MITSUBISHI OUTLANDER SPORT 2017 3.G Owners Manual

Engine specifications 11-4 Specifications
11
GVWR: maximum total weight (load) limit specified for the vehicle GAWR: maximum weight (load) limit sp
ecified for the front or rear axle
Seating capacity: the maximum number of occupants
N01147701537
N01147801336
Battery is a 12 volt type.
Maximum roof load 176 lb (80 kg)Seating capacity 5 persons
NOTE
 Roof load is important because it affects the vehicle capacity
weight. Refer to “Loading cargo on the roof” on page 6-11.
Engine specifications
Item
2.0 liter models
2.4 liter models
Engine model 4B11 4B12Engine displacement 121.9 CID (1,998 cm³) 144.0 CID (2,360 cm³)No. of cylinders and cylinder arrangement 4 in lineBore 3.39 in (86.0 mm) 3.46 in (88.0 mm)Stroke 3.39 in (86.0 mm) 3.82 in (97.0 mm)Compression ratio 10.0 10.5Thermostat valve opening temperature 189 °F (87 °C)Spark plugs
NGK DIFR6C11 DIFR5C11
Spark plug gap .040 to .043 in (1.0 to 1.1 mm)Firing order
1-3-4-2
Battery
75D23L
BK0239500US.bo
ok 4 ページ ２０１６年５月１３日　金曜日　午前８時５３分

Tires and wheels
Specifications 11-5
11
N01147901816
PCD: Pitch Circle Diameter (installation holes)
N01148002244
Tires and wheels Tire
P215/70R16
99H
P225/55R18
97H
Wheel
Size 16 x 6 1/2J 18 x 7JPCD 4.5 in (114.3 mm)Off- set
1.81 in (46 mm)
1.50 in (38 mm)
NOTE
 Contact an authorized Mitsubishi Motors dealer for details on the combination used on your vehicle.  These tires satisfy vehicle loading conditions described in this owner’s manual.
Capacity
Item
Capacity
Lubricants
Fuel (approximate)
Front-wheel drive vehicles 16.6 gal (63 L)
Refer to “Fuel selection” on page 3-2.
All-wheel drive vehicles 15.8 gal (60 L)Vehicles with manual trans- axle
Oil pan 4.2 qt (4.0 L)
Engine oils displaying the IL
SAC certification mark (“star-
burst” symbol) on the container. If these oils are not available,
API classification SN or higher
can be used.
Oil filter .32 qt (0.3 L)
Vehicles with continuously variable trans- mission (CVT)
Oil pan 4.5 qt (4.3 L)Oil filter .32 qt (0.3 L)
Manual transaxle 2.6 qt (2.5 L)
Mitsubishi Motors Genuine NEW MULTI GEAR OIL API classification GL-3 SAE 75W-80
Continuously variable trans- mission (CVT)
2.0 liter models 7.3 qt (6.9 L)
Refer to “Continuously variable
transmission (CVT) fluid” on
page 9-9.
2.4 liter models 7.5 qt (7.1 L)
BK0239500US.bo
ok 5 ページ ２０１６年５月１３日　金曜日　午前８時５３分

Capacity 11-6 Specifications
11
* : similar high quality ethylene glycol based non-silicate, non-am
ine, non-nitrate and non-borate
coolant with long life hybrid
organic acid tech-
nologyTransfer oil .53 qt (0.5 L)
Mitsubishi Motors Genuine Super Hypoid Gear Oil API classi- fication GL-5 SAE 80
Differential
Rear axle .42 qt (0.4 L)
Mitsubishi Motors Genuine Super Hypoid Gear Oil API classi- fication GL-5 SAE 80
Brake/Clutch (if so equipped) As required C
onforming to Brake fluid DOT3 or DOT4
Hood lock release mechanism and safety catch As required Multipurpose type grease NLGI Grade 2Engine coolant {Includes .69 qt (0.65 L) in reserve tank}
7.9 qt (7.5 L)
Mitsubishi Motors Genuine Super Long Life Coolant Premium or equivalent
*
Washer fluid 4.8 qt (4.5 L) —
Item
Capacity
Lubricants
BK0239500US.bo
ok 6 ページ ２０１６年５月１３日　金曜日　午前８時５３分

