NISSAN ARMADA 2015 1.G Quick Reference Guide

9
69
HIGH BEAM SELECT

Push the headlight control switch forward
4 to

select the high beam function. The blue indicator
light
will illuminate in the instrument panel.
Pull the headlight switch back to the original
position to select the low beam. The blue
indicator light will extinguish.

Pull and release the headlight control switch
5
to flash the headlight high beams on and off.
FOG LIGHT SWITCH (if so equipped)

The headlights must be on and the low beams
selected for the fog lights to operate.

Turn the switch (inside collar) to the
position 6 to turn the fog lights on.
Turn the switch (inside collar)
to the OFF position to turn the fog lights off.
LANE CHANGE SIGNAL

Move the lever up or down until the turn signal begins to flash but th\
e lever does not
latch to signal a lane change. Hold the lever until the lane change is completed.

Move the lever up or down until the turn signal begins to flash but th\
e lever does not
latch and release the lever. The turn signal will automatically flash 3 times.

Choose the appropriate method to signal a lane change based on the road and
traffic conditions.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
WINDSHIELD WIPER AND WASHER SWITCH
Move the lever to one of the following positions to
operate the windshield wipers:

1 Mist (MIST) – One sweep operation of the
front wipers.

2 Intermittent (INT) – Front wipers operate
intermittently. The intermittent operation speed
can be adjusted by twisting the time control
ring
3 to increase or decrease wiper speed.

4 Low (LO) – Front wipers operate at a
continuous low-speed.

5 High (HI) – Front wipers operate at a
continuous high-speed.

6 Front washer
– Pull the lever toward
you to activate the front washer.
The front wipers will operate several times.
REAR WINDSHIELD WIPER AND WASHER

7 Intermittent (INT) – Rear wiper
operates intermittently.

8 Low (ON) – Rear wiper operates at a continuous low-speed.

9 Rear washer
– Push the lever forward to activate the rear washer. The rear
wiper will operate several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
45
6
3
1
2
4
5
MIST
Type A (if so equipped)
OFF
INT
LO
HI
INT
ON7
8
1904705_15c_Armada_QRG_072315.indd 97/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

10
FIRST DRIVE FEATURES
1
48
9
5
67
23
AUTOMATIC CLIMATE CONTROLS
1 AUTO BUTTON/DRIVER’S SIDE TEMPERATURE CONTROL DIAL

The automatic mode may be used year-round. Press the AUTO button to turn
the system on, and the system will automatically control the inside temp\
erature
(automatic cooling and/or dehumidified heating), air flow distribu\
tion and fan speed.

Turn the driver’s side temperature control dial left for cooler air or right for warmer \
air.
2 DUAL BUTTON/PASSENGER’S SIDE TEMPERATURE CONTROL DIAL

Press the D UAL button to turn the passenger’s side temperature controls on or off.
This will allow the passenger’s side temperature to be adjusted independently from
the driver’s side.

Turn the passenger’s side temperature control dial left for cooler air or right for
warmer air.
3 FAN SPEED CONTROL BUTTONS

Press the fan speed control buttons to manually increase the fan speed

or decrease fan speed .
4 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the front window defroster button
to turn the system on. The A/C
automatically turns on when the defroster mode is selected. This feature removes
humidity from the air.

Use the temperature control dial
1 to set the desired temperature.

To set the front window defroster on high, press the fan speed control bu\
tton to
increase the fan speed to the maximum setting.
5 MODE BUTTON

Press the MODE button
5 to cycle through the following air flow outlets:

Air flows from the center and side vents.

Air flows from the center, side and foot vents.

Air flows mainly from the foot vents.

Air flows from the front defroster and foot vents.
6 REAR WINDOW AND OUTSIDE MIRROR DEFROSTER SWITCH

Push the rear window defroster switch
to turn the system on or off.

The rear window defroster automatically turns off after approximately 15 minutes.
1904705_15c_Armada_QRG_072315.indd 107/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

11
AM/FM/SiriusXM®* SATELLITE RADIO WITH CD/DVD PLAYER
(if so equipped)
1 ON•OFF BUTTON/VOL (volume) CONTROL KNOB

Press the ON•OFF button to turn the system on or off.

