Page 109 of 148

CYLINDER BLOCK
EM-109
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
7. Drain engine coolant by removing water drain plugs (1, 4) from
cylinder block both sides as shown in the figure.
8. Remove oil pan (upper, lower). Refer to EM-26, "
OIL PAN AND OIL STRAINER" .
9. Remove front timing chain case, timing chain and rear timing chain case. Refer to EM-53, "
TIMING
CHAIN" .
10. Remove cylinder head. Refer to EM-89, "
CYLINDER HEAD" .
11. Remove knock sensor.
CAUTION:
Carefully handle sensor avoiding shocks.
12. Remove rear oil seal.
13. Remove baffle plate from lower cylinder block.
14. Remove piston and connecting rod assembly as follows:
Before removing piston and connecting rod assembly, check the connecting rod side clearance. Refer
to EM-125, "
CONNECTING ROD SIDE CLEARANCE" .
a. Position crankshaft pin corresponding to connecting rod to be removed onto the bottom dead center.
b. Remove connecting rod bearing cap.
c. Using hammer handle or similar tool, push piston and connect-
ing rod assembly out to the cylinder head side.
CAUTION:
Be careful not to damage the cylinder wall and crankshaft
pin, resulting from an interference of the connecting rod big
end.
15. Remove connecting rod bearings from connecting rod and connecting rod bearing cap.
CAUTION:
Identify installation position, and store them without mixing them up.
16. Remove piston rings form piston.
Before removing piston rings, check the piston ring side clearance. Refer to EM-126, "PISTON RING
SIDE CLEARANCE" .
2 : Washer
3: Plug
: Engine front
PBIC5014E
PBIC2940E
Page 111 of 148
![NISSAN 350Z 2007 Z33 Engine Mechanical Owners Manual CYLINDER BLOCK
EM-111
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
19. Remove lower cylinder block as follows:
Screw M8 bolt [Pitch: 1.25 mm (0.049 in), Length: approx. 50
mm (1.97 in)] NISSAN 350Z 2007 Z33 Engine Mechanical Owners Manual CYLINDER BLOCK
EM-111
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
19. Remove lower cylinder block as follows:
Screw M8 bolt [Pitch: 1.25 mm (0.049 in), Length: approx. 50
mm (1.97 in)]](/img/5/765/w960_765-110.png)
CYLINDER BLOCK
EM-111
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
19. Remove lower cylinder block as follows:
Screw M8 bolt [Pitch: 1.25 mm (0.049 in), Length: approx. 50
mm (1.97 in)] into bolt holes (A) shown in the figure. Then
equally tighten each bolt, and remove lower cylinder block.
CAUTION:
Be careful not to damage the mating surface.
Do not tighten bolts too much.
Do not insert screw driver, this will damage the mating
surface.
20. Remove crankshaft.
21. Pull rear oil seal out from rear end of crankshaft.
22. Remove main bearings and thrust bearings from cylinder block and lower cylinder block.
CAUTION:
Identify installation positions, and store them without mixing them up.
Be careful not to drop main bearing, and to scratch the surface.
23. Remove oil jet.
ASSEMBLY
1. Fully air-blow engine coolant and engine oil passages in cylinder block, cylinder bore and crankcase to
remove any foreign material.
CAUTION:
Use a goggles to protect your eye.
: Engine front
PBIC5016E
: Engine front
PBIC5047E
Page 128 of 148

EM-128
CYLINDER BLOCK
Revision: 2006 November2007 350Z
Piston Pin Outer Diameter
Measure the outer diameter of piston pin with micrometer.
Connecting Rod Bushing Oil Clearance
(Connecting rod bushing oil clearance) = (Connecting rod bushing inner diameter) – (Piston pin outer diame-
ter)
If the measured value exceeds the limit, replace connecting rod assembly and/or piston and piston pin
assembly.
If replacing piston and piston pin assembly, refer to EM-119, "HOW TO SELECT PISTON" .
If replacing connecting rod assembly, refer to EM-131, "CONNECTING ROD BEARING OIL CLEAR-
ANCE" to select the connecting rod bearing.
Factory installed parts grading:
Service parts apply only to grade “0”.
Unit: mm (in)
*: After installing in connecting rod
CYLINDER BLOCK DISTORTION
Using scraper, remove gasket on the cylinder block surface, and also remove engine oil, scale, carbon, or
other contamination.
CAUTION:
Be careful not to allow gasket flakes to enter engine oil or engine coolant passages.Standard : 21.989 - 22.001 mm (0.8657 - 0.8662 in)
PBIC0117E
Standard : 0.005 - 0.017 mm (0.0002 - 0.0007 in)
Limit : 0.030 mm (0.0012 in)
A : Sample code
B : Bearing stopper groove
C : Small end diameter grade
D : Big end diameter grade
E : Weight grade
F : Cylinder No.
G : Management code
H : Front mark
I : Management code
PBIC5046E
A : Piston grade number
B : Front mark
C : Piston pin grade number
Grade 0 1
Connecting rod bushing
inner diameter * 22.000 - 22 .0 06
(0.8661 - 0.8664) 22.006 - 22.012
(0.8664 - 0.8666)
Piston pin hole diameter 21.993 - 21.999
(0.8659 - 0.8661) 21.999 - 22. 005
(0.8661 - 0.8663)
Piston pin outer diameter 21.989 - 21.995
(0.8657- 0.8659) 21.995 - 22.001
(0.8659 - 0.8662)
PBIC4994E