Alphabetical index
12-1
12
Numerics
4-wheel drive operation
.......................
5-60
A
Accessory (installation)
.........................
3-6
Active stability control (ASC)
..............
5-70
Air bag
......................
........................
4-26
Air cleaner filter
...................
................
9-8
Air conditioning
Automatic air conditioning
.....
7-14
, 7-19
Important air conditioning operating tips
..
7-24Manual air conditioning
.............
7-4
, 7-9
Air purifier
....................
.....................
7-25
Aluminum wheels
...............................
9-44
AM/FM radio
....................
.................
7-25
Anti-lock braking system
.....................
5-67
Arm rest
........................
.......................
4-7
Assist grip
.....................
...................
5-178
Audio
AM/FM radio
................
.................
7-25
CD player
.....................
.................
7-25
Troubleshooting
.............................
7-60
Automatic air conditioning
.........
7-14
, 7-19
Automatic transaxle
Fluid
......................
........................
11-5
B
Back-up light
Bulb capacity
..................
...............
9-30
Replacement
...................
...............
9-38
Ball joint, steering linkage seals and drive shaft boots
.....................
..................
9-24
Battery
........................
......................
9-11
Charging system warning light
.......
5-121
Disconnection and connection
.........
9-13
During cold weather
.......................
9-13
Specification
...................
...............
11-4
Bluetooth 2.0 interface
.......................
5-137
Bottle holders
...................
.................
5-177
Brake
Fluid
.......................
......................
11-5
Brake assist system
.............................
5-66
Braking
.......................
........................
6-5
Anti-lock braking system
................
5-67
Hose
.......................
......................
9-23
Pad wear alarm
...............
...............
5-65
Parking brake
..................
...............
5-40
Pedal
.......................
......................
5-64
Pedal free play
................
...............
9-21
Power brakes
..................
...............
5-64
Service brake
..................
...............
5-64
Warning lights
..............................
5-120
Break-in recommendations
....................
5-3
Bulb capacity
...................
..................
9-30
C
California Perchlorate Materials Requirements
.....................
................
3-6
Capacities
.....................
.....................
11-5
Card holder
...................
...................
5-164
Cargo area cover
................
...............
5-177
Cargo loads
...................
.....................
6-10
Cargo room light
Bulb capacity
................
.................
9-32
Catalytic converter
................
................
9-2
Cautions on the handling of all-wheel drive vehicles
.......................
.....................
5-63
CD player
......................
.....................
7-25
Certification label
...............................
11-3
Charging system warning light
...........
5-121
Child restraint systems
........................
4-19
Child safety locks for rear door
............
5-31
Cleaning
Inside of your vehicle
......................
9-40
Outside of your vehicle
...................
9-41
Clutch
Pedal free play
...............
.................
9-21
Coat hook
......................
...................
5-178
Consumer information
.........................
10-2
Continuously variable transmission (CVT)
...
5-51
BK0239500US.bo
ok 1 ページ ２０１６年５月１３日　金曜日　午前８時５３分

Alphabetical index 12-2
12
Fluid
.....................
.................
9-9
, 11-5
Selector lever operation
...................
5-51
Selector lever positions
...................
5-54
Sports mode
..................
.................
5-55
Coolant (engine)
..........................
9-7
, 11-5
Cruise control
....................
.................
5-73
Cup holder
....................
...................
5-176
D
Daytime running lights
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-37
Defogger (rear window)
....................
5-136
Defrosting or defogging (windshield, door windows)
.................
7-8
, 7-13
, 7-18
, 7-24
Dimensions
...................
.....................
11-3
Dimmer (high/low beam change)
.......
5-127
Disc brake pads
.................
.................
9-23
Dome light
Bulb capacity
................
.................
9-32
Doors
Lock
......................
........................
5-28
Power door locks
............................
5-30
Driving during cold weather
..................
6-5
Driving precaution
................
................
6-2
Driving, alcohol and drugs
.....................
6-2
E
Electric rear window defogger switch
..5-136
Electronic immobilizer (Anti-theft starting system)
.....................
................
5-4
, 5-23
Electronically controlled 4WD system
..5-58
Emission-control system maintenance
...
9-22
Engine
Compartment
..................
.................
9-5
Coolant
...................
................
9-7
, 11-5
Hood
.......................
........................
9-3
Oil and oil filter
.......................
9-5
, 11-5
Overheating
....................
.................
8-4
Serial number
.................
................
11-2
Specification
...................
................
11-4
Engine coolant temperature display
.......
5-92
Engine hood
....................
....................
9-3
Engine switch
.....................
................
5-17
Exhaust system
...................
................
9-24
F
Floor console box
..............................
5-175
Floor mat
.........................
....................
6-3
Fluid
Automatic transaxle fluid
.................
11-5
Brake fluid
.....................
................
11-5
Continuously variable transmission (CVT) fluid
...................
...................
9-9
, 11-5
Engine coolant
.........................
9-7
, 11-5
Washer fluid
.........................
9-10
, 11-5
Fluid capacities and lubricants
.............
11-5
Free-hand advanced security transmitter (F.A.S.T.-key)
.................
.................
5-12
Front fog lights
Bulb capacity
................
.................
9-30
Indicators
..................
...................
5-120
Replacement
.................
.................
9-35
Switch
......................
...................
5-130
Front seat adjustment
............................
4-3
Front side-marker lights
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-34
Front turn signal light
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-35
Fuel
Filling the fuel tank
...........................
3-3
Fuel economy
...................
................
6-2
Fuel hoses
.....................
.................
9-23
Fuel selection
...................
................
3-2
Tank capacity
................
.................
11-5
Fuses
.........................
........................
9-25
Fusible links
..................
.....................
9-25
G
General maintenance
Maintenance
..................
.................
9-23
General vehicle data
............................
11-3
BK0239500US.bo
ok 2 ページ ２０１６年５月１３日　金曜日　午前８時５３分

