Roadster models1. Antenna (P.4-20)
2. Trunk lid release switch (P.3-11)
3. Trunk light (P.2-39, P.8-27)
4. High-mounted stop light (Bulb) (P.8-27)
5. Rear window defroster (P.2-21)
6. Soft top (P.3-18)
7. Interior trunk lid release (P.3-12)
8. License plate lights (Bulbreplacement)
(P.8-27)
9. Back-up, Turn signal light (Bulbreplacement)
(P.8-27)
10. Side marker, Stop/Tail light (Bulbreplace-
ment) (P.8-27)
11. Fuel
— Fuel filler lid (P.3-13)
— Fuel recommendation (P.9-3)
SSI0003
0-4
Illustrated table of contents
04.1.22/Z33-D/V5.0
Page 50 of 262
Console box .................................................................. 2-32
Rear floor box ................................................................ 2-33
Rear parcel box ............................................................ 2-33
Stowing golf bags ......................................................... 2-34
Coat hook .............................................................................. 2-35
Windows .............................................................................. 2-35
Power windows ............................................................ 2-35
Automatic adjusting function ...................................... 2-37
Interior lights ........................................................................ 2-37
Interior ............................................................................. 2-37
Map .................................................................................. 2-38
Vanity mirror light (if so equipped) ................................ 2-38Luggage compartment light (Coupe models) ............. 2-39
Trunk light (Roadster models).......................................... 2-39
HomeLink
universal transceiver (if so equipped) .... 2-39
Programming HomeLink
........................................... 2-40
Programming HomeLinkfor Canadian
customers ....................................................................... 2-41
Operating the HomeLinkuniversal
transceiver ...................................................................... 2-42
Programming trouble diagnosis ................................ 2-42
Clearing the programmed information .................... 2-42
Reprogramming a single HomeLink
button ........ 2-42
If your vehicle is stolen ............................................... 2-42
04.1.22/Z33-D/V5.0
Page 67 of 262
Security indicator lightThis light blinks whenever the ignition switch is in
the LOCK, OFF or ACC position. This is normal.How to arm the vehicle security
system1. Close all windows.
The system can be activated even if the
windows are open.
2. Remove the key from the ignition switch.
3. Close and lock all doors, hood and rear
hatch/trunk lid.Lock all doors by pressing the LOCK button
on the keyfob. When using the keyfob, the
hazard indicators flash twice to indicate all
doors are locked.
4. Confirm that the security indicator light
comes on. The security indicator light glows
for about 30 seconds and then blinks. The
system is now activated. If, during this 30
second time period, the door is unlocked by
the key or the keyfob, or the ignition key is
turned to ACC or ON, the system will not
activate.
Even when the driver and/or passengers
are in the vehicle, the system will activate
with all doors, hood and rear hatch/trunk
lid locked and ignition key off. Turn the
ignition key to ACC to turn the system off.
Vehicle security system activationThe security system will give the following alarm:
The headlights blink and the horn sounds
intermittently.
The alarm automatically turns off after ap-
proximately 50 seconds. However, the alarm
reactivates if the vehicle is tampered with
again. The alarm can be shut off by unlocking
a door with the key, or by pressing the
UNLOCK button on the keyfob.The alarm is activated by:
Opening the door without using the key or
keyfob.
Opening the rear hatch or the trunk lid with-
out using the release switch or keyfob.
Opening the hood.
How to stop an activated alarmThe alarm will stop only by unlocking a door with
the key, or by pressing the UNLOCK button on
keyfob. The alarm will not stop if the ignition
switch is turned to ACC or ON.
If the system does not operate as de-
scribed above, have it checked by your
NISSAN dealer.NISSAN VEHICLE IMMOBILIZER
SYSTEM (NVIS)The Nissan Vehicle Immobilizer System (NVIS)
will not allow the engine to start without the use
of the registered NVIS key.
If the engine fails to start using the registered
NVIS key, it may be due to interference caused
by another NVIS key, an automated toll road
device or automated payment device on the key
ring. Restart the engine using the following
procedures:
SIC1699
2-18
Instruments and controls
04.1.22/Z33-D/V5.0
Page 83 of 262
accident or a sudden stop.
STOWING GOLF BAGSFollow the instructions here to stow golf bags in
the rear cargo space of your vehicle. Normally
two bags can be stowed in the luggage area
(Coupe models) or one bag in the trunk (Road-
ster models).
However, in some cases you may not be able to
stow the above number of golf bags in your
vehicle, depending on their sizes or types.
