MITSUBISHI OUTLANDER 2020 Owner's Manual (in English)

Vents 7-4 Comfort controls
7
Air flows mainly to the leg area. Air flows to the leg area, the windshield and
the door windows.
Air flows mainly to the windshield and the door windows.
Foot position
Foot/Defroster position
NOTE
 The foot/defroster ai
r flow ratio can be
adjusted with the mode selection in the “ ” position. For further information, we recommend you to consult an authorized Mitsubishi Motorsdealer or a repair facility of your choice. On vehicles equipped with the Smartphone- link Display Audio (SDA
), screen operations
can be used to make the adjustment. Refer to the separate owner’
s manual for details.
Defroster position
BK0278200US.book 4 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climat
e control air conditioner Comfort controls 7-5
7
N00731501412
The air conditioner can only be us
ed while the engine is running.
N00711801783
Dual-zone automatic climat
e control air conditioner
CAUTIONThe engine speed may increase when
the air conditioner is operating.
With an increased engine speed, an A/T or
CVT vehicle will creep to a gr
eater degree than with a lo
wer engine speed. Fully depr
ess the brake pedal to pre-
vent the vehicl
e from creeping.
Control panel 1- Air conditioning switch 2- Driver’s side temperature control dial 3- AUTO switch
4- Passenger’s side temperature control
dial
5- MODE switch 6- Defogger switch
7- Blower speed
selection switch
8- SYNC switch 9- Electric rear win
dow defogger switch
 P.5-216
BK0278200US.book 5 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climate
control air conditioner
7-6 Comfort controls
7
N00736901248
Press the blower speed selection switch (1) to increase the blower speed. Press the blower speed selection switch (2) todecrease the blower speed. The selected blower sp
eed will be shown in
the display (A).
10- Air selection switch 11- OFF switch 12- Driver’s side temperature display
 P.7-7
13- Mode selection display 14- Blower speed display 15- SYNC indicator 16- Passenger’s side temperature display
 P.7-7NOTE
There is an interior air temperature sensor (A) in the illustrated position. Never place anything ove
r the sensor, since
doing so will prevent it from functioningproperly.NOTE
 Since the air conditi
oning operation is con-
trolled while the ECO mode is operating,you may feel that effectiveness of the air conditioner is insufficient.  ECO mode switch P.5-209
Even during ECO mode operation, you can select normal operati
on of the air condi-
tioner.On vehicles equipped with the Smartphone- link Display Audio (SDA
), screen operations
can be used to change
the setting. Refer to
the separate owner’
s manual for details.
 In extreme cold, the air conditioning control panel screen may ope
rate sluggishly. This
does not indicate a problem. It will disappear when the vehicle interiortemperature rises to a normal temperature.NOTE
Blower speed selection switch 1- Increase 2- Decrease
BK0278200US.book 6 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climat
e control air conditioner Comfort controls 7-7
7
N00737001536
Turn the temperature control dial clockwise to make the air warmer. Turn it counterclock- wise to make the air cooler.The selected temperature will be shown in the display (A).
The above indicates th
e factory settings. You
can personalize the air selection switch and
NOTE
 Due to a drop in the battery voltage or some other problem, the blower speed may tempo-rarily become less than the selected blowerspeed display setting or the fan may stop. If the fan stops, turn the ignition switch to the “OFF” position or
set the operation mode
to OFF, wait a few minutes, and then turn the ignition switch back to
the “ON” position or
set the operation m
ode back to ON.
In the following cases, have the system inspected by your authorized Mitsubishi Motors dealer or a repair facility of yourchoice. • The blower speed remains lower than the blower speed set using the blower speed display or the blower
speed decreases fre-
quently. • The fan does not operate even after stop- ping and restarting the engine or the fanstops frequently.
Temperature control dial
NOTE
 The temperature value
of air conditioner is
switched in conjunction
with outside temper-
ature display unit of
the multi information
display. Refer to “Changing the temperature unit” onpage 5-172.
 When the engine coolant temperature is low, the air temperature from the heater will becool/cold until the engine warms up, even ifyou have selected warm
air with the dial.
To prevent the windshield and windows from fogging up, the vent mode
will be changed to
“ ” and the blower sp
eed will be reduced
while the system is operating in the AUTO mode.  When you feel that it is hotter or colder than the set temperature, you may adjust it to yourpreference. For further information, we recommend you to consult an authorized Mitsubishi Motorsdealer or a repair fa
cility of your choice.
 When the temperature is set to the highest or the lowest setting, the air selection and the air conditioner will be
automatically changed
as follows.Also, if the air select
ion is operated manually
after an automatic ch
angeover, manual oper-
ation will be
selected.
• Quick Heating (When the temperature is set to the highest setting)Outside air will be introduced and the air conditioner will stop. • Quick Cooling (When th
e temperature is set
to the lowest setting) Inside air will be re
circulated and the air
conditioner will operate.NOTE
SC00000700-5.fm 7 ページ ２０１９年４月１５日　月曜日　午後２時０分

