Page 6 of 27
- 6 -
Engine Compartment
The engine compartment of the Altima Hybrid houses an aluminum alloy 2.5 liter gasoline engine, the high
voltage harnesses, fuse/fusible link box, fuse block, inverter unit, transaxle and electric air conditioning
compressor.
Engine compartment components and locations
1. Fuse/Fusible link box
2.
Fuse block 3. Inverter unit
4. High voltage harness (orange) 5.
Transaxle 6. Electric air conditioning
compressor
7. Gasoline engine A.
HV electrical connector : Vehicle front
Page 19 of 27
- 19 -
Alternative High Voltage System Shut Down Procedure
NOTE:
If the service disconnect procedure cannot be performed, the following alternative shut down procedure is
acceptable.
A. Locate the fuse/fusible link box (1) under the hood near the driver
side strut tower (2).
• : Vehicle Front
B. Remove the fuse/fusible link box cover and remove the IGCT 50
amp fusible link (1) from the fuse/fusible link box (2). If the correct fuse
cannot be recognized, pull all the fuses in the fuse/fusible link box.