Turn the VOL (volume) control knob right or left to increase or decrease the volum\
e.
2 AUDIO BUTTON/TUNE/FLDR KNOB

To manually tune the radio, turn the TUNE/FLDR knob left or right.

Press the AUDIO button to go to the audio settings screen.
3 SEEK/CAT AND TRACK BUTTONS

To scan quickly and stop at the previous or next broadcast station, press the SEEK/CAT button or the TRACK button.

For satellite radio, press the SEEK/CAT button or the TRACK button to
switch to the first channel of the previous or next category.

To change tracks on a CD, press the SEEK/CAT button or the TRACK button.

To rewind or fast forward a track on a CD, press and hold the SEEK/CAT button
or the TRACK button.
2
36
5
1
44
*SiriusXM® Satellite Radio is only available on vehicles equipped with an optional s\
atellite radio subscription service.
7 AIR RECIRCULATION BUTTON

Press the air recirculation button
to recirculate air inside the vehicle. The
indicator light on the button will illuminate. This mode helps to adjust the inside
vehicle temperature more effectively.

Press the air recirculation button
again to turn air recirculation off. This allows
outside air to be drawn into the passenger compartment to prevent foggin\
g in front
defroster, floor or front defroster/floor mode.

The air recirculation mode cannot be activated when the climate control s\
ystem is in
the front defroster mode or the front defroster and foot vent mode.
8 A/C BUTTON

Press the A/C button to manually turn the A/C on or off.
9 OFF BUTTON

Press the OFF button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)” and the “Monitor, climate, audio, phone
and voice recognition systems (section 4)” of your Owner’s Manual.
1904705_15c_Armada_QRG_072315.indd 117/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

12
CRUISE CONTROL
The cruise control system enables you to set a
constant cruising speed once the vehicle has
reached 25 mph (40 km/h).

The system will automatically maintain the set
speed until you tap the brake pedal, accelerate,
cancel or turn the system off.

To activate the cruise control, push the ON/OFF
switch
1. The CRUISE indicator light in the
vehicle information display will illuminate.

To set a cruising speed, accelerate the vehicle to the desired speed, pus\
h the
COAST/SET switch
2 and release. The SET indicator light in the vehicle
information display will illuminate. Take your foot off the accelerator pedal. Your vehicle
will maintain the set speed.

To reset at a faster cruising speed, push and hold the ACCEL/RES switch
3.
When the vehicle attains the desired speed, release the switch.
4
3
2
1
USB ( Universal Serial Bus) CONNECTION PORT/
AUX JACK AND iPOD® INTERFACE
The USB port/Aux jack
1 is located in the
center console under the armrest.

When a compatible USB memory device, iPod® or
auxiliary device is plugged into the USB port/Aux
jack, compatible audio files stored on the device can
be played through the vehicle’s audio system.
For more information, refer to the “Monitor, climate, audio, phone and
voice recognition systems (section 4)” of your Owner’s Manual.
1
4 STATION PRESET BUTTONS

Six stations can be set for the AM band, 12 for the FM band and 18 for satellite radio.

To store a station in a preset, you must first select a radio band by pressing the \

AM/FM button

5 or XM
button
6 then tune to the desired AM, FM or satellite
radio station.

Next press and hold the desired station preset button (1-6) until the preset number
is updated on the display and the sound is briefly muted. The channel indicator will
then come on, and the sound will resume. Programing is now complete.

To retrieve a previously set station, select the radio band where the preset was
stored then press the corresponding station select button (1-6).
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)”
of your Owner’s Manual.
FIRST DRIVE FEATURES
1904705_15c_Armada_QRG_072315.indd 127/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

13
POWER OUTLETS
The power outlets are used for powering
electrical accessories such as cellular
telephones. They are rated at 12 volt,
120W (10A) maximum.

Power outlets are located on the instrument
panel

1, on the rear of the center console 2
and in the cargo area 3.

To use a power outlet, open the cap.