Coupe modelsNormally, two standard golf bags can be stowed
across the strut tower bar in the luggage area as
illustrated (A and B). When stowing a golf bag A
in the rear space, insert the top of the golf baginto left side of the luggage area
1then put the
bag down
2.
SIC2196
2-34
Instruments and controls
04.1.22/Z33-D/V5.0
Page 84 of 262
Roadster modelsNormally, one standard golf bag C can be
stowed in the trunk. Insert the top of the golf bag
into left side of the trunk
1
then put the bag
down
2.The hooks are located above the side windows
as shown in the illustration.
CAUTION:
Do not place items which are more than 2
lb (1 kg) on the hook.
POWER WINDOWS
WARNING
Make sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before clos-
ing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.
Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls
and become trapped in a window.
Unattended children could become
involved in serious accidents.
SIC2237
SIC2378
COAT HOOK WINDOWS
Instruments and controls
2-35
04.1.22/Z33-D/V5.0
Page 88 of 262
The light illuminates when the rear hatch is
opened. When the rear hatch is closed, the light
will go off.The light illuminates when the trunk lid is
opened. When the trunk lid is closed, the light
will go off.The HomeLink
Universal Transceiver provides a
convenient way to consolidate the functions of
up to three individual hand-held transmitters into
one built-in device.
HomeLink
Universal Transceiver:
Will operate most Radio Frequency (RF)
devices such as garage doors, gates, home
and office lighting, entry door locks and se-
curity systems.
Is powered by your vehicle’s battery. No
separate batteries are required. If the vehi-
cle’s battery is discharged or is discon-
nected, HomeLink
will retain all program-
ming.
Once the HomeLinkUniversal Transceiver
is programmed, retain the original trans-
mitter for future programming procedures
(for example, new vehicle purchases).
Upon sale of the vehicle, the programmed
HomeLink
Universal Transceiver buttons
should be erased for security purposes.
For additional information, refer to “Pro-
gramming HomeLink
” later in this sec-
tion.
LUGGAGE COMPARTMENT LIGHT
(Coupe models)TRUNK LIGHT (Roadster models)
HomeLink
UNIVERSAL
TRANSCEIVER (if so equipped)Instruments and controls
2-39
04.1.22/Z33-D/V5.0
Page 94 of 262
3 Pre-driving checks and adjustmentsKeys ......................................................................................... 3-2
Doors ....................................................................................... 3-2
Locking with key ............................................................. 3-3
Locking with inside lock knob..................................... 3-3
Locking with power door lock switch ....................... 3-4
Remote keyless entry system ............................................ 3-4
How to use remote keyless entry system ................ 3-5
Battery replacement ....................................................... 3-8
Hood ........................................................................................ 3-9
Rear hatch (Coupe models) .............................................. 3-9
Opener operation ......................................................... 3-10
Secondary rear hatch release .................................... 3-10
Trunk lid (Roadster models) ............................................ 3-11
Opener operation ......................................................... 3-11
Interior trunk lid release ............................................... 3-12
Secondary trunk lid release ........................................ 3-13
Fuel filler lid ......................................................................... 3-13Opener operation ......................................................... 3-13
Fuel filler cap ................................................................. 3-14
Steering wheel .................................................................... 3-15
Tilt operation .................................................................. 3-15
Extension sun visor (if so equipped) ........................... 3-16
Mirrors ................................................................................... 3-16
Inside mirror ................................................................... 3-16
Automatic anti-glare inside mirror
(if so equipped) ........................................................... 3-17
Outside mirrors ........................................................... 3-17
Soft top operation (Roadster models) ........................... 3-18
Before operating the top ............................................. 3-18
When operating the top .............................................. 3-20
Opening the top ............................................................ 3-23
Closing the top .............................................................. 3-24
If the top does not open or close electrically ........ 3-24
Care of the soft top and the vehicle body.............. 3-27
04.1.22/Z33-D/V5.0
Page 96 of 262
LOCKING WITH KEYThe power door lock system allows you to lock
or unlock all doors including the rear hatch/trunk
lid simultaneously.
Turning the driver’s door key to the rear of the
vehicle will lock all doors including the rear
hatch/trunk lid.
Turning the driver’s door key one time to the
front of the vehicle will unlock the driver’s
door and rear hatch/trunk lid. From that po-
sition, returning the key to neutral (where the
key can only be removed and inserted) and
turning it to the front again within 5 secondswill unlock the passenger’s door.
Opening and closing windowsTurn the driver’s door key towards the front of
the vehicle (UNLOCK position) and hold for
about 1 second, all door windows will begin to
lower.
To close all door windows, turn the key to the
LOCK position and hold for about 1 second.
To stop opening or closing, turn the key to the
neutral position.
