CENTER CONSOLE ASSEMBLYIP-15
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
IP
N
O P
6. Open the fuse block cover, remove the instrument lower cover screw (A), then remove the instrument lower cover (1).
Disconnect the asperator tube and the harness connectors.
7. Remove both the console side finishers.
8. Remove the console upper screws (A).
9. Remove the console side screws (A).
10. Position both RH and LH front seats forward.
11. Remove both the console rear screw covers, then remove the rear screws (A), then remove the console assembly.
INSTALLATION
Installation is in the reverse order of removal.
ALJIA0019ZZ
ALJIA0022ZZ
ALJIA0023ZZ
ALJIA0024ZZ
Revision: September 20092010 Altima