Dual-zone automatic climate
control air conditioner
7-8 Comfort controls
7
air conditioning switch to match your per- sonal preferences.Contact your Mitsubishi
Motors dealer or a
repair facility of your choice for assistance. Refer to “Personalizi
ng the air conditioning
switch (Changing the function setting)” on page7-11. Refer to “Personalizing the air selection(Changing the function setting)” on page7-10. When the “SYNC” indicator (A) goes off by turning the passenger’s side temperature con- trol dial (B) or pressing the SYNC switch, the driver’s side and the passenger’s side temper-ature can be controlled
independently of each
other.
N00737101306
To change the amount of air flowing from thevents, press the MODE switch. Each time the MODE switch is presse
d, the mode changes
to the next one in the following sequence: “”
 “”
 “”
 “”
 “”

“ ”. The selected mode
is shown in the dis-
play (A). Refer to “C
hanging the mode selec-
tion” on page 7-3.

To control the driver’s side and the passenger’s side temperature inde-pendently
NOTE
 When the “SYNC” indi
cator (A) appears by
pressing the SYNC switch, the passenger’sside temperature will
be controlled to the
same setting temperature
as the driver’s side.
While the “SYNC” indicator (A) is dis- played, if the driver’s side temperature con-trol dial is turned
, the passenger’s side
setting temperature wi
ll be synchronized to
the driver’s side.
Mode switch
BK0278200US.book 8 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climat
e control air conditioner Comfort controls 7-9
7
N00703401113
When this switch is pressed, the mode changes to the “ ” mode and the blower speed will be set at the maximum automati- cally. The indicator light (A) will come on and the “ ” mode is shown in the display (B).
N00737201495
Normally, use the outside air position to keep the windshield and side
windows clear and to
quickly remove fog or frost from the wind-shield. To change the air selection, simply press the air selection switch.  Outside air {Indicator light (A) OFF} Outside air is introduced into the passen-ger compartment.  Recirculated air {Ind
icator light (A) ON}
Air is recirculated
inside the passenger
compartment.
When the air conditioning turns on, the air selection is controlled automatically. Whenthe air conditioning turns
off, the air selection
automatically goes back to the outside posi- tion.If high cooling performan
ce is desired, or if
the outside air is dusty or contaminated in some way, use the recirculation position.Switch to the outside
position every now and
then to keep the windows from fogging up.
Defogger switch
NOTE
 When the defogger switch is pressed, the air conditioning system au
tomatically operates
and outside air (as oppos
ed to recirculated
air) is selected. This automatic switching control is carried out to prevent misting of the windows even if “Disable automatic airconditioning control” or
“Disable automatic
air selection control” is set. Refer to “Person- alizing the ai
r conditioning sw
itch (Changing
the function setting)” on page 7-11, “Person- alizing the air select
ion (Changing the func-
tion setting)” on page 7-10.  The indicator light (A) will go off when adjusting the blower speed.
Air selection switch
CAUTION Using recirculated ai
r for a long time may
cause the windows to fog up.NOTE
 If the mode selection is set “ ” position, you cannot turn the air conditioner off orselect the recirc
ulation position.
This prevents the windows from fogging up.
BK0278200US.book 9 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climate
control air conditioner
7-10 Comfort controls
7
N00712300094
You can change the following functions to match your preference.  Enable automatic air selection control: When the AUTO switch is pressed, the airselection switch will also be automatically controlled.  Disable automatic ai
r selection control:
Even when the AUTO switch is pressed,the air selection switch will not be auto- matically controlled.  Changing the settings Press the air selecti
on switch for approxi-
mately 10 seconds or longer. When the setting has changed, the system will beep and the i
ndicator light (A) will
flash.
• When the setting has changed from enabled to disabled,
the system will beep
three times and the
indicator light (A)
will flash three times. • When the setting has changed from dis-abled to enabled, the system will beep two times and the indicator light (A) will flash three times. On vehicles equipped with the Smart- phone-link Display Audio (SDA), screen operations can also be used to change the setting. Refer to th
e separate owner’s
manual for details.
N00737301500
Push the switch, and the air conditioningcompressor will turn on. The indicator light (A) will come on. Push the switch again and the air condition- ing compressor will stop and the indicatorlight goes off.
 When the engine coolan
t temperature rises to
a certain level, the air selection is automati-cally switched to the
recirculation position
and the indicator light
(A) comes on. At this
time, the system will not switch to the out- side position even if
the air selection switch
is pushed.