The power outlets are powered only when the
ignition switch is in the ACC or ON position.
For more information, refer to the “Starting and driving (section 5)”
of your Owner’s Manual.
11
2
3
To reset at a slower cruising speed, push and hold the COAST/SET switch
2.
Release the switch when the vehicle slows to the desired speed.

To cancel the preset speed, tap the brake pedal or push the CANCEL switch
4.

To turn off cruise control, push the ON/OFF switch
1. Both the CRUISE
indicator light and SET indicator light in the vehicle information display will extinguish.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
1904705_15c_Armada_QRG_072315.indd 137/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

14
SYSTEM GUIDE
VEHICLE INFORMATION DISPLAY
The vehicle information display
1 is located to
the left of the speedometer.

Press the vehicle information display INFO
button 2 located on the instrument panel to
toggle through the following modes:
• MPG – Displays the instant fuel economy since
the last reset.
• RANGE – Displays the estimated distance the
vehicle can be driven before refueling.
• WARNING – Displays when a warning is present.

To highlight the desired menu option within the
selected mode, turn the INFO button 2.

To enter the highlighted menu, press the INFO button 2.

To reset TRIP A or TRIP B, go to the desired mode on the trip computer and press
and hold the change button 3 for more than 1 second.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
2
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
3
BLUETOOTH® STREAMING AUDIO WITH NAVIGATION
(if so equipped)
If you have a compatible Bluetooth® device with streaming audio (A2DP and AVRCP
profiles), you can set up the wireless connection between your Blueto\
oth® device and
your vehicle’s audio system. This connection allows you to listen to audio from the
Bluetooth
® device using your vehicle’s speakers.

A cellular telephone should not be used while driving so full attention \
may be given to
vehicle operation.*
CONNECTING PROCEDURE FOR A BLUETOOTH
® DEVICE
Use the procedure below to connect your Bluetooth
® audio device to the vehicle:
1. Press the SETTING button on the instrument
panel and touch the “Bluetooth” key on the display.
2. Touch the “Connect Bluetooth” key.
3. A pop-up box will appear on the screen,
prompting you to confirm that the connection is
for the hands-free phone system. Touch the
“No” key.
4. This will bring up the PIN pad on the screen.
Enter a unique 4-digit PIN into the pad and touch
the “OK” key.
• When prompted for a PIN on the device, enter
the unique 4-digit PIN that was entered
on the screen.
1904705_15c_Armada_QRG_072315.indd 147/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

15
• The connecting procedure varies according to
each device model. For detailed connecting
instructions and a list of compatible devices,
please visit www.NissanUSA.com/bluetooth.
5. Verify that the system confirms your device has
been added and then select it as an audio player.
6. Select “Connected Devices” in the Settings menu.
7. Select “Audio Player”.
8. Select the name of the device that you are
attempting to connect as an audio player.
9. Select “Select”.
10. Verify that the system confirms that the device
has been selected as an audio player.
For more information, refer to the “Monitor, climate, audio, phone
and voice recognition systems (section 4)” of your Owner’s
Manual or please visit www.nissanusa.com/bluetooth.
1904705_15c_Armada_QRG_072315.indd 157/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

16
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
BLUETOOTH® HANDS-FREE PHONE SYSTEM
A cellular telephone should not be used
while driving so full attention may be given to
vehicle operation.*
SYSTEM OPERATING TIPS

Press the or button to interrupt the voice
prompts at any time and speak a command after
the tone.

For vehicles not equipped with Navigation:
• To use the system faster, you may speak the
second level commands with the main menu
command on the main menu. For example,
press the
or button, and after the tone,
say “Call Redial”.

For vehicles equipped with Navigation:
• This system has an Alternate Command Mode
setting that allows the total number and length
of prompts to be reduced. When the Alternate
Command Mode is activated, you may speak second level commands with the \
main
menu command. For example, press the
button, and after the tone, say “Call”
followed by a stored name. Refer to the “Voice Recognition (section 9)” of your
Navigation System Owner’s Manual.

The “Help” command can be used to hear a list of available commands\
at any time.

Reduce background noise as much as possible by closing windows and pointing HVAC
vents away from the ceiling.