In the event of a hand in the way, or other
obstruction, the auto reverse function will acti-
vate.
LOCKING WITH INSIDE LOCK
KNOBPushing the door inside lock knobto the LOCK
or UNLOCK position will lock or unlock the
corresponding door. (The rear hatch/trunk lid
lock is linked with the driver side door lock.)
To individually lock the doors from the outside
(without a key), move the inside lock knobto the
LOCK position. Then close the door.
When locking the door without a key, be
sure not to leave the key inside the vehicle.
SPA1503
SPA1504
Pre-driving checks and adjustments
3-3
04.1.22/Z33-D/V5.0
Page 97 of 262
LOCKING WITH POWER DOOR
LOCK SWITCHAll door locks will be engaged when the power
door lock switch is moved to the LOCK position
with the driver’s or front passenger’s door open.
Then close the door and all doors will be locked.Lockout protectionWhen the power door lock switch (driver or front
passenger) is moved to the LOCK position with
the key in the ignition and any door open, all
doors will lock and unlock automatically. This
helps to prevent the keys from being accidentally
locked inside the vehicle.It is possible to lock/unlock all doors (including
the rear hatch/trunk lid), release the rear
hatch/trunk lid and activate the panic alarm by
using the keyfobfrom outside the vehicle.
Before locking the doors, make sure the
key is not left in the vehicle.
The keyfobcan operate at a distance of approxi-
mately 33 ft (10 m) from the vehicle. (The
effective distance depends upon the conditions
around the vehicle.)
As many as 5 keyfobs can be used with one
vehicle. For information concerning the purchase
and use of additional keyfobs, contact your
NISSAN dealer.
The keyfobwill not function when:
the battery is discharged,
the distance between the vehicle and the
keyfobis over 33 ft (10 m).
The panic alarm and the rear hatch/trunk
lid release will not activate when the key is
in the ignition switch.
CAUTION
The following conditions or occurrences
will damage the keyfob.Do not allow the keyfob to become
wet.
Do not drop the keyfob.
Do not strike the keyfob sharply
against another object.
Do not place the keyfob for an ex-
tended period in an area where tem-
peratures exceed 140°F (60°C).
If a keyfob is lost or stolen, NISSAN
recommends erasing the ID code of that
keyfob. This will prevent the keyfob
from unauthorized use to unlock the
vehicle. For information regarding the
erasing procedure, please contact a
NISSAN dealer.
SPA1505
REMOTE KEYLESS ENTRY
SYSTEM
3-4
Pre-driving checks and adjustments
04.1.22/Z33-D/V5.0
Page 98 of 262
HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM
Locking doors1. Remove the ignition key.*1 *2
2. Close all the doors.*3
3. Push the LOCK button on the keyfob.
4. All the doors will lock.
All of the doors will lock when the LOCK
button on the keyfob is pushed even
though a door remains open and/or the
ignition key is in the ONposition.5. The hazard indicator flashes twice and the
horn chirps once.
When the LOCK button is pushed with all
doors locked, the hazard indicator flashes
twice and the horn chirps once as a reminder
that the doors are already locked.
*1: Doors lock with the keyfobwhile a key is in
the ignition switch. However, the panic
alarm and the rear hatch/trunk lid release will
not activate when the key is in the ignition
switch.
*2: Doors lock with the keyfobwhile the ignition
switch is in the ON position. However, the
hazard indicator and horn will not function.
*3: Doors lock with the keyfobwhile any door is
open. However, the hazard indicator and
horn will not function.
Unlocking doors1. Push the UNLOCK button on the keyfob
once.
The driver’s door and rear hatch/trunk lid
unlock.
The hazard indicator flashes once if all doors
are completely closed with the ignition key in
any position except the ON position.
The interior light turns on and the light timeractivates for 30 seconds when the switch is
in the DOOR position with the ignition key in
any position except the ON position.
2. Push the UNLOCK button on the keyfob
again within 5 seconds.
Passenger’s door unlocks.
The hazard indicator flashes once if all doors
are completely closed.
All doors will be locked automatically unless one
of the following operations is performed within 1
minute of pressing the UNLOCK button.
Any door or rear hatch/trunk lid is opened.
The ignition switch is turned to the ON
position.
The interior light can be turned off without
waiting for 30 seconds by turning the ignition
switch to the ON position or by locking the
doors with the keyfob.
Opening the windowsPush the UNLOCK button on the keyfob and the
driver’s door will unlock.
Continue to press the UNLOCK button for 3
seconds. All the door windows will start to be
lowered.
SPA1433C
Pre-driving checks and adjustments
3-5
04.1.22/Z33-D/V5.0