Personalizing the air selection (Changing the function setting) NOTE
NOTE
 The factory setting is
“Enable automatic air
selection control”.  When the defogger switch is pressed, the air selection will automatically change to theoutside air position, even if the system is set to “Disable automatic air selection control”, in order to prevent windows from foggingup.
Air conditioning switch
NOTE
 If a problem is detected in the air condition- ing compressor, the indicator light blinks. Press the air conditioni
ng switch once to turn
it off, then once more to turn it back on. Ifthe indicator li
ght does not blink, there is no
problem. If it does blink,
have it checked at
an authorized Mitsubish
i Motors dealer or a
repair facility
of your choice.
BK0278200US.book 10 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climat
e control air conditioner Comfort controls 7-11
7
N00712200107
You can change the following functions to match your preference.  Enable automatic ai
r conditioning control:
When the AUTO switch is pressed, orwhen the temperature control dial has been set to the minimum temperature, the air conditioning switch
is automatically
controlled.  Disable automatic air conditioning con- trol: The air conditioning switch is not auto-matically controlled, unless the air condi- tioning switch is used.  Changing the settings Press the air condi
tioning switch for
approximately 10 seconds or longer.
When the setting has changed, the system will beep and the i
ndicator light (A) will
flash. • When the setting has changed from enabled to disabled, the system will beepthree times and the indicator light (A) will flash three times. • When the setting has changed from dis-abled to enabled, the system will beep two times and the indi
cator light (A) will
flash three times. On vehicles equipped with the Smart- phone-link Display Audio (SDA), screen operations can also be used to change thesetting. Refer to the separate owner’s manual for details.
N00703501097
When the AUTO switch is pressed, the indi-cator light (A) comes on and the mode selec- tion, blower speed adju
stment, reci
rculated/
outside air selection, temperature adjustment, and air conditioner ON/
OFF status are all
controlled automatically. The selected modeand the blower speed are not shown in the display.
 For example, sometimes after using a high- pressure car wash, the
condenser can get wet,
and the indicator light
blinks temporarily.
Wait for a while, pres
s the air conditioning
switch once to turn the system off, then once more to turn it back on. Once the water evap-orates, the blinking will stop.

Personalizing the
air conditioning
switch (Changing the function set-ting) NOTE
NOTE
 The factory setting is “Enable automatic air conditioning control”.  When the defogger switch is pressed, the air conditioner will run automatically, even ifthe system is set to “Disable automatic air conditioning control”, in order to prevent windows from fogging up.
AUTO switch
BK0278200US.book 11 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climate
control air conditioner
7-12 Comfort controls
7
N00703601072
Push the switch to turn off the air condition- ing system.
N00731701629
In normal conditions, use the system in the AUTO mode and follow these procedures: 1. Push the AUTO switch. 2. Set the temperature control dial to the desired temperature. The temperature can be set within a range of around 61 (LO) to89 (HI) (when the outside temperature unit of the multi-information display shows °F) or 17 (LO) to 31 (HI) (when theoutside temperature unit of the multi- information display shows °C).
The vents, recirculati
on/outside air, blower
speed, temperature ad
justment, and ON/OFF
of air conditioner will be
controlled automati-
cally.
N00731801125
Blower speed and vent mode may be con- trolled manually by setting the blower speedselection switch and the MODE switch to the desired positions. To
return to automatic
operation, press the AUTO switch.
OFF switch
Operating the air conditioning system (automatic mode)
NOTE
 Set the temperature at approximately 75 (when the outside temp
erature unit of the
multi-information display shows °F) or 24(when the outside temp
erature unit of the
multi-information display shows °C) under normal conditions.  When the engine coolan
t temperature is low,
the air temperature from the heater will becool/cold until the engi
ne warms up, even if
you have selected warm
air with th
e temper-
ature dial. To prevent the windshield andwindows from fogging up, the vent mode will be changed to “ ” and the blower speed will be reduced.
Operating the air conditioning system (manual mode)
BK0278200US.book 12 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Important air conditioning operating tips
Comfort controls 7-13
7
N00732401649
To remove frost or mist from the windshield and door windows, use the MODE switch or defogger switch (“ ” or “ ”). Use this setting to ke
ep the windshield and
door windows clear of mist, and to keep theleg area heated (when driving in rain or snow). 1. Set the air selection
switch to the outside
position.
2. Set the MODE switch to the “ ” posi- tion. 3. Select your desired blower speed bypressing the blower speed selection switch. 4. Select your desired temperature by turn-ing the temperature control dial. 5. Push the air conditioning switch. 1. Push the defogger switch. 2. Set the temperature to the highest posi- tion.
N00733701362
1. Park the vehicle in the shade whenever possible. Parking in the hot sun makes the vehicle interior extremely hot which thenrequires more time to cool. If it is neces- sary to park in the sun, open the windows for the first few minutes of air condition-ing to expel the hot air. 2. Afterwards, keep the windows closed when the air conditioner is in use. Theentry of outside air through open windows will reduce cooling efficiency.
Defrosting or defogging (wind- shield, door windows)
CAUTION For safety, make sure you have a clear view through all the windows.

For ordinary defrosting

For quick defrosting NOTE
While the “ ” indicator light is on, the air conditioning compressor
will run automati-
cally. The outside air
position will also be
selected and the blower
speed will be set at
the maximum au
tomatically.
If the “ ” indicator light is on, you cannot turn the air conditioner of
f or select the recir-
culation position. This prevents the windowsfrom fogging up.  To defog quickly, direct the air flow from the side vents toward the door windows.  When defrosting, do not set the temperature to the maximum cool position. This will blow cool air on the
window glass and fog it
up.
Important air conditioning operating tips
NOTE
BK0278200US.book 13 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
