms generator and alternator are interchangeable.
Mitsubishi generators are conventional 3-phase, self-
rectifying type units containing 6 diodes (3 positive and 3 negative)
which are used to rectify current. All models use a case-mounted
Integrated Circuit (IC) voltage regulator.
Generator relay or resistor with diode is used to ensure
charging of battery even if charging indicator light is defective.
ADJUSTMENTS
BELT TENSION
For belt tension, see DRIVE BELT ADJUSTMENT table.
DRIVE BELT ADJUSTMENT TABLE









\









\









\









\









\









\









\







( 1) Deflection ( 1) Deflection
Application New Belt In. (mm) Used Belt In. (mm\
)
Diamante ( 2) ........... .24-.28 (6.0-7.2) ..... .32-.37 (8.2-9.3)
Eclipse
2.0L Non-Turbo ( 3) ... .30-.41 (7.5-10.5) ... .35-.47 (9.0-12.0)
2.0L Turbo ( 4) ....... .30-.35 (7.5-9.0) ............ .39 (10.0)
2.4L ( 4) ............. .30-.35 (7.5-9.0) ............ .39 (10.0)
Galant ( 4) ............. .30-.35 (7.5-9.0) ............ .39 (10.0)
Mirage ( 3)
1.5L ................. .36-.42 (9.2-10.6) .... .26-.33 (6.6-8.3\
)
1.8L ................. .33-.39 (8.5-10.0) .... .28-.31 (7.0-8.0\
)
Montero ( 4) ............ .22-.29 (5.5-7.5) ..... .31-.35 (8.0-9.0)
Montero Sport
2.4L ( 4) ............. .22-.29 (5.5-7.5) ..... .30-.33 (7.5-8.3)
3.0L ( 4) ............. .22-.29 (5.5-7.5) ..... .31-.35 (8.0-9.0)
3000GT
DOHC ( 5) ............. .14-.16 (3.5-4.0) ..... .16-.20 (4.0-5.0)
SOHC ( 6) ............. .16-.20 (4.0-5.0) ..... .24-.32 (6.0-8.0)
( 1) - With 22 lbs. (10 kg) pressure applied midway on belt run.
( 2) - Measure between A/C compressor pulley and crankshaft pulley.
( 3) - Measure between crankshaft pulley and generator pulley.
( 4) - Measure between water pump pulley and generator pulley.
( 5) - Measure between crankshaft pulley and idler pulley.
( 6) - Measure between power steering pulley and idler pulley.









\









\









\









\









\









\









\







TROUBLE SHOOTING
NOTE: See TROUBLE SHOOTING article in the GENERAL INFORMATION
section.

WIRING DIAGRAM COMPONENT LOCATIONS
When trying to locate a component in a wiring diagram and you
don't know the specific system where it is located, use this handy
component locator to find the system wiring diagram in which the
component is located. Then, go to that system and locate the component
within the wiring diagram.
For example, if you don't know the specific system in which
the ignition switch is located, look up ignition switch in the wiring
diagram component location tables and go to the appropriate wiring
diagram(s) which contain either full or partial views of the ignition
switch. The full view of the ignition switch is located in Power
Distribution.
The first listing for the component will be the full or most
complete view of the component. Additional listings will be partial
views of the component. Not all components are used on all models.
All components will have a partial view in Ground
Distribution and Power Distribution. Data Link Connectors show
connecting circuits between modules. Alternate names for components
may be listed in wiring diagram component locations tables.
WIRING DIAGRAM COMPONENT LOCATIONS TABLE









\









\









\









\









\









\









\







Component Wiring Diagram
ABS Electronic Control Unit ....................... Anti-Lock Brakes
Data Link Connectors
ABS Hydraulic Unit ................................ Anti-Lock Brakes
Acceleration Sensor ............................... Anti-Lock Brakes
Accessory Delay Relay ................................ Power Windows
A/C Compressor Clutch Relay ..................... Engine Performance
A/C Sensor ...................................... Engine Performance
A/C Pressure Switch ............................. Engine Performance
Adaptive Lamp Control Module ....................... Exterior Lights
Air Bag(s) ................................ Air Bag Restraint System\
Air Bag Module ............................ Air Bag Restraint System
Air Bag Sensor(s) ......................... Air Bag Restraint System\
Air Injection Pump Relay ........................ Engine Performance
Air Temperature Sensor ............................ Overhead Console
Alternator (Generator) ..................... Generators & Regulators\
Anti-Theft Control Module ........................ Anti-Theft System
Starters
Autolamp Control Relay ........................... Headlight Systems
Daytime Running Lights
Automatic Shutdown (ASD) Relay .................. Engine Performance\
Generators & Regulators
Autostick Switch ................................ Engine Performance
Auxiliary Battery Relay .................... Generators & Regulators
Back-Up Lights ...................................... Back-Up Lights
Exterior Lights
Barometric (BARO) Pressure Sensor ............... Engine Performance\
Battery ......................................... Power Distribution
Battery Temperature Sensor ...................... Engine Performance
Body Control Module .......................... Body Control Computer
Anti-Theft System
Daytime Running Lights
Engine Performance
Headlight Systems
Warning Systems
Boost Control Solenoid .......................... Engine Performance
Boost Sensor .................................... Engine Performance
Brake Fluid Level Switch .................. Analog Instrument Panels

1 - 60 Amp
Battery
2 - 100 Amp
Alternator
3 - 20 Amp (Yellow)
Multipoint Injection
4 - 40 Amp
Ignition Switch
5 - 30 Amp (Green)
Rear Window Defogger
6 - 30 Amp (Green)
Power Window Control
7 - 30 Amp (Green)
Air Conditioner
8 - 40 Amp
Lights
9 - 10 Amp (Red)
AIR CONDITIONING & HEAT Compressor
10 - 25 Amp
Condenser Fan
11 - 10 Amp (Red)
Tail Lights
12 - 10 Amp (Red)
Headlight Upper Beam
13 - 10 Amp (Red)
Hazard Warning Flashers