Speak naturally without long pauses and without raising your voice.

When speaking phonebook names, please be aware some cellular phones requi\
re the
last name to be spoken before the first name. For example, “Michael Smith” may be
spoken as “Smith Michael”.

To cancel a Voice Recognition session, say “Cancel” or “Quit” or press and hold the
or button.

If the Voice Recognition system does not recognize your voice commands, train
the system using the Speaker Adaptation Mode. See your Owner’s Manual for
detailed information.

For more detailed information and instructions, refer to your cellular phone’s Owner’s
Manual and visit www.NissanUSA.com/bluetooth.
Bluetooth®
Controls
Microphone
SYSTEM GUIDE
1904705_15c_Armada_QRG_072315.indd 167/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

17
BLUETOOTH® SYSTEM WITHOUT NAVIGATION* (if so equipped)
PAIRING PROCEDURE

The vehicle must be stationary when pairing the
cellular phone.
1. Press the

button on the steering wheel.
The system announces the available commands.
2. Say: “Connect Phone”. The system acknowledges
the command and announces the next set of
available commands.
3. Say: “Add Phone”. The system acknowledges
the command and announces the next set of
available commands.
4. Initiate connecting from the cellular phone.
• The pairing procedure varies according to each cellular phone model.
For detailed pairing instructions and a list of compatible cellular phones, ple\
ase
visit www.NissanUSA.com/bluetooth.
• When prompted for a PIN, enter “1234” from the handset. (The PIN is assigned by
NISSAN and cannot be changed.)
• For cellular phones that support SSP (Simple Secure Pairing), confirm the PIN on the
vehicle display matches the PIN displayed on the cellular phone.
5. When the system asks you to provide a name for the cellular phone, say the name. You
can give the cellular phone a name of your choice.
PHONEBOOK SETUP

The phonebook stores up to 1,000 entries for each cellular phone paired with the system.

Depending on your cellular phone, the system may automatically download \
your
cellular phone’s entire phonebook to the vehicle’s Bluetooth® system.

If the phonebook does not download automatically, entries can be individually downloaded.

To manually download entries:
1. Push the
button on the steering wheel.
2. After the tone, say “Phonebook”.
3. After the next tone, say “Transfer Entry”. The system acknowledges the command
and asks you to initiate the transfer from the cellular phone handset. T\
he new
contact phone number will be transferred from the cellular phone to the vehi\
cle.
• The transfer procedure varies according to each cellular phone.
See your cellular phone’s Owner’s Manual for details. You can also
visit www.NissanUSA.com/bluetooth for instructions on transferring phone
numbers from NISSAN-recommended cellular phones.
4. The system repeats the number and prompts you for the next command. When you
have finished entering numbers or transferring an entry, choose “Store”.
5. The system confirms the name, location and number.
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
1904705_15c_Armada_QRG_072315.indd 177/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

18
SYSTEM GUIDE
MAKING A CALL FROM THE PHONEBOOK
1. Press the
button.

2. After waiting for the tone, say “Call”.
3. After the next tone, speak the name of a phonebook entry. For example, “Michael Smith”.
4. Confirm the correct name is recognized by saying “Dial” after the tone.

In some cases, names stored using all UPPERCASE letters may not be recognized by
the Voice Recognition system.
MAKING A CALL BY PHONE NUMBER
1. Press the
button.
2. After waiting for the tone, say “Call”. The system acknowledges the command and
announces the next set of available commands.
3. Say: “Number”. The system acknowledges the command and announces the next set
of available commands.
4. Say the number you wish to call starting with the area code in single digit format.
5. When you have finished speaking the phone number, the system repeats it back and
announces the available commands.
6. Say: “Dial”. The system acknowledges the command and makes the call.
RECEIVING/ENDING A CALL
When you receive a cellular phone call, a ring tone sounds through the audio system.

To accept the call, press the
button on the steering wheel.

To reject the call, press the button on the steering wheel.

To hang-up the cellular phone at the end of a call or to disconnect durin\
g call placement,
press the
button on the steering wheel.
1904705_15c_Armada_QRG_072315.indd 187/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
