NISSAN ALTIMA HYBRID 2009 L32A / 4.G Dismantling Guide

11. Remove the outlet duct bolts (1), then remove the outlet
duct (2) from the HV battery (3).










12. Disconnect the HV battery blower motor connector (1)
from the HV battery bl

Page 22 of 22

NISSAN ALTIMA HYBRID 2009 L32A / 4.G Dismantling Guide
22. Disconnect the electrical connectors (1) from the EPS
DC/DC converter (2).
23. Remove the harness clips and harness from the HV
battery.








24. Disconnect the vent hose (3) from
