instrument panel NISSAN 350Z 2007 Z33 Wiper, Washer And Horn Workshop Manual

WW-2Revision: 2006 November2007 350Z INSTALLATION .................................................... 35
Removal and Installation of Washer Pump ............. 35
REMOVAL ........................................................... 35
INSTALLATION .................................................... 35
REAR WIPER AND WASHER SYSTEM .................. 36
Components Parts and Harness Connector Loca-
tion .......................................................................... 36
System Description ................................................. 36
OUT LINE ............................................................ 36
BCM WIPER SWITCH READING FUNCTION .... 37
Wiring Diagram — WIP/ R — ................................. 38
Terminals and Reference Values for BCM .............. 40
How to Proceed With Trouble Diagnosis ................ 41
Preliminary Check .................................................. 42
CHECK POWER SUPPLY AND GROUND CIR-
CUIT .................................................................... 42
CONSULT-III Function (BCM) ................................. 43
DATA MONITOR .................................................. 43
ACTIVE TEST ..................................................... 43
Rear Wiper Does Not Operate ............................... 43
Rear Wiper Does Not Return to Stop Position ........ 45
Only Rear Wiper ON Does Not Operate ................. 46
Only Rear Wiper INT Does Not Operate ................ 46
Wiper Does Not Wipe When Rear Washer Operates ... 46
Rear Wiper Does Not Stop ..................................... 46
Removal and Installation of Rear Wiper Arm, Adjust-
ment of Wiper Arms Stop Location ......................... 46
REMOVAL ........................................................... 46
INSTALLATION .................................................... 47
Removal and Installation of Rear Wiper Motor ....... 47REMOVAL ............................................................ 48
INSTALLATION .................................................... 48
Washer Nozzle Adjustment ..................................... 48
Washer Tube Layout ............................................... 49
Removal and Installation of Rear Washer Nozzle ... 49
REMOVAL ............................................................ 49
INSTALLATION .................................................... 49
Inspection for Washer Nozzle ................................. 49
CHECK VALVE INSPECTION ............................. 49
Inspection of Rear Wiper and Washer Switch Circuit ... 49
Removal and Installation of Rear Wiper and Washer
Switch ..................................................................... 49
Removal and Installation of Washer Tank ............... 50
Removal and Installation of Washer Pump ............. 50
POWER SOCKET ..................................................... 51
Wiring Diagram — P/SCKT — ................................ 51
Removal and Installation (Luggage Floor Finisher
Lower) ..................................................................... 52
REMOVAL ............................................................ 52
INSTALLATION .................................................... 52
Removal and Installation (Instrument Passenger
Panel Lower) ........................................................... 52
REMOVAL ............................................................ 52
INSTALLATION .................................................... 52
HORN ........................................................................ 53
Wiring Diagram — HORN — .................................. 53
Removal and Installation ......................................... 54
REMOVAL ............................................................ 54
INSTALLATION .................................................... 54

WW-34
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 November2007 350Z
Inspection of Front Wiper and Washer Switch CircuitNKS0052T
Refer to LT- 9 2 , "Combination Switch Inspection" .
Removal and Installation of Front Wiper and Washer SwitchNKS0052U
REMOVAL
1. Remove steering column lower cover and combination meter.
Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect wiper and washer switch connector.
3. Pull wiper and washer switch toward the passenger door while
pressing pawls in direction shown by the arrow ( ) in the figure,
and remove it from the base.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of Washer TankNKS0052V
REMOVAL
1. Remove clip and pull out washer tank inlet.
2. Remove under cover.
3. Remove fender protector. Refer to EI-21, "
FENDER PROTEC-
TOR" .
4. Remove front bumper fascia. Refer to EI-14, "
FRONT
BUMPER" .
5. Disconnect washer pump connector.
6. Remove washer tank mounting bolt and nuts.
7. Remove washer tube, and remove washer tank from the vehicle.
PKIB4999E
PKIA1903E
PKIB1791E
PKIA3704E

WW-52
POWER SOCKET
Revision: 2006 November2007 350Z
Removal and Installation (Luggage Floor Finisher Lower)NKS0053L
REMOVAL
1. Remove power socket finisher assembly using a clip driver or a
suitable tool.
2. Disconnect power socket connector.
3. Remove inner socket from ring. While pressing hook on ring out
from square hole.
4. Remove ring from power socket finisher while pressing pawls.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation (Instrument Passenger Panel Lower)NKS0053M
REMOVAL
1. Remove socket using a clip driver or a suitable tool that pressing
pawls in socket hole.
2. Disconnect power socket connector.
3. Remove ring from instrument passenger panel lower.
INSTALLATION
Installation is the reverse order of removal.
PKIA1915E
PKIB1789E