Alphabetical index
12-3
12
Genuine parts
....................
...................
3-6
Glove compartment
...........................
5-174
H
Hazard warning flasher switch
...........
5-130
Hazard warning lights
.......................
5-119
Head restraints
...................
...................
4-7
Headlight leveling switch
..................
5-129
Headlights
Bulb capacity
................
.................
9-30
Dimmer
....................
...................
5-127
Headlight flasher
..........................
5-127
Replacement
.........................
9-32
, 9-33
Switch
......................
...................
5-123
High beam indicator
..........................
5-120
High-mount stop light
Bulb capacity
................
.................
9-30
Hill start assist
...................
.................
5-65
HomeLink® Wireless Control System 5-165 Hood lock release mechanism and safety catch
........................
........................
9-24
Horn switch
...................
...................
5-136
I
If the vehicle breaks down
.....................
8-2
Ignition switch
...................
.................
5-46
Important facts to know in case of an accident 10-4 Indicators
....................
.....................
5-119
Information screen display
..................
5-83
Inside rearview mirror
.........................
5-42
Inspection and maintenance following rough road operation
...................
...............
5-63
Instrument cluster
................
...............
5-85
Interior lights
...................
.................
5-170
J
Jack
Storage
........................
....................
8-5
Jump-starting the engine
.......................
8-2
K
Key slot
.......................
......................
5-22
Keyless entry system
....................
5-7
, 5-25
Keys
...........................
........................
5-3
L
Labeling
......................
......................
11-2
License plate light
Bulb capacity
..................
...............
9-30
Replacement
...................
...............
9-39
Liftgate
.......................
......................
5-32
Inside liftgate release
......................
5-33
Link System
..................
...................
5-137
Loading information
..............................
6-7
Lubricants
.....................
.....................
11-5
Luggage hooks
..................
...............
5-179
M
Malfunction indicator light
................
5-120
Manual air conditioning
..................
7-4
, 7-9
Manual transaxle
................
.................
5-49
Oil
............................
.......................
9-9
Shift points (recommended speed)
....
5-50
Modification of your vehicle
..................
3-5
Multi-information display
....................
5-83
O
Octane rating
.....................
...................
3-2
Oil
Engine oil
...............................
9-5
, 11-5
Manual transaxle oil
..........................
9-9
Rear axle oil
..........................
9-10
, 11-5
Transfer oil
.............................
9-9
, 11-5
Operation mode
.................
.................
5-17
Operation under adverse driving conditions
..
8-14 Outside rearview mirrors
.....................
5-44
Overheating
.......................
...................
8-4
BK0239500US.bo
ok 3 ページ ２０１６年５月１３日　金曜日　午前８時５３分

