Page 291 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual Replacement procedures
All other lights are either type A, B, C or D. When
replacing a bulb, first remove the lens, lamp
and/or cover.
Indicates bulb removal
Indicates bulb installationUse a cloth
s1t

Page 292 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual Use a cloths1to protect the light housing. Use a cloths1to protect the light housing.
Front map light
WDI0584
Rear map light
WDI0585
High-mounted stop light (rear window)
WDI0320
8-28Maintenance and d

Page 293 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual If you have a flat tire, see the “In case of
emergency” section of this manual.
TIRE PRESSURE
Tire Pressure Monitoring System
(TPMS)
This vehicle is equipped with the Tire
Pressure Monitoring Syst

Page 294 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual Incorrect tire pressure, including un-
der inflation, may adversely affect
tire life and vehicle handling.
WARNING
cImproperly inflated tires can fail
suddenly and cause an accident.
cThe Gross Vehicl

Page 295 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual Tire and loading information label
s1Seating capacity: The maximum num-
ber of occupants that can be seated
in the vehicle.
s2Vehicle load limit: See loading infor-
mation in the “Technical and con-

Page 296 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual Checking tire pressure
1. Remove the valve stem cap from the
tire.
2. Press the pressure gauge squarely
onto the valve stem. Do not press too
hard or force the valve stem side-
ways, or air will escap

Page 297 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual s1Tire size (example: P215/65R15 95H)
1. P: The9P9indicates the tire is de-
signed for passenger vehicles (not all
tires have this information) .
2. Three-digit number (215): This num-
ber gives the w

Page 298 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual s2TIN (Tire Identification Number) for a
new tire (example: DOT XX XX XXX
XXXX)
1. DOT: Abbreviation for the9Depart-
ment Of Transportation.9The symbol
can be placed above, below or to the
left or rig

Page 299 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual s7The word “radial”
The word “radial” is shown if the tire has
radial structure.
s8Manufacturer or brand name
Manufacturer or brand name is shown.
Other Tire-related Terminology
In addition to

Page 300 of 344

NISSAN ALTIMA HYBRID 2007 L32A / 4.G Owners Manual studded tires. Skid and traction capabilities of
studded snow tires on wet or dry surfaces may be
poorer than that of non-studded snow tires.
TIRE CHAINS
CAUTION
Only certain SAE class “S” tire ch
