Page 344 of 443
Dual-zone automatic climat
e control air conditioner Comfort controls 7-7
7
N00737001536
Turn the temperature control dial clockwise to make the air warmer. Turn it counterclock- wise to make the air cooler.The selected temperature will be shown in the display (A).
The above indicates th
e factory settings. You
can personalize the air selection switch and
NOTE
Due to a drop in the battery voltage or some other problem, the blower speed may tempo-rarily become less than the selected blowerspeed display setting or the fan may stop. If the fan stops, turn the ignition switch to the “OFF” position or
set the operation mode
to OFF, wait a few minutes, and then turn the ignition switch back to
the “ON” position or
set the operation m
ode back to ON.
In the following cases, have the system inspected by your authorized Mitsubishi Motors dealer or a repair facility of yourchoice. • The blower speed remains lower than the blower speed set using the blower speed display or the blower
speed decreases fre-
quently. • The fan does not operate even after stop- ping and restarting the engine or the fanstops frequently.
Temperature control dial
NOTE
The temperature value
of air conditioner is
switched in conjunction
with outside temper-
ature display unit of
the multi information
display. Refer to “Changing the temperature unit” onpage 5-172.
When the engine coolant temperature is low, the air temperature from the heater will becool/cold until the engine warms up, even ifyou have selected warm
air with the dial.
To prevent the windshield and windows from fogging up, the vent mode
will be changed to
“ ” and the blower sp
eed will be reduced
while the system is operating in the AUTO mode. When you feel that it is hotter or colder than the set temperature, you may adjust it to yourpreference. For further information, we recommend you to consult an authorized Mitsubishi Motorsdealer or a repair fa
cility of your choice.
When the temperature is set to the highest or the lowest setting, the air selection and the air conditioner will be
automatically changed
as follows.Also, if the air select
ion is operated manually
after an automatic ch
angeover, manual oper-
ation will be
selected.
• Quick Heating (When the temperature is set to the highest setting)Outside air will be introduced and the air conditioner will stop. • Quick Cooling (When th
e temperature is set
to the lowest setting) Inside air will be re
circulated and the air
conditioner will operate.NOTE
SC00000700-5.fm 7 ページ 2019年4月15日 月曜日 午後2時0分
Page 361 of 443
Tire repair kit (if so equipped) 8-8 For emergencies
8
1. Park the vehicle on a safe, flat and level place. 2. Set the parking brake firmly.3. Move the selector
lever to the “P”
(PARK) position, and stop the engine. 4. Turn on the hazard warning lights and setup a warning sign, such as a warning tri- angle or flashing signal lamp, at an ade- quate distance from the vehicle, and haveall your passengers leave the vehicle. 5. Take out the tire repair kit. Make sure that the compressor switch isOFF.
6. Shake the tire sealant bottle well. 7. Take the valve cap (D) off the tire valve (E).
8. Unwind the bottle hose (F) from around the sealant bottle. 9. Pull out the compressor’s hose (G) from the bottom of the compressor and securely attach it to the valve (H) of the bottle byturning it clockwise until tight.
Immediately wash clothes contaminated with tire sealant. The tire sealant may not beremoved from the clothes.NOTE
Do not pull out an object, such as a nail or screw, that penetrat
es the punctured tire.
Move the vehicle so th
at the tire valve is
positioned away from the point where thetire touches the ground. If the valve is near the point where the tire touches the ground, the sealant may not enter the tire easily. Check the tire sealant’
s expiration date regu-
larly, and be sure to
purchase a new one from
an authorized Mitsubishi Motors dealer before the expiration date.CAUTION
NOTE
In cold conditions (w
hen the ambient tem-
perature is 32 °F {0 °C} or lower), thicken- ing of the tire sealant can make the tiresealant hard to squeeze out of the bottle. Warm the bottle betw
een your hands inside
the vehicle.
BK0278200US.book 8 ページ 2019年4月10日 水曜日 午前10時59分