Alphabetical index 12-4
12
P
Parking
.........................
.......................
6-6
Parking brake break-in
....................
9-21
Parking brake lever stroke
...............
9-21
Parking brake
....................
.................
5-40
Parking lights
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-34
Polishing
.......................
.....................
9-43
Power brakes
.....................
.................
5-64
Power outlet
..................
...................
5-164
Power windows
.................
.................
5-37
Puncture (Tire changing)
.......................
8-6
R
Radio
General information about your radio 7-63
Reading lights
Bulb capacity
................
.................
9-32
Rear axle oil
...............
...............
9-10
, 11-5
Rear combination lights
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-37
Rear side-marker lights
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-37
Rear turn signal light
Bulb capacity
..................
................
9-30
Replacement
...................
................
9-37
Rear-view camera
...............
................
5-81
Rearview mirror
Inside rearview mirror
.....................
5-42
Outside rearview mirrors
.................
5-44
Replacement of light bulbs
...................
9-29
Replacing tires and wheels
...................
9-19
Reporting Safety Defects
.....................
10-2
S
Safe driving techniques
.........................
6-4
Seat belt
......................
.......................
4-11
Adjustable seat belt shoulder anchor
.4-17
Child restraint systems
.....................
4-19
Front passenger seat belt warning light
.....
4-16Maintenance and inspection
.............
4-26
Seat belt extender
............................
4-17
Seat belt force limitter
.....................
4-19
Seat belt pre-tensioners
....................
4-17
Seat belt use during pregnancy
.........
4-17
Seats
...........................
........................
4-2
Arm rest
......................
....................
4-7
Front seats
...................
....................
4-3
Head restraints
................
.................
4-7
Heated seat
.....................
.................
4-6
Seats and restraint systems
................
4-2
Service brake
...................
...................
5-64
Service precautions
...............
................
9-2
Side turn signal light
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-35
Snow tires
.....................
.....................
9-20
Spark plugs
...................
.....................
9-22
Starting the engine
..............................
5-47
Steering
Power steering fluid
........................
11-5
Steering wheel height and reach adjustment5-41
Stop lights
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-37
Storage spaces
...................
...............
5-174
Sun visors
.....................
...................
5-163
Sunshade
......................
.....................
5-39
Supplemental Restraint System
............
4-26
How the Supplemental Restraint System works
.....................
.....................
4-29
Maintenance service
.......................
4-41
T
Tail light
Bulb capacity
................
.................
9-30
Replacement
.................
.................
9-37
Tank capacity
....................
.................
11-5
Theft-alarm system
.............................
5-34
BK0239500US.bo
ok 4 ページ ２０１６年５月１３日　金曜日　午前８時５３分

Alphabetical index
12-5
12
Tire
...........................
........................
9-14
Inflation pressure
............................
9-18
Maintenance
..................
.................
9-19
Quality grading
...............................
10-2
Replacing tires and wheels
...............
9-19
Rotation
....................
.....................
9-19
Size (tire and wheel)
.......................
11-5
Snow tires
.....................
.................
9-20
To change a tire
................
................
8-6
Tread wear indicator
.......................
9-19
Tire pressure monitoring system
...........
5-77
Tires
Tire and loading information placard 11-2 Tire chains
....................
.................
9-21
Tools
.........................
..........................
8-5
Storage
.........................
...................
8-5
Towing
......................
........................
8-12
Trailer towing
....................
.................
6-12
Transfer oil
................
.................
9-9
, 11-5
Turn signal light
Indicators
..................
...................
5-119
Lever
........................
...................
5-129
U
USB input terminal
...........................
5-160
How to connect an iPod
.................
5-161
USB input terminal device
How to connect a USB memory
.....
5-160
V
Vanity mirror
...................
.................
5-164
Vanity mirror lights
Bulb capacity
..................
...............
9-32
Vehicle care precautions
.....................
9-40
Vehicle dimensions
............................
11-3
Vehicle labeling
..................
...............
11-2
Vehicle preparation before driving
.........
6-4
Vehicle weights
...................
...............
11-3
Vents
..........................
........................
7-2
W
Warning lights
.................
.................
5-120
Washer
Fluid
....................
.................
9-10
, 11-5
Rear window washer
.....................
5-135
Switch
.....................
.....................
5-134
Washing
......................
......................
9-42
Waxing
.......................
......................
9-43
Weights
.......................
......................
11-3
Wheel
Covers
.........................
..................
8-11
Specification
...................
...............
11-5
Wiper
Rear window wiper
.......................
5-135
Switch
.....................
.....................
5-131
Wiper blades
...................
...............
9-22
BK0239500US.bo
ok 5 ページ ２０１６年５月１３日　金曜日　午前８時５３分

How to calculate your gasoline mileage
You can calculate your miles-pe
r-gallon or kilometers-per-litre
by using the following process: 1. Fill your vehicle’s fuel tank
and record the odometer mile-
age.
2. Drive your vehicle as you normally do.
3. Refill the fuel tank. Record the odometer mileage again,
as well as the gallons/litres of fuel used.
4. Subtract the first mileage
number from the second number
to know how many miles/kilometers were driven. Divide the number of miles/kilometers driven by the number ofgallons/litres of fuel used. Th
is is your approximate miles-
per-gallon or kilometers-per-litre.
Gas mileage record Gas mileage record
Date
Odometer
Gallons /Litres This Fill
Cost Per Gallon /Litre
Cost This Fill
Miles Per Gallon/Kilo-meters Per Litre(Miles/Gals.)/(Kilome-
ters/Litres)
Date
Odometer
Gallons/Litres This Fill
Cost Per Gallon /Litre
Cost This Fill
Miles Per Gallon/Kilo-meters Per Litre(Miles/Gals.)/(Kilome-
ters/Litres)
last-page.fm 1 ページ ２０１５年６月２６日　金曜日　午後３時４８分
